DH1020VC

15 Amp SDS-max® Demolition Hammer

In-line design – better weight distribution for concrete chiseling and light-duty demolition in horizontal applications
Best-in-class impact energy – 17 Ft.-Lbs. provides maximum concrete removal for productivity
Power-to-weight ratio – 15.0 Amp demo hammer delivers 1,700 BPM at 25.1 Lbs. weight
Vibration Control technology – reduces vibration in hammer mechanism and at handle for improved comfort in all-day demolition applications
Constant Response circuitry – reliable operation with constant speed under load, soft-start control and overload protection
Vario-Lock positioning – locks chisel in one of 12 positions for optimized work angle
360° auxiliary handle – operator comfort due to a wide range of positioning
Variable-speed dial – accurate bit starting and controlled chiseling
SDS-max® bit system – ease of use with tool-free bit changes with automatic bit locking and maximum impact-energy transfer rate
Service Minderlight – indicates when preventative maintenance is required
Padded rear handle – for additional comfort

Manuals

Application Images

Features/Claims

Product Images

Product Images

Product Feature Walk Around Image

Service One Pager

Brand	Bosch
Model Number	DH1020VC
SKU	0611336010
Product Name	15 Amp SDS-max® Demolition Hammer
Short Description	15 Amp SDS-max® Demolition Hammer
List Price - USD	2218.98
MSRP - USD	1149
UNSPSC	Demolition hammers
UNSPSC - Code	27112705
Country of Origin	DE
Search Keywords	bosch,demolition hammers,chipping,rotary, sds max, demo hammers, demolition, demo, hammer, hammers, demolition hammer, carrying case, case
Marketing Copy	The Bosch DH1020VC SDS-max® demolition hammer features an in-line design, for excellent weight distribution while chiseling concrete in downward or horizontal applications. It is a 15.0 Amp tool that gets the job done, delivering a best-in-class 17.0 Ft.-Lbs. of impact energy and a Max of 1,700 BiM. Yet it weighs only 25.1 Lbs. for an outstanding power-to-weight ratio. This hammer provides Constant Response circuitry for constant power under load, as well as smooth starts and overload protection. The hammer's variable-speed dial allows the operator to match the hammering power to application – from 900 BiM to 1,700 BiM. For added user comfort, it features Vario-Lock positioning for rotating and locking the chisel with precision, a 360° rotating auxiliary handle and a padded rear handle. The SDS-max® chuck system provides tool-free bit changes.
Extended Marketing Copy	Bosch DH1020VC SDS-max® Demolition Hammer The Bosch DH1020VC SDS-max® Demolition Hammer features an in-line design, which is ideal for handling downward or vertical chiseling jobs. This hard-hitting hammer delivers a best-in-class 17.0 ft.-lbs. of impact energy for superior concrete removal. The hammer provides maximum chipping and chiseling muscle in a 15.0-AMP tool that weighs only 25.1 lbs. for professional power and terrific performance-to-weight ratio. The DH1020VC provides Constant Response™ circuitry for constant load under pressure as well as smooth starts. And it has a Vario-Lock™ positioning feature, which allows the user to rotate the chisel for maximum working angles. Lighter Tool, Heavier Hammering The hammer includes an in-line design, which allows for excellent weight distribution while chiseling concrete or handling light-duty demolition in horizontal applications. Its shape makes it the ideal solution for handling downward or vertical chiseling jobs. It has a 15.0-AMP rating, and it delivers a best-in-class 17.0 ft.-lbs. of impact energy and 1,700 BPM for maximum concrete removal. This performance comes in a tool that is only 25.1 lbs., for an outstanding power-to-weight ratio. Max User Comfort The Bosch DH1020VC SDS-max® Demolition Hammer allows users to operate more efficiently with less user fatigue, using Bosch's Vibration Control™ systems. This technology reduces shock in the hammer mechanism with an elongated air cushion. It also has a shock-absorbing and padded rear grip area. Its 360° articulating auxiliary handle provides a wide range of movement for greater operator control. Smooth, Constant Power This hammer produces reliable performance with Constant Response™ circuitry, even when the chiseling is its toughest. Along with constant speed under load, the tool provides soft-start operation, overload protection and steady control – important for extended periods of work. It includes a Service Minder™ light to indicate when preventative maintenance is required. Best Chiseling Angle The Bosch DH1020VC features Vario-Lock™ positioning, so the operator can position then lock the chisel into one of 12 different positions to optimize the work angle. The variable-speed dial provides a lower chipping adjustment, which allows the user to match the hammering speed to the application – from 900 BPM to 1,700 BPM. The industry-standard SDS-max® chuck provides tool-free bit changes, with automatic bit locking and maximum impact-energy transfer rate. What's in the Box The Bosch DH1020VC includes an auxiliary handle and a carrying case. Includes (1) Demolition Hammer, (1) Auxiliary Handle, (1) Carrying Case Features Include In-line design – better weight distribution for concrete chiseling and light-duty demolition in horizontal applications Best-in-class impact energy – 17 ft.-lbs. provides maximum concrete removal for productivity Power-to-weight ratio – 15.0-AMP demo hammer delivers 1,700 BPM at 25.1 lbs. Vibration Control™ technology – reduces vibration in hammer mechanism and at handle for improved comfort in all-day demolition applications Constant Response™ circuitry – reliable operation with constant speed under load, soft-start control and overload protection Vario-Lock™ positioning – locks chisel in one of 12 positions for optimized work angle 360° auxiliary handle – operator comfort due to a wide range of positioning Variable-speed dial – accurate bit starting and controlled chiseling SDS-max® bit system – ease of use with tool-free bit changes with automatic bit locking and maximum impact-energy transfer rate Service Minder™ light – indicates when preventative maintenance is required Padded rear handle – for additional comfort
Feature - Benefit Bullet 1	In-line design – better weight distribution for concrete chiseling and light-duty demolition in horizontal applications
Feature - Benefit Bullet 2	Best-in-class impact energy – 17 Ft.-Lbs. provides maximum concrete removal for productivity
Feature - Benefit Bullet 3	Power-to-weight ratio – 15.0 Amp demo hammer delivers 1,700 BPM at 25.1 Lbs. weight
Feature - Benefit Bullet 4	Vibration Control technology – reduces vibration in hammer mechanism and at handle for improved comfort in all-day demolition applications
Feature - Benefit Bullet 5	Constant Response circuitry – reliable operation with constant speed under load, soft-start control and overload protection
Feature - Benefit Bullet 6	Vario-Lock positioning – locks chisel in one of 12 positions for optimized work angle
Global Trade Item Number (GTIN)	00000346426564
California Prop 65 Warning Required?	No
FAQs	Q: What is the primary use for the 15 Amp SDS-max® Demolition Hammer? A: 15 Amp SDS-max® Demolition Hammer Bosch DH1020VC SDS-max® Demolition Hammer The Bosch DH1020VC SDS-max® Demolition Hammer features an in-line design, which is ideal for handling downward or vertical c...
Average Rating	5
Reviews	Very very nice product, happy to get this product. Will buy again
UPC code NA	000346426564
Spec 1	Amperage: 15
Spec 2	Blasts Per Minute - Maximum (BPM): 1700
Spec 3	Chuck Design: Keyless
Spec 5	Powered Tool Power Source: Electric - Corded
Spec 6	Impact Energy/EPTA (ft. lbs.): 17.0 ft./ lbs. EPTA
Spec 7	No Load BPM: 850-1,800
Spec 8	Thin Wall Core Bit Capacity: No
Spec 9	Side Handle: Yes
Spec 10	Cord Length (ft.): 8 ft
