AK7100BS290-BF
Head On IsoDownload

Range Hood

AK7100BS290-BF

Gust Under-Cabinet

  • A discreet, European-style, professional-looking range hood, Gust adds fashion to under-cabinet installations. With its mechanical controls neatly tucked away below the canopy, Gust provides the subtlety its owners require. Its perfectly curved corners and understated top-mounted return-air louver offer further evidence that Gust spares nothing when it comes to quality construction. Available with LumiLight LED lighting and optional recirculating kit.
Size
Color/Finish
  • Product StatusActive
    BrandZephyr
    Model #AK7100BS290-BF
    MSRP ($)$849
    Short DescriptionGust, UC, 30in, SS, Baffles, LED, 290
    CollectionCore Collection
    UPC646328008764
    CategoryRange Hood
    Installation TypeUnder Cabinet
    For Outdoor UseNo
    Controls TypeMechanical Slide
    Lighting TypeLED
    Lights Quantity2
    Maximum Amperage1.55
    ColorStainless Steel
    Lights Levels2
    Compatible ModelsZRC-0071, MUA006A, AK00067, Z0F-C005, AK1710
    Country of OriginTaiwan
    CEC Title 20 CompliantYes
    CEC Title 24 CompliantYes
    ADA CompliantYes, with optional wall switch
    Wi-Fi ConnectedNo
    Bluetooth ConnectedNo
    Automatic Delay-OffNo
  • Blower Speeds3
    Blower IncludedYes
    Clean Air FunctionNo
    Compatible Mesh or Baffle Filter Part NumberZ0F-B002
    Duct DischargeVertical or Horizontal
    Duct Size; Horizontal; IN3.25 x 10
    Duct Size; Vertical; IN7, 3.25 x 10
    Duct Type
    • Vertical
    • Horizontal
    Mounting Height Above Cooktop; IN24 - 32
    Remote IncludedNo
    Remote OptionalNo
    Vent TypeConvertible
  • Lighting TypeLED
  • Duct DischargeVertical or Horizontal
    Duct Size; Horizontal; IN3.25 x 10
    Duct Size; Vertical; IN7, 3.25 x 10
  • Net Height; IN7.375
    Net Width; IN29.9
    Nominal Width; IN30
    Net Depth; IN21
    Weight; LBS32.500
    Ceiling Height Maximum12 ft.
    Ceiling Height Minimum8 ft.
  • Feature 1Welded and polished body
    Feature 1 DefinitionA welded and polished body ensures a high quality, seamless appearance.
    Feature 2LumiLight LED Lighting
    Feature 2 DefinitionLumiLight LED lights are eco-friendly and built to last with a lifetime of more than 25,000 hours.
    Feature 3Mechanical Slide Controls
    Feature 3 Definition3-speed mechanical slide controls move along a track to adjust the range hood blower and dual-level LED lighting.
    Feature 4Dual-Level Lighting
    Feature 4 DefinitionThe dual-level dimmable LEDs require less energy than traditional halogen lights, are cool to the touch, and provide uniform light distribution.
    Feature 5Baffle filters
    Feature 5 DefinitionHigh-quality filters that are dishwasher safe and ensure a lifetime of exceptional performance.
    Feature 6Vertical or horizontal ducting
    Feature 6 DefinitionThis hood has the ability to vent either out the top or out the back.
    Feature 7Optional Ductless Recirculating Kit
    Feature 7 DefinitionDuctless recirculating kit used when venting air outside your home is not possible. Smoke and odors pass through charcoal filters allowing purified air to be reintroduced into the kitchen.
    Energy Star CertifiedNo
  • Blower IncludedYes
    Internal Blower 1 CFM290
    Internal Blower 1 Min. Sones1.1
    Internal Blower 1 Max Sones3.2
  • Warranty Parts / Labor3 / 1
  • Shipping Height; IN11
    Shipping Length; IN33
    Shipping Width; IN25
    Shipping Weight; LBS39
  • Optional Accessory 1ZRC-0071
    Optional Accessory 2MUA006A
    Optional Accessory 3AK00067
    Optional Accessory 4Z0F-C005
    Optional Accessory 5AK1710
