Head On Iso
Range Hood
AK8400BS290
Tornado Mini Insert
- The Tornado Mini power pack was designed with cost efficiency and versatility in mind. Tornado Mini’s small footprint fits under the standard 12” cabinet depth — or choose one of our optional, adjustable-depth, stainless steel liners to accommodate custom hood enclosures from 17-1/2” to 20-1/2” deep. Features include dual-level LumiLight LED lights, an ultra-quiet blower, and a recirculating option for ductless installations.
Product Status Discontinued Brand Zephyr Model # AK8400BS290 MSRP ($) $369 Short Description Tornado Mini, Insert, 21", SS, 290 CFM Collection Core Collection UPC 646328009525 Category Range Hood Installation Type Insert For Outdoor Use No Controls Type Mechanical Slide Lighting Type LED Lights Quantity 2 Voltage 120 Maximum Amperage 2 Color Stainless Steel Blower Speeds 3 Watts Per Bulb 6 Lights Levels 2 Mounting Height Above Cooktop; IN 20 - 36 Compatible Models AK0840AS, AK0846AS, ZRC-8400A, Z0F-C084 Country of Origin Taiwan Grease Filter Type Mesh Compatible Mesh or Baffle Filter Part Number 50200054 CEC Title 20 Compliant Yes CEC Title 24 Compliant Yes ADA Compliant No Duct Discharge Vertical Duct Size; Vertical; IN 6 Net Height; IN 9.687 Net Width; IN 20.562 Nominal Width; IN 21 Net Depth; IN 11 Weight; LBS 14 Cutout Depth in. 10.25 Cutout Width in. 19.75 Feature 1 Mechanical Slide Controls Feature 1 Definition 3-speed mechanical slide controls move along a track to adjust the range hood blower and dual-level LED lighting. Feature 2 3 Speed Levels Feature 2 Definition Quiet and efficient, three speed levels allow you to control proper airflow depending on your cooking needs. Feature 3 LumiLight LED Lighting Feature 3 Definition LumiLight LED lights are eco-friendly and built to last with a lifetime of more than 25,000 hours. Feature 4 Dual-Level Lighting Feature 4 Definition The dual-level dimmable LEDs require less energy than traditional halogen lights, are cool to the touch, and provide uniform light distribution. Feature 5 Dishwasher Safe Aluminum Mesh Filters Feature 5 Definition High-quality, dishwasher-safe aluminum mesh filters for improved capture and performance. Feature 6 Optional Ductless Recirculating Kit Feature 6 Definition Ductless recirculating kit used when venting air outside your home is not possible. Smoke and odors pass through charcoal filters allowing purified air to be reintroduced into the kitchen. Feature 7 Optional Adjustable Depth Liner Feature 7 Definition An optional adjustable-depth, stainless steel liner is available to protect your cabinetry and provide a more finished appearance. Energy Star Certified No Blower Included Yes Internal Blower 1 CFM 290 Internal Blower 1 Min. Sones 1.3 Internal Blower 1 Max Sones 3.2 Warranty Parts / Labor 3 / 1 Shipping Height; IN 14.5 Shipping Length; IN 24.9 Shipping Width; IN 13 Shipping Weight; LBS 16.8 Optional Accessory 1 AK0840AS Optional Accessory 2 AK0846AS Optional Accessory 3 ZRC-8400A Optional Accessory 4 Z0F-C084
