AK9440BS
Head On IsoDownload

Range Hood

AK9440BS

Monsoon Connect Insert

  • Monsoon Connect is unique in the marketplace. Optional dual 1300-CFM PowerWave™ blowers and stainless steel baffle filters make for a powerful, performance-driven range hood insert that is easy to clean. With a wireless remote-control option and Zephyr Connect, our most advanced operation system makes the Monsoon Connect the most quiet and energy efficient, one-piece liner available today. Dual blowers available on the 36”, 42″ and 48″ models.
Size
Color/Finish
  • Product StatusActive
    BrandZephyr
    Model #AK9440BS
    MSRP ($)$1899
    Short DescriptionMonsoon Connect, 42in, SS, LED, ACT
    CollectionCore Collection
    UPC646328008375
    CategoryRange Hood
    Installation TypeInsert
    For Outdoor UseNo
    Controls TypeProximity Touch
    Lighting TypeLED
    Lights Quantity2
    Maximum Amperage5
    ColorStainless Steel
    Lights Levels3
    Compatible Models14000005, PBD-1300B, MUA008A, MUA010A
    Country of OriginTaiwan
    CEC Title 20 CompliantYes
    CEC Title 24 CompliantYes
    ADA CompliantYes, with optional remote
    Wi-Fi ConnectedYes
    Bluetooth ConnectedNo
    Automatic Delay-OffYes
  • Blower Speeds6
    Blower IncludedYes
    Clean Air FunctionYes
    Compatible Mesh or Baffle Filter Part Number50210039
    Duct DischargeVertical or Horizontal
    Duct Size; Horizontal; IN8
    Duct Size; Vertical; IN8
    Duct Type
    • Vertical
    • Horizontal
    Mounting Height Above Cooktop; IN24 - 36
    Remote IncludedNo
    Remote OptionalYes
    Vent TypeDucted
  • Lighting TypeLED
  • Duct DischargeVertical or Horizontal
    Duct Size; Horizontal; IN8
    Duct Size; Vertical; IN8
  • Net Height; IN12
    Net Width; IN40.375
    Nominal Width; IN42
    Net Depth; IN19.25
    Weight; LBS55.000
    Cutout Depth in.19.625
    Cutout Width in.40.625
    Ceiling Height Maximum12 ft.
    Ceiling Height Minimum8 ft.
  • Feature 1Compatible with Zephyr Connect App
    Feature 1 DefinitionThe Zephyr Connect app allows customers to remotely control their range hoods from anywhere using a mobile device.
    Feature 2LumiLight LED Lighting
    Feature 2 DefinitionLumiLight LED lights are eco-friendly and built to last with a lifetime of more than 25,000 hours.
    Feature 3Airflow Control Technology™ (ACT™)
    Feature 3 DefinitionAirflow Control Technology or ACT is an exclusive technology that gives installers the ability to set the maximum CFM levels to meet local code requirements.
    Feature 4CleanAir Function
    Feature 4 DefinitionThe CleanAir Function powers the hood on every four hours for 10 minutes to refresh the cooking area.
    Feature 5Professional Baffle Filters
    Feature 5 DefinitionHigh-airflow baffle filters that are dishwasher safe and ensure a lifetime of exceptional performance.
    Feature 6Vertical or horizontal ducting
    Feature 6 DefinitionThis hood has the ability to vent either out the top or out the back.
    Feature 7Optional Wireless Remote Control (14000005)
    Feature 7 DefinitionADA-compliant, wireless RF remote control with battery and holder. Equipped with a magnet on the back for easy storage on any magnetic surface. Maximum remote control communication distance is 15 feet from the hood. Please check your Zephyr range hoods specification sheet to ensure compatibility.
    Energy Star CertifiedNo
  • Blower IncludedYes
    Blower CFM w/ACT590, 390, 290
    Internal Blower 1 CFM700
    Internal Blower 1 Min. Sones0.8
    Internal Blower 1 Max Sones6
    Internal Blower 2 CFM1300
  • Warranty Parts / Labor3 / 1
  • Shipping Height; IN24.6
    Shipping Length; IN43.3
    Shipping Width; IN16.7
    Shipping Weight; LBS57.6
  • Optional Accessory 114000005
    Optional Accessory 2PBD-1300B
    Optional Accessory 3MUA008A
    Optional Accessory 4MUA010A
