ALL-M90BBX
Head On IsoDownload

Range Hood

ALL-M90BBX

Layers Island

  • A bold take on the classic island range hood is a streamlined fusion of black or white glass and stainless steel. A slim profile enhances the floating effect to lend new meaning to “leading edge.” Optional duct cover extension available to accommodate contemporary loft-style kitchens with ceilings of up to 12 feet.
Size
Color/Finish
  • Product StatusDiscontinued
    BrandZephyr
    Model #ALL-M90BBX
    MSRP ($)$2699
    Short DescriptionLayers, Island, 90cm, SS/Blk Glass, LED, BODY ONLY
    CollectionDesigner Collection
    UPC646328004308
    CategoryRange Hood
    Installation TypeIsland
    For Outdoor UseNo
    Controls TypeCapacitive Touch
    Lighting TypeLED
    Lights Quantity2
    Maximum Amperage6.5
    ColorStainless Steel + Black
    Lights Levels3
    Compatible ModelsZRC-01LL, Z1C-02LL, MUA006A, MUA008A, Z0F-01AC
    Country of OriginItaly
    CEC Title 20 CompliantYes
    ADA CompliantYes
    Wi-Fi ConnectedNo
    Bluetooth ConnectedNo
    Automatic Delay-OffYes
  • Required Accessory: Blower 1CBI-290A
    Required Accessory: Blower 2CBI-600A
    Required Accessory: Blower 3CBE-1000
    Required Accessory: Blower 4PBN-1000A
  • Blower Speeds3
    Blower IncludedNo
    Clean Air FunctionYes
    Compatible Mesh or Baffle Filter Part Number50200033
    Duct DischargeVertical
    Duct Size; Horizontal; INN/A
    Duct Size; Vertical; IN6, 8
    Duct TypeVertical
    Mounting Height Above Cooktop; IN24 - 36
    Remote IncludedYes
    Remote OptionalNo
    Vent TypeConvertible
  • Lighting TypeLED
  • Duct DischargeVertical
    Duct Size; Horizontal; INN/A
    Duct Size; Vertical; IN6, 8
  • Net Height; IN30 - 50
    Net Width; IN35.375
    Nominal Width; IN36
    Net Depth; IN26
    Weight; LBS117
    Ceiling Height Maximum10 ft.
    Ceiling Height Minimum8 ft.
  • Feature 1Includes Wireless Remote Control
    Feature 1 DefinitionOur wireless remote control places the hoods operations at your fingertips from anywhere in the kitchen.
    Feature 2Low-profile body
    Feature 2 DefinitionLow-profile body for a minimalist appearance.
    Feature 3Capacitive touch controls
    Feature 4CleanAir Function
    Feature 4 DefinitionThe CleanAir Function powers the hood on every four hours for 10 minutes to refresh the cooking area.
    Feature 5Optional Ductless Recirculating Kit
    Feature 5 DefinitionDuctless recirculating kit used when venting air outside your home is not possible. Smoke and odors pass through charcoal filters allowing purified air to be reintroduced into the kitchen.
    Feature 6Optional extension duct cover kit
    Energy Star CertifiedNo
  • Blower IncludedNo
    Internal Blower 1 CFM290
    Internal Blower 1 Min. Sones1.4
    Internal Blower 1 Max Sones3
    Internal Blower 2 CFM600
    Internal Blower 2 Max Sones6
    In-Line Blower CFM1000
    External Blower CFM1000
  • Warranty Parts / Labor1 / 1
  • Shipping Height; IN31.5
    Shipping Length; IN20.87
    Shipping Width; IN40.55
    Shipping Weight; LBS123.5
  • Optional Accessory 1ZRC-01LL
    Optional Accessory 2Z1C-02LL
    Optional Accessory 3MUA006A
    Optional Accessory 4MUA008A
    Optional Accessory 5Z0F-01AC
