ASL-E48ASX
Head On IsoDownload

Range Hood

ASL-E48ASX

Surface Island

  • Smoke-gray glass lends dramatic yet minimalist flair to the contemporary stainless steel kitchen. No curves here – just clean, straight lines. Four halogen lights and a remote control put this island range hood’s reflective play of power and light right in your hands.
Size
Color/Finish
  • Product StatusDiscontinued
    BrandZephyr
    Model #ASL-E48ASX
    Short DescriptionSurface, Island, 48in, 290 CFM, SS+G, HALOGEN
    CollectionDesigner Collection
    UPC646328000225
    CategoryRange Hood
    Installation TypeIsland
    For Outdoor UseNo
    Controls TypeCapacitive Touch
    Lighting TypeHalogen
    Lights Quantity4
    Maximum Amperage6.5
    ColorStainless Steel + Glass
    Lights Levels3
    Compatible ModelsZRC-00SL, Z1C-00SL, MUA006A, MUA008A
    Country of OriginItaly
    CEC Title 20 CompliantYes
    ADA CompliantYes
    Wi-Fi ConnectedNo
    Bluetooth ConnectedNo
    Automatic Delay-OffYes
  • Required Accessory: Blower 1CBI-290A
    Required Accessory: Blower 2CBI-600A
    Required Accessory: Blower 3CBE-1000
    Required Accessory: Blower 4PBN-1000A
  • Blower Speeds3
    Blower IncludedNo
    Clean Air FunctionYes
    Compatible Mesh or Baffle Filter Part Number50200035
    Duct DischargeVertical
    Duct Size; Horizontal; INN/A
    Duct Size; Vertical; IN6, 8
    Duct TypeVertical
    Mounting Height Above Cooktop; IN24 - 36
    Remote IncludedYes
    Remote OptionalNo
    Vent TypeConvertible
  • Lighting TypeHalogen
  • Duct DischargeVertical
    Duct Size; Horizontal; INN/A
    Duct Size; Vertical; IN6, 8
  • Net Height; IN31 - 48
    Net Width; IN48
    Nominal Width; IN48
    Net Depth; IN27
    Weight; LBS91.5
    Ceiling Height Maximum10 ft.
    Ceiling Height Minimum8 ft.
  • Feature 1Includes Wireless Remote Control
    Feature 1 DefinitionOur wireless remote control places the hoods operations at your fingertips from anywhere in the kitchen.
    Feature 2Capacitive touch controls
    Feature 3CleanAir Function
    Feature 3 DefinitionThe CleanAir Function powers the hood on every four hours for 10 minutes to refresh the cooking area.
    Feature 4Multiple blower options
    Feature 5Optional Ductless Recirculating Kit
    Feature 5 DefinitionDuctless recirculating kit used when venting air outside your home is not possible. Smoke and odors pass through charcoal filters allowing purified air to be reintroduced into the kitchen.
    Energy Star CertifiedNo
  • Blower IncludedNo
    Internal Blower 1 CFM290
    Internal Blower 1 Min. Sones1.4
    Internal Blower 1 Max Sones3
    Internal Blower 2 CFM600
    Internal Blower 2 Max Sones6
    In-Line Blower CFM1000
    External Blower CFM1000
  • Warranty Parts / Labor1 / 1
  • Shipping Height; IN32.7
    Shipping Length; IN33.7
    Shipping Width; IN53
    Shipping Weight; LBS126.8
  • Optional Accessory 1ZRC-00SL
    Optional Accessory 2Z1C-00SL
    Optional Accessory 3MUA006A
    Optional Accessory 4MUA008A
