ZAN-M90CBS
Head On IsoDownload

Range Hood

ZAN-M90CBS

Anzio Wall

  • Anzio, a low-profile, chimney-style range hood that will add style and value to any kitchen. Available in stainless steel and Titanium-coated, black-stainless-steel finishes for improved durability and easy cleaning. Complete with a 600 CFM blower, ICON Touch® controls, BriteStrip™ LED lighting and our exclusive Airflow Control Technology™ (ACT™). Now available in a 24” width.
Size
Color/Finish
  • Product StatusDiscontinued
    BrandZephyr
    Replacement ModelZAN-M90DBS
    Model #ZAN-M90CBS
    MSRP ($)$1599
    Short DescriptionAnzio, Wall, 90cm, Blk SS, 600 CFM, ACT, LED
    CollectionCore Collection
    UPC646328005312
    CategoryRange Hood
    Installation TypeWall
    For Outdoor UseNo
    Controls TypeElectronic LCD
    Lighting TypeLED
    Lights Quantity1
    Maximum Amperage5
    ColorBlack Stainless Steel
    Lights Levels2
    Compatible ModelsZRC-01AN, Z1C-00ANBS, Z0F-B002, MUA006A, Z0F-C091
    Country of OriginTaiwan
    CEC Title 20 CompliantYes
    ADA CompliantNo
    Wi-Fi ConnectedNo
    Bluetooth ConnectedNo
    Automatic Delay-OffYes
  • ZAN-M90DBS
  • Blower Speeds5
    Blower IncludedYes
    Clean Air FunctionNo
    Compatible Mesh or Baffle Filter Part NumberZ0F-B002
    Duct DischargeVertical
    Duct Size; Horizontal; INN/A
    Duct Size; Vertical; IN6
    Duct TypeVertical
    Mounting Height Above Cooktop; IN26 - 34
    Remote IncludedNo
    Remote OptionalNo
    Vent TypeConvertible
  • Lighting TypeLED
  • Duct DischargeVertical
    Duct Size; Horizontal; INN/A
    Duct Size; Vertical; IN6
  • Net Height; IN27 - 48.5
    Net Width; IN35.4375
    Nominal Width; IN36
    Net Depth; IN22.0625
    Weight; LBS38.1
    Ceiling Height Maximum9.5 ft.
    Ceiling Height Minimum8 ft.
  • Feature 1Airflow Control Technology™ (ACT™)
    Feature 1 DefinitionAirflow Control Technology or ACT is an exclusive technology that gives installers the ability to set the maximum CFM levels to meet local code requirements.
    Feature 2ICON Touch® Controls
    Feature 2 DefinitionICON Touch Controls seamlessly integrate into the hoods stainless steel canopy, which lets users control functions such as the 5 speeds, delay-off, dual-level lighting, and auto reminders. With its blue LED indicator lights and sleek modern aesthetic, the ICON Touch Controls are the future of ventilation control technology.
    Feature 3Low-profile body
    Feature 3 DefinitionLow-profile body for a minimalist appearance.
    Feature 4BriteStrip™ LED Lighting
    Feature 4 DefinitionThe future just got brighter. BriteStrip LED lighting includes key features such as being dimmable, lasts 25,000 hours, has a 3,000K warm white color and evenly distributes light over your cooking surface.
    Feature 5Dual-Level Lighting
    Feature 5 DefinitionThe dual-level dimmable LEDs require less energy than traditional halogen lights, are cool to the touch, and provide uniform light distribution.
    Feature 6Optional Ductless Recirculating Kit
    Feature 6 DefinitionDuctless recirculating kit used when venting air outside your home is not possible. Smoke and odors pass through charcoal filters allowing purified air to be reintroduced into the kitchen.
    Feature 7Optional Extension Duct Cover Kit
    Feature 7 DefinitionExtension duct cover kit to accommodate ceiling heights up to 12 ft see spec sheets for more details.
    Energy Star CertifiedNo
  • Blower IncludedYes
    Blower CFM w/ACT390, 290
    Internal Blower 1 CFM600
    Internal Blower 1 Min. Sones1
    Internal Blower 1 Max Sones6
  • Warranty Parts / Labor3 / 1
  • Shipping Height; IN27.36
    Shipping Length; IN39.49
    Shipping Width; IN23.62
    Shipping Weight; LBS55.8
  • Optional Accessory 1ZRC-01AN
    Optional Accessory 2Z1C-00ANBS
    Optional Accessory 3Z0F-B002
    Optional Accessory 4MUA006A
    Optional Accessory 5Z0F-C091
