ZSI-E30AS-ES
Head On IsoDownload

Range Hood

ZSI-E30AS-ES

Siena Wall ENERGY STAR®

  • The Siena ES, certified ENERGY STAR® hood is packed with power. With a 400-CFM blower and ACT™ technology this hood has a versatile range of features perfect for any kitchen. With energy-efficient, warm white fluorescent lights, an extension duct cover option and Zephyr’s new ICON Touch® controls, clearing the air is as simple as the touch of a button.
Size
Color/Finish
  • Product StatusDiscontinued
    BrandZephyr
    Replacement ModelZSI-E30BS-ES
    Model #ZSI-E30AS-ES
    MSRP ($)$1099
    Short DescriptionSiena ENERGY STAR, Wall, 30", SS, 400 CFM, ACT, Hybrid Baffles
    CollectionCore Collection
    UPC646328003592
    CategoryRange Hood
    Installation TypeWall
    For Outdoor UseNo
    Controls TypeICON Touch®
    Lighting TypeFluorescent
    Lights Quantity2
    Voltage120
    Maximum Amperage1.2
    ColorStainless Steel
    Blower Speeds3
    Watts Per Bulb13
    Lights Levels1
    Mounting Height Above Cooktop; IN26 - 34
    Compatible ModelsZ1C-00SI, MUA006A, AK1710
    Country of OriginTaiwan
    Grease Filter TypeHybrid Baffle
    Compatible Mesh or Baffle Filter Part Number50200050
    CEC Title 20 CompliantYes
    ADA CompliantNo
  • ZSI-E30BS-ES
  • Duct DischargeVertical
    Duct Size; Horizontal; INN/A
    Duct Size; Vertical; IN8
  • Net Height; IN27.5 - 42
    Net Width; IN29.9375
    Nominal Width; IN30
    Net Depth; IN21.9375
    Weight; LBS38.4
  • Feature 1ENERGY STAR® Certified
    Feature 1 DefinitionENERGY STAR models are certified for superior efficiency using 20%-30% less energy than traditional models.
    Feature 2Airflow Control Technology™ (ACT™)
    Feature 2 DefinitionAirflow Control Technology or ACT is an exclusive technology that gives installers the ability to set the maximum CFM levels to meet local code requirements.
    Feature 3ICON Touch® Controls
    Feature 3 DefinitionICON Touch Controls seamlessly integrate into the hoods stainless steel canopy, which lets users control functions such as the 5 speeds, delay-off, dual-level lighting, and auto reminders. With its blue LED indicator lights and sleek modern aesthetic, the ICON Touch Controls are the future of ventilation control technology.
    Feature 4Hybrid baffle filters
    Feature 53 Year Parts, 1 Year Labor Warranty
    Feature 5 DefinitionWith service at the forefront, we back our products with a generous 1-year labor and 3-year parts warranty.
    Feature 6Fluorescent Lighting
    Feature 7Optional Extension Duct Cover Kit
    Feature 7 DefinitionExtension duct cover kit to accommodate ceiling heights up to 12 ft see spec sheets for more details.
    Energy Star CertifiedYes
  • Blower IncludedYes
    Blower CFM w/ACT290
    Internal Blower 1 CFM400
    Internal Blower 1 Min. Sones1.4
    Internal Blower 1 Max Sones6
  • Warranty Parts / Labor3 / 1
  • Shipping Height; IN29.13
    Shipping Length; IN35.75
    Shipping Width; IN18.31
    Shipping Weight; LBS50.7
  • Optional Accessory 1Z1C-00SI
    Optional Accessory 2MUA006A
    Optional Accessory 3AK1710
