Head On Iso
Range Hood
ZSL-E42BS
Siena Pro Island
- With its classic, professional-style design, Siena Pro manages to encompass a wealth of features perfect for the culinary pro or any aspiring home chef. Equipped with a 1200-CFM blower, Zephyr’s ICON Touch® controls, the new LumiLight LED lighting, and our exclusive Airflow Control Technology (ACT™). Clean, efficient power is just a touch away.
Product Status Discontinued Brand Zephyr Replacement Model ZSL-E42CS Model # ZSL-E42BS MSRP ($) $2749 Short Description Siena Pro Island, 42", SS, 1200 CFM, Hybrid Baffles, LED Collection Core Collection UPC 646328005817 Category Range Hood Installation Type Island For Outdoor Use No Controls Type ICON Touch® Lighting Type LED Lights Quantity 2 Maximum Amperage 9 Color Stainless Steel Lights Levels 2 Compatible Models Z1C-00SL, MUA010A Country of Origin Taiwan CEC Title 20 Compliant Yes ADA Compliant No Wi-Fi Connected No Bluetooth Connected No Automatic Delay-Off Yes Replacement Model ZSL-E42DS Blower Speeds 5 Blower Included Yes Clean Air Function No Duct Discharge Vertical Duct Size; Horizontal; IN N/A Duct Size; Vertical; IN 10 Duct Type Vertical Mounting Height Above Cooktop; IN 26 - 34 Remote Included No Remote Optional No Vent Type Ducted Lighting Type LED Duct Discharge Vertical Duct Size; Horizontal; IN N/A Duct Size; Vertical; IN 10 Net Height; IN 32.5 - 48.5 Net Width; IN 41.875 Nominal Width; IN 42 Net Depth; IN 28 Weight; LBS 92.3 Ceiling Height Maximum 9 ft. Ceiling Height Minimum 8 ft. Feature 1 ICON Touch® Controls Feature 1 Definition ICON Touch Controls seamlessly integrate into the hoods stainless steel canopy, which lets users control functions such as the 5 speeds, delay-off, dual-level lighting, and auto reminders. With its blue LED indicator lights and sleek modern aesthetic, the ICON Touch Controls are the future of ventilation control technology. Feature 2 BriteStrip™ LED Lighting Feature 2 Definition The future just got brighter. BriteStrip LED lighting includes key features such as being dimmable, lasts 25,000 hours, has a 3,000K warm white color and evenly distributes light over your cooking surface. Feature 3 Quick-Lock Installation System Feature 3 Definition Zephyrs Quick-Lock Installation System is an innovative, hassle-free method for installing island range hoods. A quick-lock motion lets the user assemble the frame, lift the hood and lock it into place on the frame and then assemble the 4-piece duct covers. This easy three-step process ensures the island hood is securely installed without additional build-out required. While most island range hood installations require at least three people, Zephyrs Quick-Lock Installation can be completed by one or two people. Feature 4 Hybrid baffle filters Feature 5 Dual-Level Lighting Feature 5 Definition The dual-level dimmable LEDs require less energy than traditional halogen lights, are cool to the touch, and provide uniform light distribution. Feature 6 Optional Extension Duct Cover Kit Feature 6 Definition Extension duct cover kit to accommodate ceiling heights up to 12 ft see spec sheets for more details. Feature 7 Optional Make-Up Air Kit Feature 7 Definition A make-up air kit is a system installed to introduce fresh, outside air to compensate for the air removed by the range hood. This helps maintain balanced indoor air pressure and ensures the efficient operation of the range hood. Check your local codes for more information. Energy Star Certified No Blower Included Yes Blower CFM w/ACT 590, 390 Internal Blower 1 CFM 1200 Internal Blower 1 Min. Sones 3.5 Internal Blower 1 Max Sones 9 Warranty Parts / Labor 3 / 1 Shipping Height; IN 32.4 Shipping Length; IN 46.26 Shipping Width; IN 32.28 Shipping Weight; LBS 126.5 Optional Accessory 1 Z1C-00SL Optional Accessory 2 MUA010A
