9" Bench Top Cold Saw
Main ImageDownload

9" Bench Top Cold Saw

9683150

    • Product ID9683150
      Product Name9" Bench Top Cold Saw
      UPC726896831503
      Product CopyPalmgren’s smallest cold saw is a lightweight bench model that can be easily moved to various workstations to complete cutting operations throughout the shop or on job sites. With its durable cast iron construction, this cold saw can cut small solids, tubing and structural shapes fast, with a smooth, mill-like finish.
      Product FeaturesMiter cuts from 0° to 45° to the left. Bronze worm gear and hardened ground worm screw gear box in an oil bath. Control handle with safety spring loaded trigger switch to start or stop the machine. Equipped with variable speed inverter delivering a broader range of speeds. Fully enclosed blade guard. Coolant system. Manual vise. Adjustable work stop
      CategoryMachine-Saw-Cold
      Country of OriginTaiwan
      Stock UOMEach
    • Product Height (inches)15.2
      Product Length (inches)18.7
      Product Width (inches)16.5
      Product Weight (lbs)47.3
    • Machine dimensions XYZ17-3/4" x 13-1/4" x 17-3/4"
      Machine Weight44 lbs.
    • Motor HP2
      Overall Dimensions (LxWxH)17-3/4" x 13-1/4" x 17-3/4"
      PhaseSingle
    • Round Material Max. 0º2-3/8"
      Round Material Max. 45º2-3/8"
    • Saw Blade Diameter9"
      Sawing TypeVertical Band Saws
      Square Max. 0º2-3/8" x 2-3/8"
      Square Max. 45º2-3/8" x 2-3/8"
    • Vise Opening2-3/4"
      Voltage115
      Warranty3 years
