10G2A1C25EPD-USB-HUB
3 Port USB 3 2 Gen 2 USB C Hub with 2 5G Ethernet 2 X USB A
Enable 2.5G ethernet, 100W PD pass-through, and add three USB 3.2 10Gbps ports, using this portable adapter
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
Quick-Start Guide
Video Link YouTube
Product Name 3 Port USB 3 2 Gen 2 USB C Hub with 2 5G Ethernet 2 X USB A Product Number 10G2A1C25EPD-USB-HUB UPC 065030900676 Lifecycle status Active Warranty 2 Years Weighted Opportunity 41912 Taxonomy Product > Docks, Hubs & Video Adapters > USB Hubs Category Level 1 Hubs Category Level 2 USB-C Hubs Category Level 3 USB-C Multifunction Hubs - 10Gbps Family USB-C Multifunction Hubs - 10Gbps - with Ethernet Country of Origin Europe & Japan Vietnam Country of Origin North America Vietnam Country of Origin History (1) Vietnam Country of Origin Revision (1) XXXXXX190X Product Title (Ultra-Short) USB-C Hub, 2.5GbE/PD Product Title (Short) 3-Port USB-C Hub, 2.5GbE, PD Passthrough Product Title (Medium) 3-Port USB-C Hub, 2.5GbE, 100W PD Passthrough, USB 3.2 10Gbps, 2x USB-A/1x USB-C Product Title (Standard) 3-Port USB-C Hub with 2.5 Gb Ethernet and 100W PD Passthrough - USB-C to 2x USB-A/1x USB-C, USB 3.2 10Gbps Type-C Adapter Hub Product Title (Long) 3-Port USB-C Hub with 2.5 Gbps Ethernet and 100W Power Delivery Pass-Through Port, USB 3.2 10Gbps, 2x USB-A/1x USB-C, Portable USB Type-C Adapter Hub Product Title (AMZ) 3-Port USB-C Hub, 2.5 Gbps Ethernet, 100W PD Pass-Through Port, USB 3.2 10Gbps, 2x USB-A/1x USB-C, Portable Hub Title Ingram (Part 1) 3-Port USB-C Hub 2.5Gb Ethernet Title Ingram (Part 2) 100W Power Delivery Passthrough Website Product Headline Enable 2.5G ethernet, 100W PD pass-through, and add three USB 3.2 10Gbps ports, using this portable adapter Bullet 1 3-PORT USB-C HUB: Expand the connectivity of a USB-C computer by adding three USB 3.2 Gen 2 10Gbps Ports (2x USB-A, 1x USB-C), plus a USB-C Power Delivery Port; 2.5 Gigabit Ethernet RJ45 for wired LAN connectivity (Wake-on-LAN); Easy Driverless setup Bullet 2 2.5GBASE-T MULTI-GIGABIT ETHERNET: Features a 2.5Gb network controller that delivers speeds of 10/100/1000/2500Mbps; For laptops / devices without a USB-A or Ethernet, such as MacBook /iPad Air / Pro; USB-C connectivity while providing power for charging Bullet 3 RELIABLE PERFORMANCE: USB bus powered or via external USB-C power adapter; 100W Power Delivery 3.0 pass through with 15W reserved for the USB Hub to avoid device dropouts or overdrawing power that is common in other hubs, and up to 85W for laptop charging Bullet 4 EXTRA-LONG CABLE: Attached 1ft/30cm cable with TPE jacket provides long reach for easy setup and prevents adapter from dangling on the host connector; Ideal cable length to reduce port strain on 2-in-1 convertible laptops, or host laptops on riser stands Bullet 5 OUR ADVANTAGE: Included connectivity tools for IT Pros and IT help-desk support teams; USB Event Monitoring logs/timestamps USB port usage enabling admins to identify potentially malicious devices, MAC Address Cloning & WIFI Auto Switch Utilities Bullets (Compact) 3 Port USB-C hub w/2x USB-A/1x USB-C - USB 3.2 Gen 2 10Gbps - 2.5 GbE (WoL) - 100W PD 3.0 pass-through (15W reserved for hub) - 1ft USB-C host cable (TPE jacket) - Connectivity Tools software (USB Event Monitoring/MAC Address Cloner/WIFI Auto Switch) Bullets (Consolidated) - 3 Port USB-C hub (USB 3.2 Gen 2 10Gbps) with 2x USB-A and 1x USB-C - USB Type-C adapter hub with 2.5 Gigabit Ethernet RJ45 port (Jumbo 9K Frames/Wake-On-Lan and 10/100/1000/2500Mbps) - 100W Power Delivery (PD 3.0) pass-through for laptop charging with your USB-C power adapter (15W reserved for hub) - Compact housing - 1ft USB-C cable with TPE jacket - Connectivity Tools software with USB Event Monitoring/MAC Address Cloner/WIFI Auto Switch utilities Marketing Copy Marketing Copy (No HTML) Applications - Connect a USB Solid State Drive (SSD)
- Add wired internet connectivity to a laptop
- Ideal for traveling between home and office
Website Search Keyword - 2.5 gigabit ethernet port
- 3 port usb c hub
- 3 port usb hub
- 3 usb hub
- desk mount usb hub
- desk usb hub
- ethernet adapter
- ethernet network adapter
- ethernet to usb
- ethernet to usb adapter
- ethernet to usb hub
- ethernet usb
- ethernet usb adapter
- ethernet usb c hub
- ethernet usb hub
- network adapter
- port hub usb
- thunderbolt 3 compatible
- usb 2.5 gigabit ethernet adapter
- usb 2.5 gigabit network adapter
- usb 3.2 gen 2 hub
- usb 3.2 gen 2 type c hub
- usb 3.2 hub
- usb and ethernet hub
- usb c 2.5 gigabit
- usb c 2.5 gigabit ethernet adapter
- usb c adapter
- usb c charging hub
- usb c ethernet
- usb c ethernet adapter
- usb c ethernet hub
- usb c hub
- usb c hub 2.5 gigabit ethernet
- usb c hub adapter
- usb c hub ethernet
- usb c hub with ethernet
- usb c hub with power delivery
- usb c hub with rj45
- usb c multiport adapter
- usb c network adapter
- usb c port
- usb c port hub
- usb c to a
- usb c to a hub
- usb c to ethernet
- usb c to ethernet adapter
- usb c to ethernet hub
- usb c to usb
- usb c to usb a
- usb c to usb a hub
- usb c to usb adapter
- usb c to usb hub
- usb c with pd
- usb desk hub
- usb ethernet
- usb ethernet adapter
- usb ethernet hub
- usb ethernet network adapter
- usb hub
- usb hub 3 port
- usb hub adapter
- usb hub c
- usb hub desk mount
- usb hub ethernet
- usb hub for laptop
- usb hub laptop
- usb hub with 2.5 gigabit ethernet
- usb hub with cable
- usb hub with ethernet
- usb hub with ethernet adapter
- usb hub with ethernet port
- usb hub with rj45 port
- usb hub with type c
- usb network adapter
- usb port hub
- usb rj45 adapter
- usb rj45 network adapter
- usb to ethernet
- usb to ethernet adapter
- usb to ethernet adaptor
- usb to ethernet hub
- usb to ethernet network adapter
- usb to network adapter
- usb to rj45
- usb to rj45 adapter
- usb to usb
- usb type c hub
- usb type c to ethernet
- usb type c to type a
- usb type c to usb
- usb-c hub
Required Regulatory Compliance Marks - CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- TSCA - Environmental - United States - EPA TSCA Title VI Compliant
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + paper tray/divider
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Paper
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
Special Notes - Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure the host USB-C port supports USB Power Delivery.
- Power will not pass through to the adapter when connected to a host USB-C port that lacks USB PD functionality.
- USB 3.2 Gen 2 10Gbps is also known as USB 3.1 Gen 2 10Gbps
- - Jumbo Frames are no longer supported in macOS
System and Cable Requirements - A host laptop with an available USB-C port (to ensure full adapter functionality, the host USB-C port must support USB Power Delivery).
- Optional: USB-C power adapter (for example, your laptop's USB-C based power adapter).
Accessory Products - C6PATCH15BK
- N6PATCH10BK
- N6PATCH1BL
- N6PATCH10BL
- N6PATCH6BK
- N6PATCH6BL
- N6PATCH3BL
- N6PATCH4RD
- N6LPATCH7BK
- N6PATCH7BL
- N6LPATCH10BL
- N6PATCH7BK
- N6LPATCH7BL
- USB3S2SAT3CB
- SDOCK2U33
- SDOCK2U33V
- SDOCK4U33
- USB2PACUBK
- USB2PACBK
- USB2PACWH
- UUSBHAUB1
- UUSBHAUB3
- UUSBHAUB6
- UUSBHAUB10
Related Products - 5G3AGBB-USB-C-HUB
- HB30C3A1GEA2
- HB30C3A1GEA
- HB30C3AGEPD
- HB30C3A1GE
- HB31C2A1CGS
- HB31C2A1CGB
Power Delivery 100W Power Source Bus Powered Cable Length (mm) 304.7 Color Space Gray Humidity 10% to 85% RH Material Plastic Operating Temperature 0°C to 40°C (32°F to 104°F) Product Length (mm) 34.000 Product Width (mm) 163.000 Product Height (mm) 15.000 Product Weight (g) 68.000 Storage Temperature -10°C to 70°C (14°F to 158°F) TAA Compliant No Auto MDIX Yes Compatible Networks 2.5G/1G/100Mbps/10Mbps Device Power Consumption (In Watts) 15W Downstream Maximum Data Transfer Rate USB 3.2 Gen 2 (10Gbps) Full Duplex Support Yes General Specifications Maximum Laptop Charging: 85W Jumbo Frame Support 9K max. Maximum Data Transfer Rate 10Gbps (USB 3.2 Gen 2) MTBF (hours) 286,501.33 Hours OS Compatibility - Windows 11
- Windows 11 ARM
- Windows 10
- Windows 8.1
- Windows 7
- Windows Server 2022
- Windows Server 2019
- Windows Server 2016
- Windows Server 2012 R2
- Windows Server 2008 R2
- macOS Sequoia (15.0)
- macOS Sonoma (14.0)
- macOS Ventura (13.0)
- macOS Monterey (12.0)
- macOS Big Sur (11.0)
- macOS Catalina (10.15)
- macOS Mojave (10.14)
- macOS High Sierra (10.13)
- macOS Sierra (10.12)
- Mac OS X El Capitan (10.11)
- Linux
- macOS Tahoe (26.0)
PXE No Total Available Power Output (In Watts) Up to 100W Total USB Power Output 4.5W (5V/0.9A) UASP Support Yes USB Speed USB 3.2 Gen 2 (10Gbps) USB Type and Rate USB 10Gbps Wake-On-LAN (WOL) Yes Bus Type USB 3.2 Gen 2 10Gbps Chipset ID - VIA - VL103
- VIA - VL822
- Realtek - RTL8156B
Ethernet Port Yes Industry Standards - USB 3.2 Gen 2 - Backward compatible with USB 3.2 Gen 1, USB 2.0, and 1.1
- USB Power Delivery 3.0
- Wake on USB
- IEEE 802.3bz (2.5GBASE-T/NBASE-T)
Interface/Bridge USB 10Gbps Laptop Dock / USB Hub Fast-Charge No LED Indicators - 1 - Network Link LED - Green
- 1 - Network Activity LED - Amber
USB-C Device Port(s) Yes USB-C Host Connection Yes Carton Depth (mm) 330 Carton Height (mm) 310 Carton Quantity 60 Carton Weight Gross (g) 8700 Included in Package - 1 - USB-C Hub
- 1 - Quick-Start Guide
Included In Package for Label - 1 - Quick-Start Guide
- 1 - USB-C Hub
Package Depth (mm) 142 Package Height (mm) 33 Package Width (mm) 175 Package Weight (g) 128 Packaging Description 3-Port USB 3.2 Gen 2 (10Gbps) Hub with 2.5GbE - USB-C to 2x USB-A, 1x USB-C Packaging Description India 3-Port USB 3.2 Gen 2 (10Gbps) Hub with 2.5GbE - USB-C to 2x USB-A, 1x USB-C Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-A (10Gbps, 4.5W) Connector 1 (Quantity) 2 Connector 2 USB-C (10Gbps, 4.5W) Connector 2 (Quantity) 1 Connector 3 RJ-45 Connector 3 (Quantity) 1 Connector 4 USB-C (100W PD Only) Connector 4 (Quantity) 1 Host Connector 1 USB-C (10Gbps, 4.5W) Host Connector 1 (Quantity) 1 A+ Not Required Actual Inbox Documents Created QSG in the box Amazon Merchandising Manager Kristian Haighton Application Photos Uploaded Artwork Due Date 2023-09-30 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge Yes Comparable SKU Comment 1Gig Ethernet, non VBL, slightly shorter Cable Comparable SKU 2 Comment 5Gbps data, no ethernet but PD passthrough in 10Gbps hub Digital Content Due Date 2023-12-08 Enhanced Gallery Required Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett ID Label Silkscreened or a Label Silkscreened label - requires dieline showing location Launch Markets (concatenated) BE,CA,CH,DE,DK,ES,FI,FR,IE,IN,IT,JP,NL,SE,UK,US Primary Technology - USB 3.2 Gen 2 / 10Gbps
- USB-C
- Power Delivery
Product Development Specialist Pierre Wheeler Product Information Creation Specialist (PICS) Maria Powell Product Manager Natalie Goodale Product Performance Specialist Aaron Bens Product Photographer Caleigh Le Grand Target Development Completion Date 2023-07-28 Target Production Release 2023-09-30 Tech Lead Stefan Tirolese Technical Writer Dan Dagenais Technology Lifecycle Latest Video Not Required
