142-USBC-DP-8K-10F
USB C to DisplayPort 1 4 8K Cable 3m 9 5ft
Connect a DisplayPort Alt Mode-enabled USB-C source to a DisplayPort monitor with support for resolutions up to 8K at 60Hz
Main Image
Product Images
Product Images
Product Images
Product Images
Product Name USB C to DisplayPort 1 4 8K Cable 3m 9 5ft Product Number 142-USBC-DP-8K-10F UPC 065030901291 Lifecycle status Active Warranty 3 Years Weighted Opportunity 33191 Taxonomy Product > Docks, Hubs & Video Adapters > Video Adapters Category Level 1 Display and Video Adapters Category Level 2 USB-C Display Adapters Category Level 3 USB-C to DP - 8K HDR Family USBC to DP 1.4 Adapter Cables, DP Alt Mode, Full VBL, 8K60 Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) Vietnam Country of Origin Revision (1) XXXXXX126X Product Title (Ultra-Short) 3m USB-C to DP Cable Product Title (Short) 10ft/3m USB-C to DP Adapter Cable, 8K60 Product Title (Medium) 10ft (3m) USB-C to DisplayPort Adapter Cable, 8K 60Hz, USB Type-C to DP 1.4 Product Title (Standard) 10ft (3m) USB-C to DisplayPort Adapter Cable, 8K 60Hz, 4K 144Hz, HDR10, USB Type-C to DP 1.4 Converter, USB4/TB3/4 Compatible Product Title (Long) 10ft (3m) USB-C to DisplayPort Adapter Cable, 8K 60Hz, 4K 144Hz, HDR, USB Type-C to DP 1.4 Video Converter Cable, USB4/Thunderbolt 3/4 Compatible Product Title (AMZ) 10ft (3m) USB-C to DisplayPort Adapter Cable, 8K 60Hz, 4K 144Hz, HDR10, USB Type-C to DP 1.4 Converter Title Ingram (Part 1) 3m USB-C DisplayPort Cable - Title Ingram (Part 2) USB-C to DP Adapter Cable, 8K 60Hz Website Product Headline Connect a DisplayPort Alt Mode-enabled USB-C source to a DisplayPort monitor with support for resolutions up to 8K at 60Hz Bullet 1 HIGH PERFORMANCE: 9.8ft (3m) USB-C to DisplayPort Adapter Cable connects a USB-C DP Alt-mode source to an 8K 60Hz/4K 144Hz DisplayPort monitor; Connect a primary or secondary display in extended or mirrored mode Bullet 2 NO DRIVERS OR SOFTWARE: Universal Adapter Cable is compatible with all hardware platforms and any operating system; USB Type-C to DisplayPort Cable works with USB-C DP Alt Mode, USB4, Thunderbolt 3, and Thunderbolt 4 laptops and devices Bullet 3 HOST COMPATIBILITY: Active DP Converter Cable works with laptops and devices from Dell, HP, Lenovo, Microsoft, and more; Apple M1/M2/M3 devices (e.g. MacBook Pro) only support up to 4K 60Hz over USB-C DP Alt Mode and will not be able to achieve 8K 60Hz Bullet 4 BUILD QUALITY & DESIGN: Integrated video adapter and cable minimizes failure points and signal loss; Latching DisplayPort connector ensures a secure connection, minimizing the risk of accidental disconnection; Aluminum shell provides EMI shielding Bullet 5 TECH SPECS: 9.8ft USBC to DP Cable is DisplayPort 1.4/1.2 compliant, supporting HDR10, HBR3, and DSC; HDCP 1.4/2.3; 32.4Gbps Bandwidth; Supports 2ch DP audio; Works at lower resolutions (i.e., 4K and 1080p); TPE Jacket; Outside Cable Diameter: 4.3mm Bullets (Compact) 9.8ft (3m) USB-C to DisplayPort Adapter Cable connects a USB-C DP Alt Mode laptop to an 8K 60Hz/4K 144Hz DP Display; Universal Adapter Cable requires no drivers/software; USB4/Thunderbolt 3/4 compatible; DisplayPort 1.4; HDR10; 2ch Audio Bullets (Consolidated) - 9.8ft (3m) USB-C to DisplayPort Adapter Cable connects a USB-C DP Alt-mode source to an 8K 60Hz/4K 144Hz DisplayPort Display - Universal USB Type-C to DP Converter Cable requires no drivers or software; Works with USBC DP Alt Mode/USB4/Thunderbolt 3/4 laptops and devices - DisplayPort 1.4 compliant supporting HDR10/DSC/2ch audio - Integrated video adapter and cable minimizes failure points and signal loss; Latching DisplayPort connector; Aluminum shell provides EMI shielding Marketing Copy Marketing Copy (No HTML) Applications - Connect a USB-C device to an 8K DisplayPort monitor without installing drivers or software
- Ideal for creative professionals who work with high-resolution graphics or video
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- 85
- RCM - EMC/EMI - Australia/New Zealand - DO NOT USE RCM EMC - General Statement - DON'T USE
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Plastic - Low-Density Polyethylene
- Triman/Info-Tri - Packaging - Waste - European Union - Plastic Bag
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
System and Cable Requirements - The host USB-C port must support DisplayPort over USB-C (DP Alt mode) in order to work with this adapter.
- In order to achieve maximum performance of this product, both the source and destination devices must support the appropriate specifications.
Related Products - CDP2DP1MBD
- CDP2DP2MBD
Power Delivery No PD Pass-Through Cable Length (mm) 3000 Color Black & Gray Humidity 5% ~ 95% RH Operating Temperature -20°C to 70°C (-4F° to 158F°) Product Length (mm) 306.000 Product Width (mm) 60.000 Product Height (mm) 9.000 Product Weight (g) 92.000 Storage Temperature -40°C to 70°C (-40F° to 158F°) TAA Compliant No Audio Specifications DisplayPort - 2 Channel Audio HDR Support Yes Maximum Digital Resolutions 8K 60Hz Maximum Supported Resolution 8K 60Hz (DSC) OS Compatibility OS Independent Supported Resolutions Video Output Port DisplayPort Wide Screen Supported Yes Audio Yes AV Input USB-C AV Output DisplayPort - 1.4 Cable Jacket Material TPE - Thermoplastic Elastomers Chipset ID VL103 Converter Type Cable Adapters Host Connection Port USB-C Number of Displays 1 Carton Depth (mm) 524 Carton Height (mm) 346 Carton Quantity 120 Carton Weight Gross (g) 13710 Included in Package 1 - USB-C to DisplayPort Cable Number of Sub-Cartons 12 Package Depth (mm) 199 Package Height (mm) 20 Package Width (mm) 169 Package Weight (g) 106 Packaging Description 10ft (3m) USB-C to DisplayPort Cable - 8K 60Hz Packaging Description India 10ft (3m) USB-C to DisplayPort Cable - 8K 60Hz Sub-Carton Depth (mm) 368 Sub-Carton Height (mm) 75 Sub-Carton Width (mm) 234 Sub-Carton Quantity 10 Sub-Carton Weight (g) 1052 Connector 1 USB-C DP++ (DP Alt-Mode) Connector 1 (Quantity) 1 Connector 2 DisplayPort Connector 2 (Quantity) 1 A+ Not Required Actual Inbox Documents Created None Amazon Merchandising Manager Kristian Haighton Application Photos Required Artwork Due Date 2023-07-28 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge No Comparable SKU Comment Passive cable. Comp sku is active cable and more expensive. Comparable SKU 2 Comment Passive cable. Comp sku is active cable and more expensive. Digital Content Due Date 2024-05-10 Enhanced Gallery Not Required Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level - 1 Graphic Designer Shane Arnett ID Label Silkscreened or a Label No ID label Launch Markets (concatenated) AT,BE,CA,CH,DE,DK,ES,FI,FR,IE,IN,IT,JP,NL,SE,UK,US Primary Technology - USB-C
- DisplayPort 1.4
Product Development Specialist Michael Munn Product Information Creation Specialist (PICS) Dan Dagenais Product Manager David Muzinic Product Performance Specialist John Mardinly Product Photographer Caleigh Le Grand Target Development Completion Date 2023-10-13 Target Production Release 2023-10-20 Tech Lead Brian Linseman Technical Writer Dan Dagenais Technology Lifecycle Mainstream Video Not Required
