1USB3-NVME-DOCK
M2 NVMe Docking Station - UCB-C 10Gbps
Access Ultra-Fast M.2 NVMe drive storage via USB 10Gbps
Main Image
Product Images
Product Images
Product Images
Product Images
BOM Image
Quick-Start Guide
Product Name M2 NVMe Docking Station - UCB-C 10Gbps Product Number 1USB3-NVME-DOCK UPC 065030912563 Lifecycle status Pending Warranty 2 Years Weighted Opportunity 0 Taxonomy Product > Cards & Adapters > Data Storage Cards & Adapters Category Level 1 Data Storage Category Level 2 Drive Docking Stations Category Level 3 HDD Docking Stations - 10Gbps Family Single Bay M.2 NVMe Dock 10Gbps Country of Origin Europe & Japan Vietnam Country of Origin North America Vietnam Country of Origin History (1) Vietnam Country of Origin Revision (1) XXXXXX177X Product Title (Ultra-Short) USB to M.2 NVMe Dock Product Title (Short) USB-C/USB-A to M.2 NVMe Dock Adapter Product Title (Medium) USB-C/USB-A to M.2 NVMe Dock Adapter, 10Gbps, Tool-Free External M.2 NVMe SSD Reader Product Title (Standard) USB-C/USB-A to M.2 NVMe Dock Adapter, 10Gbps, Tool-Free External M.2 NVMe SSD Reader, B+M/M-Key Product Title (Long) USB-C/USB-A to M.2 NVMe Dock Adapter, 10Gbps, Tool-Free External M.2 NVMe SSD Reader, B+M/M-Key Product Title (AMZ) USB-C/USB-A to M.2 NVMe Dock Adapter, 10Gbps, Tool-Free External M.2 NVMe SSD Reader, B+M/M-Key Title Ingram (Part 1) M.2 NVMe and SATA SSD Adapter Title Ingram (Part 2) USB-C/USB-A 10Gbps, SSD/HDD Reader Website Product Headline Access Ultra-Fast M.2 NVMe drive storage via USB 10Gbps Bullet 1 Bullet 2 Bullet 3 Bullet 4 Bullet 5 Bullets (Compact) USB-C/USB-A to M.2 NVMe Dock Adapter supports up to 10Gbps; Driverless setup for seamless compatibility across laptops/workstations; Toaster-style, tool-free design for quick drive access; Supports M-Key M.2 NVMe drives; M.2 SATA is not supported Bullets (Consolidated) Access an M.2 NVMe drive via USB-C or USB-A at up to 10Gbps - Driverless setup for seamless compatibility - Supports M-Key M.2 NVMe drives including Samsung EVO/Kingston/Western Digital/HP/Intel; NOTE: M.2 SATA is not supported - Toaster-style design allows for quick and tool-free insertion and removal of M.2 NVMe drives - Bus-powered operation for simple, cable-only setup - Perform quick backups/data transfers or disk imaging; ideal for IT pros requiring fast external M.2 NVMe SSD connectivity Marketing Copy Marketing Copy (No HTML) Applications - Enable fast, tool-free access to an M.2 NVMe drive through a USB-C or USB-A port
- Lets IT teams quickly troubleshoot M.2 NVMe drives to monitor drive health, test performance, or recover data
Website Search Keyword - nvme adapter
- USB NVMe Enclosure
- USB NVMe cable
- USB to NVMe and SATA Adapter
- USB to M.2 and SATA Adapter
Required Marketing Compliance Marks FSC - Environmental - Global - FSC Mix Packaging (Global 7 Languages) Required Regulatory Compliance Marks - Triman/Info-Tri - Manual - Waste - European Union - Print Paper
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- UKCA - Environmental - United Kingdom - UK Restriction of Hazardous Substances (RoHS) 2012
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Corrugated Fiberboard
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + paper tray/divider
Special Notes - Always eject the drive(s) safely through the Operating System before disconnecting. Avoid hot-swapping drives to prevent data loss or device damage.
- M.2 SATA drives are not supported
Cable Length (mm) 300 Color Black Humidity 20-85% RH Material Post-Consumer Recycled Plastic (PCR) Operating Temperature 0°C to 40°C (32°F to 104°F) Product Length (mm) 403.7 Product Width (mm) 59 Product Height (mm) 18 Product Weight (g) 62 Storage Temperature -20°C to 60°C (-4°F to 140°F) TAA Compliant No 4Kn Support Yes Hot Swap Capability Yes Max Drive Capacity 1 Maximum Data Transfer Rate 10 Gbps MTBF (hours) 129956 Hours SATA Type and Rate NVMe (PCIe Gen 4) S.M.A.R.T. Support Yes TRIM Support Yes UASP Support Yes USB Type and Rate USB 10Gbps Bus Type - USB-C
- USB-A
Chipset ID ASMedia - ASM2362 Compatible Drive Types M.2 NVMe Fans Included? Yes/No No Interface/Bridge USB 3.2 Gen 2 (10 Gbps) LED Indicators Number of Drives 1 Supported Drive Height(s) - 2230
- 2242
- 2260
- 2280
- 22110
Carton Depth (mm) 485 Carton Height (mm) 230 Carton Quantity 60 Carton Weight Gross (g) 7000 Included in Package - 1 - USB-C/USB-A 2-in-1 M.2 NVMe Dock Adapter
- 1 - Quick-Start Guide
Package Depth (mm) 152 Package Height (mm) 30 Package Width (mm) 100 Package Weight (g) 109 Packaging Description USB-C/USB-A 2-in-1 M.2 NVMe Dock Adapter - 10Gbps Packaging Description India USB-C/USB-A 2-in-1 M.2 NVMe Dock Adapter - 10Gbps Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 M.2 M-Key (PCIe, AHCI / NVMe) Connector 1 (Quantity) 1 Host Connector 1 USB-C (10Gbps, 4.5W) Host Connector 1 (Quantity) 1 Host Connector 2 USB-A (10Gbps, 4.5W) Host Connector 2 (Quantity) 1 A+ Not Required Actual Inbox Documents Created Compliance Insert & EN/DE QSG Amazon Merchandising Manager Veronica Ye Amazon Only SKU No Amazon Visual Content Level Diamond Apple Compatibility Apple Compatible Application Photos Uploaded Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge Yes Comparable SKU Comment Portable version with USB 10gbps Comparable SKU 2 Comment Portable version supporting TB3 and USB 10gbps Digital Content Due Date 2025-12-31 Enhanced Gallery Required Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level - 1 Graphic Designer Brooke Taylor ID Label Silkscreened or a Label Sticker label - custom size - requires size population below Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,FI,FR,IE,IN,IT,JP,MX,NL,NZ,PE,SE,SG,UK,US Primary Technology - USB 3.2 Gen 2 / 10Gbps
- USB-C
Priority New Product High Product Development Specialist Yipeng Zhang Product Information Creation Specialist (PICS) Brian Chan Product Manager Tony Parackal Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Development Completion Date 2025-09-05 Target Production Release 2025-09-12 Tech Lead Justin Weaver Technical Writer Brian Chan Technology Lifecycle None Video Not Required
