9FMNM-3M-RS232-CABLE
3m DB9 RS232 Serial Null Modem Cable F M
Connect serial enabled devices at a distance of up to 3m
Main Image
Product Images
Product Images
Product Images
Product Images
Product Name 3m DB9 RS232 Serial Null Modem Cable F M Product Number 9FMNM-3M-RS232-CABLE UPC 065030894449 Lifecycle status Active Warranty Lifetime Taxonomy Product > Cables > Serial, Parallel and PS2 Cables Category Level 1 Cables - Other Category Level 2 Serial, Parallel and PS2 Cables Category Level 3 Serial Cables Family Serial Null Modem Cable Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX045X Country of Origin History (2) China Country of Origin Revision (2) XXXXXX045X Product Title (Ultra-Short) RS232 Serial Cable Product Title (Short) RS232 Serial Null Modem Cable, Crossover Product Title (Medium) 3m RS232 Serial Null Modem Cable, Serial Port/DB9/Crossover Cable Female to Male Product Title (Standard) 3m RS232 Serial Null Modem Cable, Crossover Serial Cable w/Al-Mylar Shielding, DB9 Serial COM Port Cable Female to Male, F/M Product Title (Long) 3m RS232 Serial Null Modem Cable, Crossover Serial Cable w/Al-Mylar Shielding, DB9 Serial COM Port Cable Female to Male, Compatible w/DTE Devices, Black, F/M Product Title (AMZ) 3m RS232 Serial Null Modem Cable, Crossover Serial Cable w/Al-Mylar Shielding, DB9 Serial COM Port Cable Female to Male, Compatible w/DTE Devices, Black, F/M (9FMNM-3M-RS232-CABLE) Title Ingram (Part 1) RS232 Serial Null Modem Cable Title Ingram (Part 2) - 3m Crossover Serial Cable Website Product Headline Connect serial enabled devices at a distance of up to 3m Bullet 1 RS232 SERIAL NULL MODEM CABLE: DB9 male to female serial cable enables a connection between two DTE devices at a distance of up to 3 meters, reducing cable length restrictions and providing flexible serial device setup configuration Bullet 2 QUALITY CONSTRUCTION: High quality 28 AWG tinned wires with aluminum mylar cable shielding and shielded metal shell connectors prevent EMI interference; Molded PVC connectors with strain reliefs and PVC cable jacket prevent damage due to bends Bullet 3 SCREW LOCKING NULL-MODEM CABLE: This crossover cable features thumbscrews that prevent accidental disconnection which can lead to data loss Bullet 4 SPECIFICATIONS: 3m (9.8ft) | DB9 male to DB9 female | Color: Black | 28AWG | OD: 4.8mm | Al-Mylar cable shield & Metal shell connectors | Molded PVC strain reliefs and jacket | Note: This is a null-modem cable, it is not a straight-through cable Bullet 5 THE IT PRO'S CHOICE: Designed and built for IT Professionals, this serial null-modem DB9 cable is backed for life, including free lifetime 24/5 multi-lingual technical assistance | This serial cable is available in other lengths Bullets (Compact) 3m RS232 serial null modem DB9 male to female cable; 28 AWG tinned wires with aluminum mylar cable shielding and shielded metal shell connectors; SPECS: 3m (9.8ft) |Serial Port Male to Female | Black | 28AWG | Note: Not straight-through serial cable Bullets (Consolidated) RS232 serial null modem DB9 male to female cable enables a connection between serial devices at a distance of up to 3 meters - Constructed with high quality 28 AWG tinned wires with aluminum mylar cable shielding and shielded metal shell connectors help prevent EMI interference - Specifications: 3m (9.8ft) | Serial Port Male to Female | Color: Black | Serial Crossover Cable | Note: This is not a straight-through serial cable Marketing Copy Marketing Copy (No HTML) Website Search Keyword - crossover serial cable
- db9 null modem male to female
- db9 serial null modem cable
- male to female null modem cable
- null modem
- rs232 crossover cable
- rs232 female to male
- rs232 serial null modem cable
- serial port male to female
Required Regulatory Compliance Marks - CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
Special Notes This is not a straight-through serial cable Related Products - SCNM925FM
- SCNM9FF
- SCNM9FF1MBK
- SCNM9FF2MBK
Cable Length (mm) 3000 Color Black Connector Style Straight Humidity 15% ~ 65% Operating Temperature 20 to 80°C (68 to 176°F) Product Length (mm) 3000 Product Width (mm) 33 Product Height (mm) 15 Product Weight (g) 143.5 Storage Temperature 20 to 80°C (68 to 176°F) TAA Compliant No Wire Gauge 28 AWG Supported Protocols Null modem Cable Jacket Material PVC Cable Shield Material Aluminum-Mylar Foil with Drain Connector Plating Nickel Number of Conductors 7 Screw Lock Yes Serial/Parallel Cable Type Null Modem (RS232) Carton Depth (mm) 432 Carton Height (mm) 282 Carton Quantity 100 Carton Weight Gross (g) 16166 Included in Package 1 - Null Modem Serial Cable F/M Included In Package for Label 1 - Null Modem Serial Cable F/M Package Depth (mm) 125 Package Height (mm) 24 Package Width (mm) 187 Package Quantity 1 Package Weight (g) 156 Packaging Description 3m (10ft) DB9 RS232 Null Modem Serial Cable Packaging Description India 3m (10ft) DB9 RS232 Null Modem Serial Cable Sub-Carton Depth (mm) 154 Sub-Carton Height (mm) 134 Sub-Carton Width (mm) 255 Sub-Carton Weight (g) 1532 Connector 1 DB-9 Serial Connector 1 (Quantity) 1 Connector 2 DB-9 Serial Connector 2 (Quantity) 1 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2021-11-19 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Digital Content Due Date 2022-07-18 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,DE,DK,ES,FI,FR,IE,IN,IT,JP,MX,NL,NZ,PE,SE,UK,US Primary Technology None Product Development Specialist Alex Sikora Product Information Creation Specialist (PICS) Brian Chan Product Manager Tim North Product Performance Specialist Ray Aoki Product Photographer Caleigh Le Grand Target Development Completion Date 2021-10-28 Target Production Release 2022-01-20 Tech Lead Justin Weaver Technical Writer Maria Powell Technology Lifecycle Mainstream
