AF211C-POE-INJECTOR
1 Port 802 3at 30W Gigabit PoE Injector
Supply power and data to a remote Powered Device (PD) with this PoE/PoE+ injector
Main Image
Product Images
Product Images
Product Images
Product Images
BOM Image
Quick-Start Guide
Video Link YouTube
Product Name 1 Port 802 3at 30W Gigabit PoE Injector Product Number AF211C-POE-INJECTOR UPC 065030905169 Lifecycle status Active Warranty 2 Years Weighted Opportunity 39305 Taxonomy Product > Networking > Network Switches Category Level 1 Networking Category Level 2 POE Injectors and Extenders Category Level 3 POE Injectors Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX128X Product Title (Ultra-Short) 1-Port PoE+ Injector Product Title (Short) 1-Port Multi-Gigabit PoE/PoE+ Injector Product Title (Medium) 1-Port Gigabit PoE+ Injector, 10M/100M/1G Ethernet, PoE/PoE+, 30W (802.3at) Product Title (Standard) 1-Port Gigabit PoE+ Injector, 10M/100M/1G Ethernet, PoE/PoE+ (802.3af/802.3at), 30W, Wall Mountable, Unmanaged, TAA Product Title (Long) 1-Port Gigabit PoE+ Injector, 10M/100M/1G Ethernet, PoE/PoE+ (802.3af/802.3at), 30W Power Budget, Wall Mountable, Unmanaged Inline Power Over Ethernet - TAA Product Title (AMZ) 1-Port Gigabit PoE+ Injector, 10M/100M/1G Ethernet, PoE/PoE+ (802.3af/802.3at), 30W Power Budget, Wall Mountable, TAA Title Ingram (Part 1) 1-Port PoE/PoE+ Injector 30W - Title Ingram (Part 2) 802.3at, 10M/100M/1G Ethernet Website Product Headline Supply power and data to a remote Powered Device (PD) with this PoE/PoE+ injector Bullet 1 GIGABIT POE INJECTOR: Single port PoE+ injector supports up to 1Gbps with auto-negotiation; TAA-compliant Power Sourcing Equipment (PSE) supports up to 30W PoE/PoE+; Features level-4 ESD protection for reliable performance and durability Bullet 2 MULTIPLE SPEEDS: Auto-negotiation between 1Gbps & 10/100Mbps Ethernet; Deliver data & power to Powered Devices (PDs) up to 328ft (100m) w/Cat5/5e/6/6a cabling; Unmanaged inline injector w/built-in LAN transformer for electrical isolation reducing EMI Bullet 3 HASSLE-FREE INSTALLATION: Wall-mountable design with front mounting holes; Streamline deployment without additional software/settings; Connect the PoE injector to the network (e.g., switch or router) & the remote PD via standard Cat5/e or Cat6/6a cabling Bullet 4 APPLICATIONS: Enable data & power over a single RJ45 connection to critical PoE devices such as IP cameras & Access Points (APs); Ideal for remote device installations with limited power sources; Wall-mountable design for convenient installation & access Bullet 5 TECH SPECS: x2 RJ45 ports (data/data+power); 54VDC 0.6A output; 30W max output; Compliant with IEEE 802.3af and IEEE 802.3at; 10/100Mbps & 1Gbps with auto negotiation; WoL/PXE/9K jumbo frames; Wall mountable; Dimensions 4x2.3x1.3-inch (100x58.4x33.4mm) Bullets (Compact) 1-Port multi-speed PoE+ injector - Unmanaged inline injector supports PoE/PoE+ (802.3af/802.3at) up to 30 Watts - Multiple speed PoE plus injector (10/100Mbps and 1Gbps) - Extend data/power up to 100m w/Ethernet Cat5/5e/6/6a cables - Wall Mountable Bullets (Consolidated) - Single port unmanaged PoE+ injector supports 1Gbps and 10/100M Ethernet - Up to 30 Watts PoE/PoE+ (802.3af/802.3at) output to a remote Powered Device (PD) - Extend power and Gigabit data at distances of up to 100m over Cat5/5e/6/6a - Features network multi-speed auto-negotiation (10/100/1000); Surge protection up to 2Kv; No software or drivers required - Inline injector is ideal for powering remote IP cameras/WiFi APs/PoE lighting/signage boxes; Wall mountable Marketing Copy Marketing Copy (No HTML) Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- UL - Safety - Electrical - Canada / United States - Enhanced UL Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- Triman/Info-Tri - Product - Waste - European Union - EEE Device + accessories + cords
Accessory Products - N6PATCH100BL
- N6PATCH50BL
- N6PATCH25BK
- N6PATCH10OR
- WIRC6PATBLRL
- WIRC6PATBKRL
- WIRC6CMRBL
Related Products - AS445C-POE-INJECTOR
- POEINJ30W
- POEINJ1G90W
- POEINJ1G
- PR12GIP-NETWORK-CARD
- ST1000PEXPSE
Input Current 0.8 A Input Voltage 100 - 240 AC Output Current 0.6 A Output Voltage (V) 54 DC Power Consumption (In Watts) 32.4 Power Source Standard 120V Power Cords Color Black Humidity 5~95% RH (Non-Condensing) Material Plastic Operating Temperature 32°F to 122°F (0°C to 50°C) Primary Material Plastic Product Length (mm) 100.000 Product Width (mm) 58.400 Product Height (mm) 33.400 Product Weight (g) 100.000 Storage Temperature 14°F to 158°F (-10°C to 70°C) TAA Compliant Yes Auto MDIX Yes Compatible Networks 10/100/1000 Mbps ESD Protection - +/-8kV (Contact)
- +/-15kV (Air)
Jumbo Frame Support 9K max. Maximum Cable Length (mm) 100000 Maximum Data Transfer Rate 1000 Mbps OS Compatibility OS Independent PXE Yes Supported Protocols Wake-on-LAN (WoL) Total Available Power Output (In Watts) 30W Wake-On-LAN (WOL) Yes Chipset ID Monolithic Power Systems - MP3924 Ethernet Port Yes Industry Standards LED Indicators 1 - Power LED: </br> Steady Green - Power is being supplied to the PoE Injector </br> Off - No power is being supplied to the PoE Injector Mounting Options Surface Mount Carton Depth (mm) 524 Carton Height (mm) 464 Carton Quantity 40 Carton Weight Gross (g) 15640 Included in Package - 1 - PoE Injector
- 1 - 6ft (1.8m) NA Power Cord
- 1 - Quick-Start Guide
Package Depth (mm) 212 Package Height (mm) 52 Package Width (mm) 125 Package Quantity 1 Package Weight (g) 372 Packaging Description 1-Port 802.3at 30W Gigabit PoE+ Injector Packaging Description India 1-Port 802.3at 30W Gigabit PoE+ Injector Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 IEC C6 (250V AC, 2.5A) Connector 1 (Quantity) 1 Connector 2 RJ-45 Connector 2 (Quantity) 1 Connector 3 RJ-45 Connector 3 (Quantity) 1 A+ Not Required Actual Inbox Documents Created QSG in the box Amazon Merchandising Manager Kathleen Marshall Application Photos Required Artwork Due Date 2024-01-15 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Comparable SKU Comment 1-port 1G 802.3at PoE Injector Comparable SKU 2 Comment Industrial 802.3at Gigabit PoE injector Digital Content Due Date 2024-04-24 Enhanced Gallery Not Required Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level - 2 Graphic Designer Shane Arnett ID Label Silkscreened or a Label Sticker label - 50x25mm Launch Markets (concatenated) CA,US Product Development Specialist Alex Sikora Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Development Completion Date 2023-11-30 Target Production Release 2024-01-15 Tech Lead Stefan Tirolese Technical Writer Dan Dagenais Technology Lifecycle None Video Not Required
