Main Image
ATX2PW450BR
450W ATX 12V 80 Plus Active PFC Power Supply
Build or upgrade a computer system with an energy efficient and reliable 450 Watt Bronze ATX power supply
Main Image
Product Images
Product Images
BOM Image
Product Name 450W ATX 12V 80 Plus Active PFC Power Supply Product Number ATX2PW450BR UPC 065030852975 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Computer Cards and Adapters Category Level 2 Components, Tools and Accessories Category Level 3 Power Supplies Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX097X Product Title (Ultra-Short) 450W Power Supply Product Title (Short) 450W 80Plus Bronze Computer Power Supply Product Title (Standard) 450 Watt ATX12V 2.3 80 Plus Bronze Computer Power Supply w/ Active PFC Product Title (Long) 450 Watt ATX12V 2.3 80 Plus Bronze Computer Power Supply w/ Active PFC Product Title (AMZ) 450 Watt ATX12V 2.3 80 Plus Bronze Computer Power Supply w/ Active PFC 450W ATX Active PFC Power Supply ATX 12V 2.3 12cm Fan (ATX2PW450BR) Title Ingram (Part 1) 450W ATX 12V 80 Plus Active PFC Title Ingram (Part 2) Power Supply - 450 Watt PSU Website Product Headline Build or upgrade a computer system with an energy efficient and reliable 450 Watt Bronze ATX power supply Bullet 1 80 Plus Bronze-Certified Bullet 2 Protection: Short Circuit Protection (SCP), Over Voltage Protection (OVP), Over Current Protection (OCP), Over Power Protection (OPP) Bullet 3 110~240VAC Auto switching power supply Bullet 4 Complies with Intel EPS 12V rev: 2.8/2.92 Bullet 5 Support for Intel and AMD Systems Marketing Copy Applications - Replacing an older, less reliable power supply
- Upgrading or building an energy-efficient PC with a more efficient, 80 Plus Bronze-certified power supply
- Upgrading existing systems to meet new system requirements for SATA drive connections and PCIe graphics
Accessory Products - PAC1016
- PXT101_10
- PXT10115
- PXT101L10
- PXT101L
- PXT101Y
Related Products - ATX2PW630WH
- ATX2PW550WH
- ATX2PW530WH
- ATX2PW500WH
- ATX2PW430WH
Input Voltage 100 - 240 AC Color Black Humidity 10~90% RH Material Aluminum Operating Temperature 0°C to 40°C (32°F to 104°F) Product Length (mm) 150 Product Width (mm) 86 Product Height (mm) 140 Product Weight (g) 1726 Storage Temperature -20°C to 80°C (-4°F to 176°F) TAA Compliant No Carton Depth (mm) 257 Carton Height (mm) 460 Carton Quantity 10 Carton Weight Gross (g) 2078 Included in Package - 1 - 450 Watt Power Supply
- 1 - Quick Install Guide
Package Depth (mm) 215 Package Height (mm) 127 Package Width (mm) 242 Package Quantity 1 Package Weight (g) 2078 Packaging Description 450 Watt 80Plus ATX 2.3 Power Supply w/ Active PFC Packaging Description India 450 Watt 80Plus ATX 2.3 Power Supply w/ Active PFC Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 ATX Power (24-Pin, 3.3V / 5V / 12V) Connector 1 (Quantity) 1 Connector 2 PCIe Power (8-Pin, 12V, 150W) Connector 2 (Quantity) 1 Connector 3 ATX 12V EPS Power (4+4 pin) Connector 3 (Quantity) 1 Connector 4 ATX AUX Power (6-Pin, 3.3V / 5V) Connector 4 (Quantity) 1 Connector 5 SATA (15-Pin) Connector 5 (Quantity) 4 Connector 6 ATX Power (4-Pin, 12V, 192W) Connector 6 (Quantity) 1 Connector 7 LP4 / Molex Power (4-Pin, 5V / 12V) Connector 7 (Quantity) 3 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2013-07-08 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Graphic Designer Shane Arnett Launch Markets (concatenated) CA,EU,UK,US Primary Technology None Product Development Specialist Sead Ferhatovic Product Information Creation Specialist (PICS) Alex Garcia Product Manager Natalie Goodale Product Performance Specialist Aaron Bens Product Photographer Alejandra Valencia Tech Lead Brian Linseman Technical Writer Andrew Richardson Technology Lifecycle Legacy
