ATX2PW450GO
450W ATX 12V 80 Plus Active PFC Power Supply
Build or upgrade a computer system with an energy efficient and reliable 450 Watt Gold ATX power supply
Main Image
Product Images
Product Images
BOM Image
Product Name 450W ATX 12V 80 Plus Active PFC Power Supply Product Number ATX2PW450GO UPC 065030852944 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Computer Cards and Adapters Category Level 2 Components, Tools and Accessories Category Level 3 Power Supplies Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX097X Product Title (Ultra-Short) 450W Power Supply Product Title (Short) 450W 80 Plus Gold Computer Power Supply Product Title (Standard) 450 Watt ATX12V 2.3 80 Plus Gold Computer Power Supply w/ Active PFC Product Title (Long) 450 Watt ATX12V 2.3 80 Plus Gold Computer Power Supply w/ Active PFC Product Title (AMZ) 450 Watt ATX12V 2.3 80 Plus Gold Computer Power Supply w/ Active PFC 450W ATX Active PFC Power Supply ATX 12V 2.3 - 12cm Fan (ATX2PW450GO) Title Ingram (Part 1) 450W ATX 12V 80 Plus Active PFC Title Ingram (Part 2) Power Supply - 450 Watt PSU Website Product Headline Build or upgrade a computer system with an energy efficient and reliable 450 Watt Gold ATX power supply Bullet 1 80 Plus Gold-Certified Bullet 2 Support for Intel and AMD Systems Bullet 3 Active Power Factor Correction (A-PFC) Bullet 4 Protection: Short Circuit Protection (SCP), Over Voltage Protection (OVP), Over Current Protection (OCP), Over Power Protection (OPP) Bullet 5 Complies with Intel EPS 12V rev: 2.8/2.92 Marketing Copy Applications - Replacing an older, less reliable power supply
- Upgrading or building an energy-efficient PC with a more efficient, 80 Plus Gold-certified power supply
- Upgrading existing systems to meet new system requirements for SATA drive connections and PCIe graphics
Required Regulatory Compliance Marks - WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Safety - Electrical - European Union - Low Voltage Directive (LVD) 2014/35/EU
- UL Recognized - Safety - Electrical - Canada / United States - cURus Recognised Component Mark
Accessory Products - PAC1016
- PXT10115
- PXT101L10
- PXT101Y
- PXT101L
- PXT101_10
Related Products - ATX2PW450BR
- ATX2PW550WH
- ATX2PW530WH
- ATX2PW500WH
- ATX2PW630WH
- ATX2PW430WH
Input Voltage 100 - 240 AC Color Black Humidity 10~90% RH Material Aluminum Operating Temperature 0°C to 40°C (32°F to 104°F) Product Length (mm) 140 Product Width (mm) 150 Product Height (mm) 85 Product Weight (g) 2020 Storage Temperature -20°C to 80°C (-4°F to 176°F) TAA Compliant No Fan Bearing Type Sleeve Bearing Fans 1 - 120 mm Carton Depth (mm) 247 Carton Height (mm) 425 Carton Quantity 10 Carton Weight Gross (g) 23450 Included in Package - 1 - 450 Watt Power Supply
- 1 - Quick Install Guide
Package Depth (mm) 202 Package Height (mm) 98 Package Width (mm) 240 Package Quantity 1 Package Weight (g) 2252 Packaging Description 450 Watt 80Plus ATX 2.3 Power Supply w/ Active PFC Packaging Description India 450 Watt 80Plus ATX 2.3 Power Supply w/ Active PFC Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 ATX Power (24-Pin, 3.3V / 5V / 12V) Connector 1 (Quantity) 1 Connector 2 PCIe Power (8-Pin, 12V, 150W) Connector 2 (Quantity) 1 Connector 3 ATX 12V EPS Power (4+4 pin) Connector 3 (Quantity) 1 Connector 4 ATX AUX Power (6-Pin, 3.3V / 5V) Connector 4 (Quantity) 1 Connector 5 SATA (15-Pin) Connector 5 (Quantity) 4 Connector 6 ATX Power (4-Pin, 12V, 192W) Connector 6 (Quantity) 1 Connector 7 LP4 / Molex Power (4-Pin, 5V / 12V) Connector 7 (Quantity) 3 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2013-07-08 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Graphic Designer Shane Arnett Launch Markets (concatenated) CA,EU,UK,US Primary Technology None Product Development Specialist Sead Ferhatovic Product Information Creation Specialist (PICS) Alex Garcia Product Manager Natalie Goodale Product Performance Specialist Aaron Bens Product Photographer Alejandra Valencia Tech Lead Brian Linseman Technical Writer Andrew Richardson Technology Lifecycle Legacy
