Product Name 500 Watt ATX12V 2.01 Pro Power Supply Product Number ATX2PW500PRO UPC 065030817769 Lifecycle status Discontinued Warranty 3 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX097X Product Title (Short) 500W ATX 12V Computer PSU w/ PCIe & SATA Product Title (Standard) StarTech.com Professional - Computer Power supply with PCIe and SATA ( internal ) - ATX12V 2.01 - AC 115/230 V - 500 Watt - 16 output connector(s) Product Title (Long) Professional 500 Watt ATX12V 2.01 Computer Power Supply w/ PCIe & SATA Title Ingram (Part 1) Professional 500W ATX Computer P Title Ingram (Part 2) ower Supply w/ PCIe & SATA Bullet 1 ATX 2.01 compliant and 24/20 pin dual ATX connector for compatibility with existing standards Bullet 2 Generous number of accessory connectors Bullet 3 Nickel-plated finish Bullet 4 Premium EMI/RFI power filtration provides low noise and ripple for stable power delivery Bullet 5 Quad+1 protection against: short circuit, over power, over voltage, no load Marketing Copy Applications - Ideal for adding PCI Express and SATA power support to existing computers
- The perfect choice for new system builds and upgrades, including dual core CPU (Pentium D, Core 2 Duo, Athlon 64 X2) system designs
Website Search Keyword - PCI-e
- ATXPOW500PRO
Accessory Products - ATX2024FM
- ATXPOWEXT
- LP4PCIEXADAP
- PXT101
- PYO2L
- PYO2S
- PYO2SL
Related Products - ATX2PW400PRO
- ATX2PW450PRO
- ATX2PW550PRO
- ATX2POW500HS
- ATX2POW450HS
Material Nickel-plated Steel Product Length (mm) 150 Product Width (mm) 140 Product Height (mm) 86 Product Weight (g) 2004 TAA Compliant No General Specifications Input Current/Draw: 115V (10A), 230V (5.5A) MTBF (hours) 100,000 Hours Fan Bearing Type Ball Bearing Fans 1 - 80 mm Carton Depth (mm) 672 Carton Height (mm) 280 Carton Quantity 6 Carton Weight Gross (g) 15780 Included in Package - 1 - Instruction Manual
- 1 - Power supply
- 1 - Standard power cable
Package Depth (mm) 100 Package Height (mm) 218 Package Width (mm) 238 Package Weight (g) 2430 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 ATX Power (24-Pin, 3.3V / 5V / 12V) Connector 1 (Quantity) 1 Connector 2 LP4 / Molex Power (4-Pin, 5V / 12V) Connector 2 (Quantity) 6 Connector 3 ATX Power (4-Pin, 12V, 192W) Connector 3 (Quantity) 1 Connector 4 SATA (15-Pin) Connector 4 (Quantity) 4 Connector 5 SP4 / Floppy Power (4-Pin, 5V / 12V) Connector 5 (Quantity) 2 Connector 6 PCIe Power (6-Pin, 12V, 75W) Connector 6 (Quantity) 1 en-US Content Approved Yes Product Manager Daryl Hunt
