Main Image
ATX2PW550PRO
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Name 550 Watt ATX12V 2.01 Pro Power Supply Product Number ATX2PW550PRO UPC 065030817776 Lifecycle status Discontinued Warranty 3 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX097X Product Title (Short) 550W ATX 12V Computer PSU w/ PCIe & SATA Product Title (Standard) StarTech.com Professional - Computer Power supply with PCIe and SATA ( internal ) - ATX12V 2.01 - AC 115/230 V - 550 Watt - 18 output connector(s) Product Title (Long) Professional 550 Watt ATX12V 2.01 Computer Power Supply w/ PCIe & SATA Title Ingram (Part 1) Professional 550W ATX Computer P Title Ingram (Part 2) ower Supply w/ PCIe & SATA Bullet 1 ATX 2.01 compliant and 24/20 pin dual ATX connector for compatibility with existing standards Bullet 2 Generous number of accessory connectors Bullet 3 Nickel-plated finish Bullet 4 Premium EMI/RFI power filtration provides low noise and ripple for stable power delivery Bullet 5 Quad+1 protection against: short circuit, over power, over voltage, no load Marketing Copy Applications - Ideal for adding PCI Express and SATA power support to existing computers
- The perfect choice for new system builds and upgrades, including dual core CPU (Pentium D, Core 2 Duo, Athlon 64 X2) system designs
Website Search Keyword PCI-e Accessory Products - ATX2024FM
- ATXPOWEXT
- LP4PCIEXADAP
- PXT101
- PYO2L
- PYO2S
- PYO2SL
Material Nickel-plated Steel Product Length (mm) 150 Product Width (mm) 155 Product Height (mm) 86 Product Weight (g) 2200 TAA Compliant No General Specifications Input Current/Draw: 115V (12A), 230V (6A) MTBF (hours) 100,000 Hours Fan Bearing Type Ball Bearing Fans 1 - 120 mm Carton Depth (mm) 672 Carton Height (mm) 280 Carton Quantity 6 Carton Weight Gross (g) 17100 Included in Package - 1 - Instruction Manual
- 1 - Power supply
- 1 - Standard power cable
Package Depth (mm) 99 Package Height (mm) 217 Package Width (mm) 238 Package Weight (g) 2650 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 ATX Power (24-Pin, 3.3V / 5V / 12V) Connector 1 (Quantity) 1 Connector 2 LP4 / Molex Power (4-Pin, 5V / 12V) Connector 2 (Quantity) 6 Connector 3 ATX Power (4-Pin, 12V, 192W) Connector 3 (Quantity) 1 Connector 4 SATA (15-Pin) Connector 4 (Quantity) 6 Connector 5 SP4 / Floppy Power (4-Pin, 5V / 12V) Connector 5 (Quantity) 2 Connector 6 PCIe Power (6-Pin, 12V, 75W) Connector 6 (Quantity) 2 en-US Content Approved Yes Product Manager Rafal Gwozdz
