Product Name Refurbished 1U Cabinet Console with 8 Port KVM Switch Product Number CABCONS8R UPC 065030845014 Lifecycle status Discontinued Warranty Refurbished 90 Days Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX066X Product Title (Long) Refurbished 1U 15" Rackmount LCD Console w/ Rear 8 Port KVM Switch Bullet 1 The compact and efficient way to control multiple computers in a 19” by 36” deep Rack Cabinet Bullet 2 Laptop design with an integrated keyboard and touchpad mouse makes it comfortable to use Bullet 3 Built-in 8 port KVM switch controls up to 8 computers directly and up to 64 computers by cascading 8 KVM switches Bullet 4 High resolution 15” Active Matrix Color TFT LCD monitor with a touchpad and a 105 key low profile keyboard Bullet 5 Auto Scan Mode lets you switch between computers for easy monitoring Marketing Copy Applications - Managing cabinet mounted servers
- Improving the internal space efficiency of existing cabinets
- Centralized control of up to 64 PCs
Website Search Keyword cabconssearch Related Products - CABCONS1
- CABCONS16
- 1UCABCONS
Replacement Product RACKCONS1708 Input Current 1.8A Input Voltage 110V-240V AC Output Current 4A Output Voltage (V) 12V DC Power Consumption (In Watts) 3.75W Power Source AC Adapter Included Plug Type M Center Tip Polarity Positive Color Black Material Steel Minimum Mounting Depth (mm) 762 Product Length (mm) 480 Product Width (mm) 404 Product Height (mm) 40 Product Weight (g) 16330 TAA Compliant No Auto Scan 3, 8, 15 & 30 seconds DVI Support No KVM IP Control No Maximum Analog Resolutions 1024 x 768 pixels Maximum Number of Users 1 On-Screen Display Yes OS Compatibility OS Independent Port Selection Support Push Button, Hotkeys, and OSD (On Screen Display) Aspect Ratio 4:3 Audio No Cascadable Yes Display Size 15" Front Door Key Lock No LED Indicators - 2 - Green; Internal/Cascaded KVM in operation
- 8 - Red; PC Selection indicators
Number of KVM Ports 8 Number of Monitors Supported 1 PC Video Type VGA Rack-Mountable Yes Supported Platforms PS/2 U Height 1U Carton Depth (mm) 628 Carton Height (mm) 197 Carton Quantity 1 Carton Weight Gross (g) 17160 Package Depth (mm) 197 Package Height (mm) 628 Package Width (mm) 542 Package Weight (g) 15960 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Host Connector 1 VGA Host Connector 1 (Quantity) 8 Host Connector 2 PS/2 Host Connector 2 (Quantity) 16 en-US Content Approved Yes Product Manager Daryl Hunt
