CC18IN40GUSB4TP
USB4 Gen3 40Gbps Twisted Pair Passive Cable, 1.5ft
Use this USB-IF Certified USB-C cable for fast and reliable connections to your USB4 devices
Main Image
Product Images
Product Images
Product Images
Product Name USB4 Gen3 40Gbps Twisted Pair Passive Cable, 1.5ft Product Number CC18IN40GUSB4TP UPC 065030923699 Lifecycle status Pending Taxonomy Product > Cables > USB & Thunderbolt Cables Category Level 1 USB and Thunderbolt Cables Category Level 2 USB-C Cables Category Level 3 USB-C Cables - 40Gbps USB4 Family USB4 40Gbps Twisted Pair Country of Origin Europe & Japan Vietnam Country of Origin North America Vietnam Country of Origin History (1) Vietnam Country of Origin Revision (1) XXXXXX184X Product Title (Ultra-Short) USB4 Cable USB-C Product Title (Short) 1.5ft USB4 Cable, USB-IF Certified USB-C Product Title (Medium) 1.5ft (45cm) USB4 Cable, 40Gbps, USB-IF Certified USB-C Cable, 8K, 240W, Black Product Title (Standard) 1.5ft (45cm) USB4 Cable, 40Gbps, USB-IF Certified USB-C Cable, 240W, 8K 60Hz/4K 240Hz DP2.1, Thunderbolt 4 Compatible, Black Product Title (Long) 1.5ft (45cm) USB4 Cable, 40Gbps, USB-IF Certified USB-C Cable, 240W PD, 8K 60Hz/4K 240Hz DP2.1 DP40, TPE Jacket, Thunderbolt 4 Compatible - Black USB-C Cord Product Title (AMZ) 1.5ft (45cm) USB4 Cable, 40Gbps, USB-IF Certified USB-C Cable, 240W, 8K 60Hz/4K 240Hz DP2.1, Thunderbolt 4 Compatible, Black Title Ingram (Part 1) 45cm USB4 Cable, Black, USB-IF Title Ingram (Part 2) Certified 8K60/DP2.1/240W/40Gbps Website Product Headline Use this USB-IF Certified USB-C cable for fast and reliable connections to your USB4 devices Bullet 1 Bullet 2 Bullet 3 Bullet 4 Bullet 5 Bullets (Compact) 1.5ft/45cm USB-IF Certified USB4 cable supports 40Gbps; DisplayPort 2.1 video w/ DSC up to 8K 60Hz / 4K 240Hz; 240W PD 3.1 charging; Certified E-marker firmware; Ideal for USB-C and Thunderbolt laptops, docks, monitors, and external storage Bullets (Consolidated) - 1.5ft/45cm Certified USB4 cable supports 40 Gbps 8K video and 240W Extended Power Range (EPR) PD 3.1 charging - Ideal for high power USB-C and Thunderbolt laptops including Apple M-series Pro/Max Macbook - USB-IF Certified w/E-Marker for safety and reliability; Use connector markings to identify specs at-a-glance; TPE jacket w/Nickel-plated connectors - Suitable for USB-C, Thunderbolt laptops/docks/monitors/high-speed storage - USB 40Gbps; 8K 60Hz/4K 240Hz; DisplayPort 2.1 w/DSC; 240W PD 3.1 Marketing Copy Marketing Copy (No HTML) Applications - Designed for seamless operation with USB-C or Thunderbolt 4 docking stations
- Drive sharp 8K 60Hz video or support dual 4K 120Hz UHD displays with DSC
- Transfer data at 40 Gbps speeds and 240W of power over a USB4 connection
- Power and charge USB4/USB-C, and Thunderbolt devices
Website Search Keyword - USB4 Cable
- USB-C Cable
- Laptop Charging Cable
- Apple M3 MacBook Cable
- Apple M3 Max
- 18in USB C Cable
- 0.5m USB-C Cable
Certification USB-IF Required Marketing Compliance Marks - USB-IF - Specification - Global - USB4 Gen3 40Gbps 240W EPR Cable
- FSC - Environmental - Global - FSC Mix Packaging (Global 7 Languages)
Required Regulatory Compliance Marks - CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- UKCA - Environmental - United Kingdom - UK Restriction of Hazardous Substances (RoHS) 2012
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Corrugated Fiberboard
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
Related Products - CC50CM40GUSB4TP
- CC1M40GUSB4TP
- CC3FT40GUSB4TP
- CC18IN40GUSB4TPW
- CC1M40GUSB4TPW
- CC3FT40GUSB4TPW
- CC6FT40GUSB4GEN3
- CC2M40GUSB4GEN3
Input Current 5A Power Delivery 240W Cable Length (mm) 457 Cable OD 5.2 Color Black Connector Style Straight Humidity 40 - 65% RH Material Santoprene - Thermoplastic Rubber (TPE) Operating Temperature 0°C to 60°C (32°F to 140°F) Product Length (mm) 470.3 Product Width (mm) 12.3 Product Height (mm) 6.4 Product Weight (g) 26 Storage Temperature -20°C to 60°C (-4°F to 140°F) TAA Compliant No Wire Gauge 30/32 AWG Audio Specifications DisplayPort - 32 Channel Audio DisplayPort Version DP 2.1 - DP40 (UHBR10) HDR Support HDR10+ Maximum Data Transfer Rate 40 Gbps Maximum Digital Resolutions 8K 60Hz Supported Protocols USB Speed USB4 (40Gbps) USB Type and Rate USB4 (40Gbps) Active or Passive Adapter Passive Cable Jacket Material TPE - Thermoplastic Elastomers Cable Shield Material Copper Foil with Braid Conductors Twisted Pair Connector Plating Nickel Connectors Combo USB-C to USB-C Host or Charger Connector USB-C Peripheral Connector USB-C Carton Depth (mm) 457 Carton Height (mm) 228 Carton Weight Gross (g) 9270 Included in Package 1 - USB4 Cable - 40Gbps Package Depth (mm) 200 Package Height (mm) 160 Package Width (mm) 160 Package Weight (g) 37 Packaging Description 1.5ft USB4 Cable, 40Gbps, 240W PD, USB-IF Certified Packaging Description India 1.5ft USB4 Cable, 40Gbps, 240W PD, USB-IF Certified Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-C (40Gbps, 100W PD Input) Connector 1 (Quantity) 1 Connector 2 USB-C (40Gbps, 100W PD Input) Connector 2 (Quantity) 1 Actual Inbox Documents Created None Amazon Merchandising Manager Veronica Ye Amazon Only SKU No Apple Compatibility Apple Compatible Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge No Comparable SKU Comment NPI is twisted pair Comparable SKU 2 Comment NA en-US Content Approved Yes Graphic Designer Brooke Taylor ID Label Silkscreened or a Label No ID label Launch Markets (concatenated) CA,US Primary Technology USB4 (40Gbps) Priority New Product High Product Development Specialist Chi Zhang Product Manager Tim North Technology Lifecycle Latest
