CC6FT40GUSB4GEN3
USB4 Gen3 40Gbps Active Cable, 6ft
Enable 40Gbps USB4 performance and 8K video at distances up to 6ft using this active USB-C cable
Main Image
Enhanced Images
Product Images
Product Images
Product Images
Product Images
Product Name USB4 Gen3 40Gbps Active Cable, 6ft Product Number CC6FT40GUSB4GEN3 UPC 065030926843 Lifecycle status Pending Taxonomy Product > Cables > USB & Thunderbolt Cables Category Level 1 USB and Thunderbolt Cables Category Level 2 USB-C Cables Category Level 3 USB-C Cables - 40Gbps USB4 Family USB4 40Gbps Active Country of Origin Europe & Japan Vietnam Country of Origin North America Vietnam Country of Origin History (1) Vietnam Country of Origin Revision (1) XXXXXX190X Product Title (Ultra-Short) Active USB4 Cable Product Title (Short) 6ft Active USB4 Cable, 40Gbps, USB-C Product Title (Medium) 6ft (1.8m) Active USB4 Cable, 40Gbps, 240W, 8K 60Hz/4K 240Hz, Black USB-C Cable Product Title (Standard) 6ft (1.8m) Active USB4 Cable, 40Gbps, 240W, 8K 60Hz/4K 240Hz DP2.1, Thunderbolt 4 Compatible USB-C Cable, Black USB-C Cord Product Title (Long) 6ft (1.8m) Active USB4 Cable, 40Gbps, 240W PD, 8K 60Hz/4K 240Hz DP2.1 DP40, TPE Jacket, Thunderbolt 4 Compatible USB-C Cable - Black USB-C Cord Product Title (AMZ) 6ft (1.8m) Active USB4 Cable, 40Gbps, 240W, 8K 60Hz/4K 240Hz DP2.1, Thunderbolt 4 Compatible USB-C Cable, Black Title Ingram (Part 1) 6ft Active USB4 Cable, Black Title Ingram (Part 2) USB-C Cable/8K60/DP2.1/240W/40Gbps Website Product Headline Enable 40Gbps USB4 performance and 8K video at distances up to 6ft using this active USB-C cable Bullet 1 Bullet 2 Bullet 3 Bullet 4 Bullet 5 Bullets (Compact) 6ft/1.8m Active USB4 cable supports 40Gbps beyond passive cable lengths; DP 2.1 w/DSC supports 8K 60Hz/4K 240Hz; Integrated e-marker for safe and consistent PD charging; Ideal for USB-C and Thunderbolt laptops, docks, monitors, and external storage Bullets (Consolidated) - 6ft/1.8m Active USB4 cable supports 40 Gbps 8K video and 240W charging beyond the length of passive cables - Ideal for high power USB-C and Thunderbolt laptops including Apple M-series Pro/Max Macbook - Integrated e-marker for safe and consistent PD charging; Use connector markings to identify specs at-a-glance; TPE jacket w/Nickel-plated connectors - Suitable for USB-C, Thunderbolt laptops/docks/monitors/high-speed storage - USB 40Gbps; 8K 60Hz/4K 240Hz; DisplayPort 2.1 w/DSC; 240W PD 3.1 Marketing Copy Marketing Copy (No HTML) Applications - Designed for seamless operation with USB-C or Thunderbolt 4 docking stations
- Drive sharp 8K 60Hz video or support dual 4K 120Hz UHD displays with DSC
- Transfer data at 40 Gbps speeds and 240W of power over a USB4 connection
- Power and charge USB4/USB-C, and Thunderbolt devices
Website Search Keyword - USB4 Cable
- USB-C Cable
- Laptop Charging Cable
- Apple M3 MacBook Cable
- Apple M3 Max
- 18in USB C Cable
- 0.5m USB-C Cable
- CC2M40GUSB4GEN3
Required Regulatory Compliance Marks - CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- UKCA - Environmental - United Kingdom - UK Restriction of Hazardous Substances (RoHS) 2012
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Non-Corrugated Fiberboard
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
Related Products - CC2M40GUSB4GEN3
- CC18IN40GUSB4TP
- CC1M40GUSB4TP
- CC50CM40GUSB4TP
- CC18IN40GUSB4TPW
- CC1M40GUSB4TPW
Input Current 5A Power Delivery 240W Cable Length (mm) 1800 Cable OD 4.8 Color Black Connector Style Straight Humidity 40 - 65% RH Material Santoprene - Thermoplastic Rubber (TPE) Operating Temperature 0°C to 60°C (32°F to 140°F) Product Length (mm) 1830 Product Width (mm) 12.7 Product Height (mm) 6.9 Product Weight (g) 90 Storage Temperature -20°C to 60°C (-4°F to 140°F) TAA Compliant No Wire Gauge 32/34 AWG Audio Specifications DisplayPort - 32 Channel Audio DisplayPort Version DP 2.1 - DP40 (UHBR10) HDR Support HDR10+ Maximum Data Transfer Rate 40 Gbps Maximum Digital Resolutions 8K 60Hz Supported Protocols USB Speed USB4 (40Gbps) USB Type and Rate USB4 (40Gbps) Active or Passive Adapter Active Cable Jacket Material TPE - Thermoplastic Elastomers Cable Shield Material Copper Foil with Braid Conductors Coaxial Connector Plating Nickel Connectors Combo USB-C to USB-C Host or Charger Connector USB-C Peripheral Connector USB-C Carton Depth (mm) 540 Carton Height (mm) 215 Carton Quantity 80 Carton Weight Gross (g) 11520 Included in Package 1 - Active USB4 Cable - 40Gbps Number of Sub-Cartons 8 Package Depth (mm) 230 Package Height (mm) 30 Package Width (mm) 80 Package Weight (g) 104 Packaging Description 6ft Active USB4 Cable, 40Gbps, 240W PD Packaging Description India 6ft Active USB4 Cable, 40Gbps, 240W PD Sub-Carton Depth (mm) 260 Sub-Carton Height (mm) 95 Sub-Carton Width (mm) 240 Sub-Carton Quantity 10 Sub-Carton Weight (g) 1340 Connector 1 USB-C (40Gbps, 100W PD Input) Connector 1 (Quantity) 1 Connector 2 USB-C (40Gbps, 100W PD Input) Connector 2 (Quantity) 1 A+ Not Required Amazon Merchandising Manager Veronica Ye Amazon Only SKU No Amazon Visual Content Level Gold Application Photos Uploaded Artwork Due Date 2025-10-16 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge No Comparable SKU Comment Comp not active entended, shorter Comparable SKU 2 Comment NA Digital Content Due Date 2025-12-17 Enhanced Gallery Required Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level - 1 Graphic Designer Brooke Taylor Graphic Design SKU Logic Naming Convention CCxM40GUSB4GEN3 ID Label Silkscreened or a Label No ID label Launch Markets (concatenated) CA,IN,US Primary Technology USB4 (40Gbps) Priority New Product High Product Development Specialist Chi Zhang Product Information Creation Specialist (PICS) Brian Chan Product Manager Tim North Product Performance Specialist Aaron Bens Product Photographer Caleigh Le Grand Target Development Completion Date 2025-09-05 Target Production Release 2025-10-31 Tech Lead Justin Weaver Technical Writer Brian Chan Technology Lifecycle Latest Video Not Required
