Main Image
CDP2DP14UCPB
USB C to DisplayPort 1 4 adapter HBR3 black with PD
DisplayPort™ 1.4 Adapter | Thunderbolt™ 3 Compatible | HBR3 | 60W PD
Main Image
Product Images
Product Images
Product Images
BOM Image
Product Name USB C to DisplayPort 1 4 adapter HBR3 black with PD Product Number CDP2DP14UCPB UPC 065030883641 Lifecycle status Active Warranty 3 Years Taxonomy Product > Docks, Hubs & Video Adapters > Video Adapters Category Level 1 Display and Video Adapters Category Level 2 USB-C Display Adapters Category Level 3 USB-C to DP - 8K HDR Family USBC to DP 1.4 Adapters, DP Alt Mode, 8K60 Country of Origin Europe & Japan China Country of Origin North America Vietnam Country of Origin History (1) China Country of Origin Revision (1) XXXXXX012X Country of Origin History (2) Vietnam Country of Origin Revision (2) XXXXXX190X Product Title (Ultra-Short) USB C to DP Adapter Product Title (Short) USB C to DisplayPort Adapter w/ PD 8K/4K Product Title (Medium) USB C to DisplayPort Adapter - Power Delivery - 8K 60Hz - HBR3 Product Title (Standard) USB C to DisplayPort Adapter with 60W Power Delivery Pass-Through - 8K/4K USB Type-C to DP 1.4 Video Converter w/ Charging Product Title (Long) USB C to DisplayPort Adapter with Power Delivery - 8K 60Hz /4K 120Hz USB Type C to DP 1.4 Video Converter w/ 60W PD Pass-Through Charging - HBR3 - Thunderbolt 3 Compatible Product Title (AMZ) USB C to DisplayPort Adapter with Power Delivery - 8K 60Hz /4K 120Hz USB Type C to DP 1.4 Video Converter w/ 60W PD Pass-Through Charging - HBR3 - Thunderbolt 3 Compatible (CDP2DP14UCPB) Title Ingram (Part 1) USB C to DisplayPort Adapter Title Ingram (Part 2) Power Delivery - 8K 60Hz - HBR3 Website Product Headline DisplayPort™ 1.4 Adapter | Thunderbolt™ 3 Compatible | HBR3 | 60W PD Bullet 1 HIGH PERFORMANCE: USB-C to DisplayPort 1.4 (DP Alt Mode HBR3) (32.4Gbps) adapter to connect a single DP display supporting 8K 60Hz (7680x4320) or 4K 120Hz UHD - HDR/DisplayHDR - DSC - HDCP 2.2/1.4 - Works with systems that support DP Alt Mode over USB-C Bullet 2 COMPATIBILITY: Works w/ DP over USB Type-C (Thunderbolt 3 compatible) laptops including MacBooks and Chromebooks and supports up to 60W Power Delivery to power & charge your laptop while displaying video on a DisplayPort monitor Bullet 3 IMAGE QUALITY: This adapter features a unique video signal booster which amplifies the signal and ensures reliable performance, even with lower quality cables - The amplifier also increases the max. supported DP cable length compared to other brands Bullet 4 EXPERIENCE 8K: USB C to DisplayPort adapter was tested with 8K monitors, displays & compliance test hardware/software for optimal performance & color depth for high res imaging & content creators Bullet 5 EASY TO USE: USB C to DP adapter supports a driverless plug & play setup - Works with macOS, iPadOS, Windows, Chrome OS & Linux - Compatible with Thunderbolt 3 & previous versions of DisplayPort Bullets (Compact) USB-C to DisplayPort 1.4 video adapter converter 8K 60Hz/4K 120Hz/1080p; HDR/HBR3/DSC/HDCP 2.2/1.4 - 60W Power Delivery pass-through charging - Tested for 8K performance - USB Type C DP Alt Mode/Thunderbolt 3 devices - Driverless OS independent Bullets (Consolidated) USB-C to DisplayPort 1.4 (32.4Gbps) adapter with Power Delivery | 8K 60Hz/4K 120Hz; HDR/HBR3/DSC/HDCP 2.2/1.4 - USB-C DP alt mode video converter w/ 60W PD pass-through laptop charging while connected to a DP monitor - Unique signal booster for reliable performance even with lower-quality or longer cables | For USB-C DP Alt Mode/Thunderbolt 3 laptops like Lenovo/Dell/HP/Surface Chromebooks and MacBooks - Tested w/ 8K displays + compliance test hardware/software | Driverless setup Marketing Copy Marketing Copy (No HTML) Applications - Stream lifelike 8K video to a DisplayPort 1.4 monitor, projector or display
- Display crisp digital signage walls
- Ultimate accessory for early adopters of 8K technology
- Deliver eye-catching presentations while you’re on the go
- Connect USB-C devices to HDR capable 8K displays
- Perfect for creative professionals
Website Search Keyword - 4K
- 4k displayport adapter
- 5K
- 60Hz
- 8K
- adapter displayport
- adapter for usb c
- adapter usb c to displayport
- display adapter
- DisplayPort
- displayport 1.4 adapter
- displayport 1.4 hdr
- displayport 1.4 to usb c
- displayport 4k
- displayport adapter
- displayport adapter 4k
- displayport adapter usb c
- displayport alt mode
- displayport alternate mode
- displayport dongle
- displayport hbr3
- displayport over type c
- displayport over usb c
- displayport over usb type c
- displayport to usb c adapter
- displayport usb c adapter
- displayport version 1.4
- dp adapter
- dp hbr3
- dp monitor adapter
- dp to usb c adapter
- hdr displayport
- thunderbolt displayport
- type c adapter
- type c to displayport adapter
- type c to dp adapter
- usb 3.0 adapter
- usb 3.1 adapter
- usb 3.1 displayport
- usb 3.1 gen 1 adapter
- usb 3.1 type c
- usb 3.1 type c to displayport adapter
- usb c 4k
- usb c adapter
- usb c adapter with power delivery
- usb c display adapter
- usb c displayport
- usb c dongle displayport
- usb c over displayport
- usb c to displayport
- usb c to displayport 1.4
- usb c to displayport 4k 60hz
- usb c to displayport adapter
- usb c to displayport dongle
- usb c to dp adapter
- usb c to dp dongle
- usb dongle
- usb to displayport
- usb to displayport adapter
- usb to dp adapter
- usb type c power delivery
- usb type c to displayport adapter
- usb type c to dp adapter
- USB-C
- video adapter
- U444-06N-DP8WC
Required Regulatory Compliance Marks - CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- Triman/Info-Tri - Packaging - Waste - European Union - Plastic Bag
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Plastic - Low-Density Polyethylene
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
System and Cable Requirements - Your USB-C port must support DisplayPort over USB-C (DP Alt Mode) in order to work with this adapter.
- To achieve 8K resolutions, your source and your destination must support DisplayPort 1.4.
Accessory Products - DP14MM1M
- DP14MM2M
- DP14MM3M
- DP14MM5M
Related Products - CDP2DP146B
- CDP2DP141MB
- CDP2DPMM6B
- CDP2DPMM1MB
- CDP2DP
- CDP2DPW
- MSTCDP122DP
- MSTCDP123DP
- CDP2HDUCPW
- CDP2HD4K60W
- CDP2HDMM2MB
- CDP2HD
- CDP2HDW
- CDP2HDMM1MB
- CDP2VGAMM1MB
- CDP2DVIMM1MB
- CDP2HD4K60
- CDP2VGA
- CDP2VGAMM2MB
- CDP2VGAW
Power Delivery 60W Cable Length (mm) 110 Color Black Humidity 10%-85% RH Material Plastic Operating Temperature 5°C to 45°C (41°F to 113°F) Primary Material Plastic Product Length (mm) 190 Product Width (mm) 43 Product Height (mm) 11.500 Product Weight (g) 22.000 Storage Temperature -10°C to 70°C (14°F to 158°F) TAA Compliant No Audio Specifications DisplayPort - 7.1 Channel Audio Bandwidth HBR3 HDR Support Yes Maximum Cable Distance To Display 2000 Maximum Supported Resolution 8K 60Hz (DSC) OS Compatibility - Windows 7
- Windows 8
- Windows 10
- macOS Sierra (10.12)
- macOS High Sierra (10.13)
- macOS Mojave (10.14)
- macOS Catalina (10.15)
- macOS Big Sur (11.0)
- Windows 11
- macOS Monterey (12.0)
- macOS Ventura (13.0)
- macOS Sonoma (14.0)
- Windows 11 ARM
- macOS Sequoia (15.0)
- macOS Tahoe (26.0)
Supported Resolutions DisplayPort: 7680x4320 (8K) / 60Hz Video Output Port DisplayPort Wide Screen Supported Yes Active or Passive Adapter Active AV Input USB-C AV Output DisplayPort - 1.4 Chipset ID Converter Type Adapters Host Connection Port USB-C Number of Displays 1 Amount of recycled material in plastic packaging At Least 30% Carton Depth (mm) 300 Carton Height (mm) 210 Carton Quantity 200 Carton Weight Gross (g) 6650 Included in Package 1 - USB-C to DisplayPort Adapter Number of Sub-Cartons 20 Package Depth (mm) 128 Package Height (mm) 15 Package Width (mm) 220 Package Quantity 1 Package Weight (g) 26 Packaging Description USB-C to DisplayPort HBR3 Adapter - PD - 8K Packaging Description India USB-C to DisplayPort HBR3 Converter - PD - 8K Sub-Carton Depth (mm) 141 Sub-Carton Height (mm) 65 Sub-Carton Width (mm) 265 Sub-Carton Quantity 10 Sub-Carton Weight (g) 278 Connector 1 USB-C DP++ (DP Alt-Mode) Connector 1 (Quantity) 1 Connector 2 DisplayPort Connector 2 (Quantity) 1 Connector 3 USB-C (100W PD Only) Connector 3 (Quantity) 1 Amazon Merchandising Manager Kristian Haighton Artwork Due Date 2019-10-24 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge No Digital Content Due Date 2019-11-07 Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett ID Label Silkscreened or a Label Silkscreened label - requires dieline showing location Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FI,FR,HK,IE,IN,IT,JP,MX,NL,NZ,PE,SE,SG,UK,US Primary Technology USB-C Priority New Product N/A Product Development Specialist Abhinav Pathak Product Information Creation Specialist (PICS) Dan Dagenais Product Manager David Muzinic Product Performance Specialist John Mardinly Product Photographer Caleigh Le Grand Target Development Completion Date 2019-10-30 Target Production Release 2019-10-24 Tech Lead Brian Linseman Technical Writer Evan Hanbidge Technology Lifecycle Mainstream
