CDP2HDUCPW
USB Type-C to HDMI Adapter - USB-C Power Delivery
Using a single USB Type-C port on your laptop, output HDMI video and charge the laptop
Main Image
Product Images
Product Images
Product Images
Product Images
Product Name USB Type-C to HDMI Adapter - USB-C Power Delivery Product Number CDP2HDUCPW UPC 065030868938 Lifecycle status End of Life Warranty 3 Years Taxonomy Product > Docks, Hubs & Video Adapters > Video Adapters Category Level 1 Display and Video Adapters Category Level 2 USB-C Display Adapters Category Level 3 USB-C to HDMI Family USBC to HDMI 2.0 Adapters, DP Alt Mode, 4K60 Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX031X Product Title (Ultra-Short) USB-C to HDMI Product Title (Short) USB C to HDMI 2.0 Adapter Power Delivery Product Title (Medium) USB-C to HDMI Video Adapter with USB Power Delivery - 4K 60Hz USB Type-C to HDMI Product Title (Standard) USB C to HDMI 2.0 Adapter 4K 60Hz with 60W Power Delivery Pass-Through Charging - USB Type-C to HDMI Video Converter - White Product Title (Long) USB C to HDMI 2.0 Adapter with Power Delivery - 4K 60Hz USB Type-C to HDMI Display Video Converter - 60W PD Pass-Through Charging Port - Thunderbolt 3 Compatible - White Product Title (AMZ) USB C to HDMI 2.0 Adapter with Power Delivery - 4K 60Hz USB Type-C to HDMI Display Video Converter - 60W PD Pass-Through Charging Port - Thunderbolt 3 Compatible - White (CDP2HDUCPW) Title Ingram (Part 1) USB-C to HDMI Adapter - 4K 60Hz Title Ingram (Part 2) - USB Type-C HDMI Power Delivery Website Product Headline Using a single USB Type-C port on your laptop, output HDMI video and charge the laptop Bullet 1 HIGH PERFORMANCE: USB-C (DP 1.2 Alt Mode) to HDMI 2.0 active adapter lets you connect a single HDMI display supporting 4K 60Hz UHD (4096x2160/3840x2160) - compatible w/ HDCP 2.2/1.4 & Thunderbolt 3 Bullet 2 60W PD PASS THROUGH CHARGING: This white USB-C video converter with PD allows up to 60W Power Delivery to power & charge your laptop while displaying video on an HDMI display using a single USB-C port Bullet 3 COMPATIBILITY: Works w/ DisplayPort over USB Type-C (TB3 compatible) laptops like Lenovo ThinkPad X1 Carbon, Dell XPS 13, HP EliteBook, TB3 MacBook Pro 13 / Air, Surface Book 3/Laptop 3, Chromebook Bullet 4 DISPLAY COMPATIBILITY: Tested for peak performance at 4K 60Hz on HDMI monitors, projectors and HDTVs incl Dell, Samsung, LG, Asus, Acer, BenQ, Sony, NEC & Epson - backward compatible w/ 1080p Bullet 5 EASY TO USE: USB C to HDMI adapter supports a driverless plug & play setup & works w/ macOS, iPadOS, Windows, Chrome OS & Linux - Compatible w/ Thunderbolt 3 & previous versions of DisplayPort Bullets (Compact) White USB Type C (DP 1.2 Alt Mode) to HDMI 2.0 video display adapter converter 4K 60Hz UHD; HDCP 2.2/1.4 - 60W Power Delivery pass-through charging - Thunderbolt 3 Compatible - Tested w/ HDMI monitors, projectors & HDTVs - Driverless OS independent Bullets (Consolidated) USB-C (DP 1.2 Alt Mode) to HDMI 2.0 adapter with Power Delivery | HDCP 2.2/1.4; 4K 60Hz (4096x2160/1080p) - USB-C video converter w/ 60W Power Delivery (PD) pass-through laptop charging while connected to a display -Works w/ USB Type-C or Thunderbolt 3 laptops like Lenovo ThinkPad X1 Carbon/Dell XPS/HP EliteBook/TB3 MacBook Pro Air/Surface Book 3 Laptop 3 - Tested @ 4K 60Hz w/ Dell/Samsung/LG/Asus/Acer/BenQ/Sony/NEC/Epson monitors/projectors - No Drivers Windows/macOS/iPadOS/Chrome OS/Linux Marketing Copy Marketing Copy (No HTML) This USB-C to HDMI adapter enables you to connect your laptop or MacBook with USB Type-C to an HDMI display. The video adapter features USB Power Delivery, so you can power your laptop while simultaneously outputting video to an HDMI display. USB Type-C is a universal connectivity standard that combines all of your essential functions into one dynamic port. This video adapter works with USB-C devices that pass a DisplayPort video signal, such as the MacBook and Chromebook Pixel™ and it's also compatible with Thunderbolt 3 ports. With its all-white design, this USB-C video adapter is the perfect accessory for your USB-C equipped MacBook. The adapter is compact and lightweight, so it fits easily into your MacBook bag or carrying case, which is great for BYOD (Bring Your Own Device) applications at the office. While the adapter looks great next to your MacBook or HP ENVY laptop, it also works with any USB-C computer that supports DisplayPort ALT mode, such as your Windows® laptop. This video adapter supports USB Power Delivery and features an additional USB-C port. This means you can charge your laptop, even while outputting video, by simply connecting the laptop's power adapter to the additional port. It's the perfect solution for laptops that only have a single USB-C port. At four times the resolution of high-definition 1080p, you'll be amazed at the picture quality of a 4K monitor or television. The adapter lets you harness the video capabilities that are built into your USB Type-C connection to deliver the astonishing quality of Ultra HD to your 4K display. 4K resolution gives you additional screen space to simplify your approach to detailed work such as editing video and viewing large spreadsheets. Even if you're not running 4K, the adapter supports high-definition 1080p and lower resolutions. The CDP2HDUCPW is backed by a 3-year StarTech.com warranty and free lifetime technical support. Applications - Charge your USB Type-C laptop and output video using the same USB-C port
- Carry the adapter with you when you travel, and connect to any HDMI TV, monitor or projector
- Connect to BYOD (Bring Your Own Device) and CYOD (Choose Your Own Device) workstations at your office
Website Search Keyword U444-06N-H4K6WC Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
Accessory Products - HDMM3
- HDMM6
- HDMM10
- HDMM15
Related Products - CDP2HDUACPW
- CDP2VGA
- CDP2VGAW
- CDP2HD
- CDP2HDW
- CDP2DP
- CDP2VGAUCP
- CDP2HDUCP
- CDP2VGAUCPW
Constrained SKU Alternatives (Limited Stock) - CDP2HDUCP
- USBC-HDMI-CDP2HD4K60
Power Delivery 60W Cable Length (mm) 100 Color White Humidity 0~90% RH Material Plastic Operating Temperature 0°C to 40°C (32°F to 104°F) Primary Material Plastic Product Length (mm) 50 Product Width (mm) 33 Product Height (mm) 13 Product Weight (g) 22 Storage Temperature -20°C to 70°C (-4°F to 158°F) TAA Compliant No Audio Specifications HDMI - 7.1 Channel Audio HDR Support No Maximum Cable Distance To Display 7000 Maximum Digital Resolutions 3840 x 2160 @ 60Hz Maximum Supported Resolution 4K 60Hz (3840x2160) MTBF (hours) 363,013 hours OS Compatibility OS Independent Supported Resolutions Video Output Port HDMI Wide Screen Supported Yes AV Input USB-C AV Output HDMI - 2.0 Chipset ID Converter Type Adapters Host Connection Port USB-C Number of Displays 1 Carton Depth (mm) 336 Carton Height (mm) 320 Carton Quantity 40 Carton Weight Gross (g) 4934 Included in Package 1 - USB-C to HDMI adapter Package Depth (mm) 144 Package Height (mm) 31 Package Width (mm) 175 Package Quantity 1 Package Weight (g) 108 Packaging Description USB-C™ to HDMI® Adapter with Charge Port - White Packaging Description India USB-C™ to HDMI® Converter with Charge Port - White Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-C DP++ (DP Alt-Mode) Connector 1 (Quantity) 1 Connector 2 HDMI Connector 2 (Quantity) 1 Amazon Merchandising Manager Kristian Haighton Artwork Due Date 2016-11-29 Buying Center - AV & Collaboration Yes Buying Center - End User Compute Yes Buying Center - Networking & Edge No Digital Content Due Date 2017-01-17 Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FR,IE,IN,IT,JP,NL,NZ,PE,SE,SG,UK,US Primary Technology USB-C Product Development Specialist Abhinav Pathak Product Information Creation Specialist (PICS) Dan Dagenais Product Manager David Muzinic Product Performance Specialist John Mardinly Product Photographer Caleigh Le Grand Target Development Completion Date 2016-11-11 Target Production Release 2016-12-09 Tech Lead Brian Linseman Technical Writer Dan Dagenais Technology Lifecycle None
