Main Image
CDP2HVGUASPD
USB C to HDMI VGA GbE USB A PD 3 0 and Presentation Mo
USB-C Multiport Adapter | USB 3.2 Gen 2 (10Gbps) | 4K HDMI or 1080p VGA | Presentation Mode Switch | 100W PD 3.0 Pass Through
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
Quick-Start Guide
Product Name USB C to HDMI VGA GbE USB A PD 3 0 and Presentation Mo Product Number CDP2HVGUASPD UPC 065030875493 Lifecycle status Active Warranty 3 Years Taxonomy Product > Docks, Hubs & Video Adapters > Docking Stations & Multiports Category Level 1 Multiport Adapters Category Level 2 USB-C Multiport Adapters Category Level 3 USB-C Multiport Adapters - 10Gbps Family USB-C Multiport Adapters - 10Gbps - Single Video - 6-8 ports Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX028X Country of Origin History (2) Vietnam Country of Origin Revision (2) XXXXXX132X Product Title (Ultra-Short) USB C Mini Dock 4K Product Title (Short) USB C Multiport Adapter 10Gbps, HDMI/VGA Product Title (Medium) USB C Multiport Adapter - 4K HDMI or VGA/ 100W PD Pass-through, 10Gbps/MicroSD Product Title (Standard) USB C Multiport Adapter, USB-C to 4K HDMI or VGA Video with 100W PD Pass-through, 10Gbps USB Hub/MicroSD/GbE, USB-C Mini Dock Product Title (Long) USB C Multiport Adapter - USB-C to 4K HDMI or VGA Video with 100W Power Delivery Pass-through, 2-Port 10Gbps USB Hub, MicroSD, GbE - USB 3.1 Type-C Mini/Travel Dock Product Title (AMZ) USB C Multiport Adapter - USB-C to 4K HDMI or VGA Video with 100W Power Delivery Pass-through, 2-Port 10Gbps USB Hub, MicroSD, GbE - USB 3.1 Type-C Mini/Travel Dock (CDP2HVGUASPD) Title Ingram (Part 1) 4K USB C Multiport Adapter HDMI Title Ingram (Part 2) 4K HDMI/VGA/Power Delivery/10Gbps Website Product Headline USB-C Multiport Adapter | USB 3.2 Gen 2 (10Gbps) | 4K HDMI or 1080p VGA | Presentation Mode Switch | 100W PD 3.0 Pass Through Bullet 1 7-IN-1 FUNCTIONALITY: USB-C multiport adapter with 4K 30Hz Ultra HD HDMI/1080p VGA video/display/monitor, 2-Port 10Gbps USB Hub with 1x USB-A (BC 1.2 fast charge port) and 1x USB-C (PD or data), 100W Power Delivery pass through, microSD, Gigabit Ethernet Bullet 2 PRESENTATION MODE SWITCH: When switch is enabled, the adapter prevents your computer from launching its screen saver, going to sleep, or entering power save mode; Prevents interruptions while presenting or sharing your screen for long periods of time Bullet 3 RELIABLE PERFORMANCE: USB bus powered or via external USB-C power adapter; 100W Power Delivery 3.0 pass through w/ 15W reserved for adapter to avoid video flickering, device dropouts or overdrawing power common in other hubs; up to 85W for laptop charging Bullet 4 PORTABLE & DURABLE: This aluminum USB-C mini dock with USB 3.2 Gen 2 10Gbps Hub is lightweight for easy on-the-go use between office, working from home, and business travel; Hideaway cable to prevent tangles & microSD slot for mobile file storage Bullet 5 WIDE COMPATIBILITY: USB Type-C multiport adapter for USB-C ultrabooks, Chromebooks, tablets like iPad Pro and Surface Pro 7 & Thunderbolt 3 laptops like HP, Dell, Lenovo, MacBooks; Windows, macOS, iPadOS, Chrome OS, Android; Automatic driver setup Bullets (Compact) USB-C multiport adapter 10Gbps with 4K HDMI / VGA, USB-A (Fast Charge), USB-C, microSD, GbE - Presentation mode switch - Bus powered or USB Type-C power adapter - USB C mini dock w/100W Power Delivery passthrough - Windows/macOS/iPadOS/Chrome/Android Bullets (Consolidated) USB-C multiport adapter with 4K HDMI or 1080p VGA video/display/monitor/10Gbps USB 3.2 Gen 2 Hub with 1x USB-A (BC 1.2 fast charge port) and 1x USB-C (PD or Data)/microSD/Gigabit Ethernet - Presentation mode switch prevents computer from launching screen saver/entering power save mode - Bus powered or via external USB-C power adapter - USB Type-C mini dock w/ 100W Power Delivery pass through (15W for dock/up to 85W for laptop charging) - Windows/macOS/iPadOS/Chrome/Android | Auto drivers Marketing Copy Website Search Keyword - 4k 30hz
- 4k usb c to hdmi
- 4k30
- aluminum adapter
- Boardroom
- Built-in wrap around usb c cable
- bus powered usb c mulitport adapter
- cable management
- commercial display
- commercial monitor
- digital av multiport adapter
- digital display
- durability
- hdmi multiport adapter
- HDR Monitor
- kiosk display
- Laptop
- large format display
- macbook pro
- macbook pro usb c adapter
- multiport adapter
- multiport video adapter
- network gigabit ethernet
- On/Off option
- pd 3.0
- portable
- portable docking station
- portable docking station for laptop
- power delivery
- power delivery 3.0
- Premium
- presentation
- presentation adapter
- Presentation mode
- presentation mode switch
- professional monitor
- stay awake
- stay awake adapter
- switch
- toggle switch adapter
- travel
- TV display
- type c hdmi plus USB 3.0
- usb 3.1 gen 2 dock
- usb 3.1 gen 2 type c dock
- usb 3.1 type c power delivery
- usb c accessories for macbook
- usb c adapter
- usb c adapter hdmi usb
- usb c adapter hub
- usb c adapter vga usb
- usb c adapter with dp alt mode
- usb c adapter with laptop charging
- usb c adapter with PD 3.0
- usb c adapter with power delivery
- usb c all in one adapter
- usb c av multiport adapter
- usb c charging port
- usb c digital av multiport adapter
- usb c dock power delivery
- usb c dock with power delivery
- usb c docking station power delivery
- usb c dongle
- usb c hdmi + power delivery
- usb c hdmi + usb 3.0 adapter
- usb c hdmi adapter
- usb c hdmi usb adapter
- usb c hdmi with usb-a port
- usb c hub
- usb c hub hdmi ethernet
- usb c hub multiport adapter
- usb c hub vga
- usb c hub vga ethernet
- usb c hub with charging port
- usb c hub with ethernet
- usb c hub with ethernet and hdmi
- usb c hub with ethernet and vga
- usb c hub with hdmi
- usb c hub with hdmi and ethernet
- usb c hub with power delivery
- usb c hub with vga
- usb c hub with vga and ethernet
- usb c mini dock
- usb c multiport
- usb c multiport adapter
- usb c multiport adapter ethernet
- usb c multiport adapter hdmi
- usb c multiport adapter vga
- usb c multiport adapter with ethernet
- usb c multiport adapter with hdmi
- usb c multiport adapter with hdmi and ethernet
- usb c multiport adapter with hdmi and vga
- usb c multiport adapter with vga
- usb c multiport adapter with vga and ethernet
- usb c multiport hub
- usb c multiport power delivery
- usb c multiport video adapter
- usb c pd
- usb c power delivery
- usb c to 4k hdmi adapter
- usb c to av adapter
- usb c to ethernet
- usb c to ethernet adapter
- usb c to gigabit ethernet
- usb c to gigabit ethernet adapter
- usb c to HDMI
- usb c to hdmi + usb
- usb c to hdmi 4k
- usb c to hdmi adapter
- usb c to hdmi and usb adapter
- usb c to hdmi and vga adapter
- usb c to hdmi multiport adapter
- usb c to HDMI or VGA
- usb c to hdmi usb
- usb c to hdmi vga adapter
- usb c to hdmi with pd
- usb c to hdmi with stay awake
- usb c to usb 3.0
- usb c to usb 3.0 adapter
- usb c to usb adapter
- usb c to vga
- usb c to vga adapter
- usb c to vga and usb
- usb c to vga multiport adapter
- usb c travel dock
- usb c vga hdmi adapter
- usb c vga usb adapter
- usb c video adapter
- usb pd 3.0
- usb power delivery
- usb type c hub
- usb type c multiport adapter
- usb type c pd
- usb type c power delivery
- usb type c to hdmi
- usb type c to hdmi adapter
- usb type c to hdmi usb
- usb type c to usb 3.0
- usb type c to vga
- usb type c to vga adapter
- usb type c to vga usb
- vga multiport adapter
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- UKCA - Environmental - United Kingdom - UK Restriction of Hazardous Substances (RoHS) 2012
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- TSCA - Environmental - United States - EPA TSCA Title VI Compliant
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- Triman/Info-Tri - Manual - Waste - European Union - Print Paper
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + paper tray/divider
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
Special Notes Power Source Note: USB-C power adapter not included Accessory Products - MXT101MMHQ1
- MXT101MMHQ3
- MXT101MMHQ
- MXT101MMHQ10
- MXT101MMHQ20
- MXT101MMHQ25
- USB31C5C1M
- USB315CC2M
- USB2C5C4M
- UUSBHAUB1
- UUSBHAUB3
- UUSBHAUB6
- N6LPATCH3BK
- WCH1C
- HDMM6
Related Products - DKT30CHV
- CDP2HDUACP
- DKT30CHPD
- DKT30CSDHPD
- DKT30CHVW
- DKT30CHD
- DKT30CDVPD
- DKT30CHPDW
- CDP2HDUACPW
- MST30C2DPPD
Power Consumption (In Watts) 15W Power Delivery 100W Power Source Bus Powered and Host USB-C Power Adapter Cable Length (mm) 130 Color Black & Gray Humidity 5% to 90% RH (no condensation) Material Aluminum and Plastic Operating Temperature 0℃ to+70℃ Product Length (mm) 68.000 Product Width (mm) 125.000 Product Height (mm) 16.000 Product Weight (g) 126.000 Storage Temperature -10℃ to +55℃ TAA Compliant No Compatible Networks 10/100/1000 Mbps Device Power Consumption (In Watts) 15W Downstream Maximum Data Transfer Rate USB 3.2 Gen 2 (10Gbps) General Specifications - Wake-On-LAN (WoL): Yes
- Presentation Mode Switch: Left Position Enables Stay Awake</br> Right Position Disables Stay Awake
Maximum Analog Resolutions 1920 x 1080p @ 60Hz Maximum Digital Resolutions 3840 x 2160P @ 30Hz Maximum Supported Resolution 4K 30Hz (3840x2160) MTBF (hours) 307, 402 OS Compatibility - Windows 10
- Windows 8
- Windows 7
- macOS Big Sur (11.0)
- Chrome OS
- Windows 11
- macOS Monterey (12.0)
- macOS Ventura (13.0)
- macOS Sonoma (14.0)
- Windows 11 ARM
- macOS Sequoia (15.0)
- macOS Tahoe (26.0)
PXE Yes StarTech.com Connectivity Tools - MAC Address Changer
- USB Event Monitoring
- Windows Layout
- Wi-Fi Auto Switch
Video Output Port - HDMI
- VGA
Video Transport Technology USB-C (DP Alt-Mode) Wake-On-LAN (WOL) Yes Bus Type - USB-C
- USB-A
Chipset ID - Realtek - RTD2141DS
- Realtek - RTS5423
- Realtek - RTL8153B
- Realtek - RTS5306
Host Connection Port USB-C Industry Standards - 1 Gigabit connectivity to any 1000BASE-T device (IEEE802.3ab compliant)
- 100 Megabit connectivity to any 100BASE-TX device (IEEE802.3u compliant)
- 10 Megabit connectivity to any 10BASE-T device (IEEE802.3i compliant)
Interface/Bridge USB 10Gbps Laptop Dock 4K Support Yes Laptop Dock Number of Displays 1 Laptop Dock / USB Hub Fast-Charge Yes LED Indicators 2 - Network Indicators (RJ-45 Port): Link (Green), Activity (Amber) Network Adapter LAN Ports 1 Number of Battery Charge 1.2 Ports 1 Number of Displays 1 Other Ports - Gigabit Ethernet
- SD Card Reader
USB Pass-Through Yes Carton Depth (mm) 473 Carton Height (mm) 440 Carton Quantity 70 Carton Weight Gross (g) 14500 Included in Package - 1 - USB-C Multiport Adapter
- 1 - Quick-Start Guide
Package Depth (mm) 145 Package Height (mm) 32 Package Width (mm) 172 Package Quantity 1 Package Weight (g) 190 Packaging Description USB-C 10G HDMI/VGA Adapter w/ Presentation Mode Switch Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Actual Inbox Documents Created QSG in the box Amazon Merchandising Manager Veronica Ye Artwork Due Date 2020-11-12 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge No Digital Content Due Date 2022-05-20 Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett ID Label Silkscreened or a Label No ID label Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,FI,FR,IE,IN,IT,JP,NL,NZ,PE,SE,SG,UK,US Primary Technology USB-C Product Development Specialist Abhinav Pathak Product Information Creation Specialist (PICS) Dan Dagenais Product Manager Natalie Goodale Product Performance Specialist John Mardinly Product Photographer Caleigh Le Grand Target Development Completion Date 2021-03-02 Target Production Release 2021-03-11 Tech Lead Sam Raskas Technical Writer Dan Dagenais Technology Lifecycle Mainstream
