Main Image
CDP2MDPVGA
USB-C to VGA or mDP 2-in-1 Adapter
High Dynamic Range | Aluminum | 6" (15.24 cm) Built-In Cable
Main Image
Product Images
Product Images
Product Images
BOM Image
Product Name USB-C to VGA or mDP 2-in-1 Adapter Product Number CDP2MDPVGA UPC 065030884518 Lifecycle status End of Life Warranty 3 Years Taxonomy Product > Docks, Hubs & Video Adapters > Video Adapters Category Level 1 Display and Video Adapters Category Level 2 USB-C Display Adapters Category Level 3 USB-C Travel Adapters Family USBC to Multiport Display Adapters, DP Alt Mode, 4K60 Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX028X Product Title (Ultra-Short) USB C to mDP or VGA Product Title (Short) USB C Multiport Video Adapter to MDP/VGA Product Title (Medium) USB C Multiport Video Adapter - VGA or Mini DisplayPort - HDR 4K Display Adapter Product Title (Standard) USB C Multiport Video Adapter - USB-C to 4K 60Hz Mini DisplayPort 1.2 (HBR2 HDR) or 1080p VGA Monitor Display Adapter Product Title (Long) USB C Multiport Video Adapter - USB-C to 4K 60Hz Mini DisplayPort 1.2 or 1080p VGA Monitor Adapter - USB Type-C 2-in-1 MDP HBR2 HDR/VGA Display Converter - TB3 Compatible Product Title (AMZ) USB C Multiport Video Adapter - USB-C to 4K 60Hz Mini DisplayPort 1.2 or 1080p VGA Monitor Adapter - USB Type-C 2-in-1 MDP HBR2 HDR/VGA Display Converter - TB3 Compatible (CDP2MDPVGA) Title Ingram (Part 1) USB C Multiport Video Adapter Title Ingram (Part 2) VGA or Mini DP - HDR 4K 60 Website Product Headline High Dynamic Range | Aluminum | 6" (15.24 cm) Built-In Cable Bullet 1 FLEXIBLE VIDEO OUTPUT: 2-in-1 portable USB-C multiport video adapter w/ Mini DP 1.2 or VGA, is the perfect video hub for working from a home or office workstations, boardrooms or on the road Bullet 2 COMPATIBILITY: USB C adapter for devices like Dell XPS/Precision/Latitude, Lenovo ThinkPad X1 Carbon/Extreme, Surface Pro 7/Laptop 3, MacBook Pro/Air, HP Elite/EliteBook/Spectre/ZBook, Chromebook Bullet 3 TESTED & VERIFIED: USB-C display adapter tested for peak performance @ 4K 60Hz (mDP) and 1080p (VGA) on projectors/displays incl brands like Samsung, Dell, HP, Lenovo, Asus, Acer, LG, Sharp & Sony Bullet 4 EASY TO USE: USB C (DisplayPort over USB-C) video adapter for any TB3/USB Type C laptop/tablet/smartphone & supports driverless plug & play setup in Windows, macOS, iPadOS, Chrome OS, Linux, Android Bullet 5 HIGH PERFORMANCE: USB C (DP Alt Mode) to Mini DisplayPort 1.2 4K 60Hz HBR2 or VGA 1080p display adapter converter on a single monitor with 2ch audio, compatible with HDCP 2.2/1.4 and Thunderbolt 3 Bullets (Compact) 2-in-1 USB-C multiport video adapter w/ Mini DisplayPort 1.2 or VGA - USB-C to 4K 60Hz mDP 1.2 HBR2 or 1080p VGA - HDCP 2.2/1.4 / 2ch audio - USB-C display adapter for TB3/USB Type-C laptop/tablet Dell HP Lenovo MacBook - Driverless & OS independent Bullets (Consolidated) 2-in-1 USB-C multiport video adapter w/ Mini DisplayPort 1.2 or VGA|2ch Audio|HDCP 2.2/1.4 | Thunderbolt 3 compatible - USB-C DP Alt Mode to 4K 60Hz Mini DP(HBR2) or 1080p VGA - Works w/ Dell XPS Precision Latitude/Lenovo ThinkPad X1 Carbon Extreme/Surface Pro 7 Laptop 3 Book 3/MacBook Pro Air/HP EliteBook Spectre ZBook/Chromebook - USB-C display adapter for USB Type-C/TB3 laptops/tablet and range of mDP/VGA monitors/projector - Driverless setup Windows macOS iPadOS Chrome OS Linux Android Marketing Copy Marketing Copy (No HTML) Applications - Connect to virtually any Mini DisplayPort or VGA display while traveling or in the office
- Output video to a secondary Mini DP or VGA monitor
- Stream, view and edit 4K and HD video on your mDP or VGA display
Website Search Keyword - 2 in 1 usb c adapter
- 4k usb c adapter
- adapter mini displayport usb c
- multiport adapter
- multiport display adapter
- multiport video adapter
- type c to mini dp
- usb c 2 in 1 adapter
- usb c adapter
- usb c adapter 4k 60Hz
- usb c adapter vga
- usb c display adapter
- usb c monitor adapter
- usb c multiport
- usb c multiport adapter
- usb c multiport video adapter
- usb c to mdp
- usb c to mdp adapter
- usb c to mini displayport
- usb c to mini displayport 4k 60Hz
- usb c to mini displayport adapter
- usb c to mini dp
- usb c to mini dp adapter
- usb c to vga
- usb c to vga adapter
- usb c to vga converter
- usb c to vga monitor
- usb c video adapter
- usb type c 2 in 1 adapter
- usb type c multiport adapter
- usb type c to mini displayport
- usb type c to mini displayport adapter
- usb type c video adapter
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
Special Notes - Your USB-C device must support DP Alt Mode to work with this adapter
- This adapter only supports a single display - you are not able to output Mini DisplayPort and VGA video simultaneously
- To achieve HDR, your USB-C port must support DisplayPort 1.4 and your display must support HDMI 2.0b
Accessory Products - MDISPLPORT3
- MDISPLPORT6
- MXT101MMHQ
- MXT101MMHQ10
- MXT105MMHQ
Related Products - CDP2DPVGA
- CDP2HDMDP
- CDP2DPHD
- CDP2HDVGA
- CDPVDHDMDPRG
- CDPVGDVHDMDP
- CDPVGDVHDBP
- CDPVGDVHDB
- CDPVDHDMDP2G
- CDPVDHDMDPSG
Power Delivery No PD Pass-Through Cable Length (mm) 152.4 Color Space Gray Humidity 5~90% RH (no condensation) Material Aluminum Operating Temperature 0°C to 70°C (32°F to 158°F) Primary Material Aluminum Product Length (mm) 62.000 Product Width (mm) 44.000 Product Height (mm) 15.000 Product Weight (g) 51.000 Storage Temperature -10°C to 55°C (14°F to 131°F) TAA Compliant No Audio Specifications - Mini DisplayPort - 2 Channel Audio
- VGA - No Audio Support
HDR Support Yes Maximum Cable Distance To Display 2000 Maximum Supported Resolution 4K 60Hz (3840x2160) OS Compatibility OS Independent Supported Resolutions Video Output Port - Mini DisplayPort
- VGA
Wide Screen Supported Yes Audio Yes AV Input USB-C AV Output - Mini DisplayPort - 1.2
- VGA
Chipset ID Realtek RTD2142S-CG Converter Type Travel A/V Adapters Host Connection Port USB-C Number of Displays 1 Carton Depth (mm) 334 Carton Height (mm) 440 Carton Quantity 200 Carton Weight Gross (g) 15704 Included in Package 1 - USB-C to Mini DisplayPort and VGA Adapter Package Depth (mm) 80 Package Height (mm) 21 Package Width (mm) 177 Package Quantity 1 Package Weight (g) 74 Packaging Description USB-C to Mini DisplayPort and VGA Adapter Packaging Description India USB-C to Mini DisplayPort and VGA Converter Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-C DP++ (DP Alt-Mode) Connector 1 (Quantity) 1 Connector 2 Mini DisplayPort Connector 2 (Quantity) 1 Connector 3 VGA Connector 3 (Quantity) 1 Amazon Merchandising Manager Kristian Haighton Artwork Due Date 2019-12-19 Buying Center - AV & Collaboration Yes Buying Center - End User Compute Yes Buying Center - Networking & Edge No Digital Content Due Date 2020-01-17 Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett ID Label Silkscreened or a Label Silkscreened label - requires dieline showing location Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FI,FR,IE,IN,IT,JP,NL,NZ,PE,SE,SG,UK,US Primary Technology USB-C Priority New Product N/A Product Development Specialist Abhinav Pathak Product Information Creation Specialist (PICS) Dan Dagenais Product Manager David Muzinic Product Performance Specialist John Mardinly Product Photographer Caleigh Le Grand Target Development Completion Date 2019-11-25 Target Production Release 2019-12-19 Tech Lead Brian Linseman Technical Writer Evan Hanbidge Technology Lifecycle None
