CDP2VGAUCPW
USB C to VGA Adapter with USB Power Delivery
USB Type C Adapter | Thunderbolt 3 Compatible | 1080p
Main Image
Product Images
Product Images
Product Images
Product Name USB C to VGA Adapter with USB Power Delivery Product Number CDP2VGAUCPW UPC 065030868921 Lifecycle status End of Life Warranty 3 Years Taxonomy Product > Docks, Hubs & Video Adapters > Video Adapters Category Level 1 Display and Video Adapters Category Level 2 USB-C Display Adapters Category Level 3 USB-C to VGA Family USBC to VGA Adapters, DP Alt Mode, 1920 x 1200 Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX031X Product Title (Ultra-Short) USB-C to VGA Adapter Product Title (Short) USB C to VGA Adapter with Power Delivery Product Title (Medium) USB-C to VGA Adapter with USB Power Delivery - White - 1080p Product Title (Standard) USB C to VGA Adapter with 60W Power Delivery Pass-Through - 1080p USB Type-C to VGA Video Converter w/ Charging - White Product Title (Long) USB C to VGA Adapter with Power Delivery - 1080p USB Type-C to VGA Monitor Video Converter w/ Charging - 60W PD Pass-Through - Thunderbolt 3 Compatible - White Product Title (AMZ) USB C to VGA Adapter with Power Delivery - 1080p USB Type-C to VGA Monitor Video Converter w/ Charging - 60W PD Pass-Through - Thunderbolt 3 Compatible - White (CDP2VGAUCPW) Title Ingram (Part 1) USB-C to VGA Adapter Title Ingram (Part 2) USB-C with Power Delivery - 60 W Website Product Headline USB Type C Adapter | Thunderbolt 3 Compatible | 1080p Bullet 1 DIGITAL TO ANALOG: USB-C (DP 1.2 Alt Mode HBR2) adapter lets you connect a single VGA display supporting 2048x1280, 1920x1200 & 1920x1080 at 60Hz; equipped w/ EDID support & DDC pass-through Bullet 2 60W PD PASS THROUGH CHARGING: USB-C display adapter with up to 60W Power Delivery to power & charge your laptop while displaying video on a VGA monitor/projector using a single USB-C port Bullet 3 COMPATIBILITY: Works w/ DisplayPort over USB Type-C (TB3 compatible) laptops like Lenovo ThinkPad X1 Carbon, Dell XPS 13, HP EliteBook, TB3 MacBook Pro 13 / Air, Surface Book 3/Laptop 3, Chromebook Bullet 4 PORTABLE: Connect a VGA monitor or projector to your laptop, or add a secondary display to your workstation; portable white USB-C to VGA converter can be carried in your laptop bag during travel Bullet 5 EASY TO USE: USB C to VGA adapter supports a driverless plug & play setup & works w/ macOS, iPadOS, Windows, Chrome OS & Linux | Compatible w/ Thunderbolt 3 & previous versions of DisplayPort Bullets (Compact) USB-C (DP 1.2 Alt Mode HBR2) to VGA video display adapter w/ 60W Power Delivery pass-through charging; 2048x1280/1920x1200/1080p @ 60Hz; EDID/DDC - Thunderbolt 3 Compatible - Portable USB Type-C Monitor/Projector Converter - Driverless OS independent Bullets (Consolidated) USB-C (DP 1.2 Alt Mode HBR2) to VGA monitor adapter w/ PD supports 2048x1280/1920x1200/1080 @ 60Hz | EDID and DDC pass-through - USB-C video adapter with 60W Power Delivery pass-through laptop charging while connected to a VGA display/projector -USB-C to VGA adapter works w/USB Type-C/Thunderbolt 3 laptops Lenovo ThinkPad X1 Carbon/Dell XPS/HP EliteBook/TB3 MacBook Pro Air/Surface Book 3 Laptop 3 - Portable/travel USB-C to VGA converter - Driverless setup Windows/macOS/iPadOS/Chrome OS/Linux Marketing Copy Marketing Copy (No HTML) Applications - Connect to any VGA display while travelling
- Connect your BYOD laptop to a VGA display at work, school or home while charging your laptop
- Present on a large VGA display using your USB-C laptop
Website Search Keyword U444-06N-V-C Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + paper tray/divider
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
System and Cable Requirements Your USB-C port must support DisplayPort over USB-C (DP Alt mode) in order to work with this adapter Accessory Products - MXT101MMHQ
- MXT101MM
- MXT105MMHQ
- MXT101MMHQ3
- MXT101MM15
- MXT101MMHQ1
Related Products - CDP2HDUACPW
- CDP2VGA
- CDP2VGAW
- CDP2HD
- CDP2HDW
- CDP2DP
- CDP2VGAUCP
- CDP2HDUCP
Power Delivery 60W Power Source USB-Powered Cable Length (mm) 102 Color White Humidity 0~90% RH Operating Temperature 0°C to 40°C (32°F to 104°F) Primary Material Plastic Product Length (mm) 150.000 Product Width (mm) 33.000 Product Height (mm) 15.000 Product Weight (g) 24.000 Storage Temperature -20°C to 70°C (-4°F to 158°F) TAA Compliant No Audio Specifications VGA - No Audio Support HDR Support No Maximum Analog Resolutions 1920 x 1200 @ 60Hz Maximum Supported Resolution 1080p OS Compatibility OS Independent Supported Resolutions Video Output Port VGA Wide Screen Supported Yes AV Input USB-C AV Output VGA Chipset ID Converter Type Adapters Host Connection Port USB-C Number of Displays 1 Carton Depth (mm) 338 Carton Height (mm) 318 Carton Quantity 40 Carton Weight Gross (g) 5194 Included in Package 1 - USB-C to VGA adapter Package Depth (mm) 144 Package Height (mm) 30 Package Width (mm) 168 Package Quantity 1 Package Weight (g) 116 Packaging Description USB-C™ to VGA Adapter with Charge Port - White Packaging Description India USB-C™ to VGA Converter with Charge Port - White Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-C DP++ (DP Alt-Mode) Connector 1 (Quantity) 1 Connector 2 VGA Connector 2 (Quantity) 1 Connector 3 USB-C (100W PD Only) Connector 3 (Quantity) 1 Amazon Merchandising Manager Kristian Haighton Artwork Due Date 2016-11-29 Buying Center - AV & Collaboration Yes Buying Center - End User Compute Yes Buying Center - Networking & Edge No Digital Content Due Date 2017-03-17 Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FR,IE,IN,IT,JP,NL,NZ,PE,SE,SG,UK,US Primary Technology USB-C Product Development Specialist Abhinav Pathak Product Information Creation Specialist (PICS) Dan Dagenais Product Manager David Muzinic Product Performance Specialist John Mardinly Product Photographer Caleigh Le Grand Target Development Completion Date 2016-11-11 Target Production Release 2016-12-09 Tech Lead Brian Linseman Technical Writer Dan Dagenais Technology Lifecycle None
