Product Name 4-in-1 USB-C to MDP, VGA, DVI or HDMI 4K Converter - Space g Product Number CDPVDHDMDPSG UPC 065030878753 Lifecycle status End of Life Warranty 3 Years Taxonomy Product > Docks, Hubs & Video Adapters > Video Adapters Category Level 1 Display and Video Adapters Category Level 2 USB-C Display Adapters Category Level 3 USB-C Travel Adapters Family USBC to Multiport Display Adapters, DP Alt Mode, 4K60 Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX028X Product Title (Ultra-Short) USB C Video Adapter Product Title (Short) USB C to HDMI/VGA/mDP/DVI Video Adapter Product Title (Medium) USB-C Multiport Video Adapter - 4-in-1 USB-C Adapter - Space Gray - 4K 30Hz Product Title (Standard) USB C Multiport Video Adapter 4K/1080p - USB Type C to HDMI, VGA, DVI or Mini DisplayPort Monitor Adapter - Space Gray Product Title (Long) USB C Multiport Video Adapter with HDMI, VGA, Mini DisplayPort or DVI - USB Type C Monitor Adapter to HDMI 1.4 or mDP 1.2 (4K) - VGA or DVI (1080p) - Space Gray Aluminum Product Title (AMZ) USB C Multiport Video Adapter with HDMI, VGA, Mini DisplayPort or DVI - USB Type C Monitor Adapter to HDMI 1.4 or mDP 1.2 (4K) - VGA or DVI (1080p) - Space Gray Aluminum (CDPVDHDMDPSG) Title Ingram (Part 1) USB-C Multiport Video Adapter Title Ingram (Part 2) - USBC/HDMI/VGA/DVI/mDP Space Gray Website Product Headline USB Type-C™ to VGA DVI HDMI or mDP Travel Adapter | Wrap-Around Cable Bullet 1 4-IN-1 MULTIPORT USB-C VIDEO ADAPTER: USB-C DP Alt Mode to any one of HDMI 1.4 (4K 30Hz & 7.1ch audio), mDP 1.2 (4K 60Hz & 2ch audio), VGA or DVI (1080p), HDCP 2.2/1.4, Thunderbolt 3 compatible Bullet 2 TOUGH & PORTABLE: Durable aluminum Space Gray enclosure with a magnetically-secured hideaway cable wrap for on-the-go users in the office, at home, boardrooms, and classrooms Bullet 3 COMPATIBILITY: USB-C display adapter for Dell XPS/Precision/Latitude, Lenovo ThinkPad X1 Carbon/Extreme, Surface Laptop 3/Surface Book 3, TB3 MacBook Pro/Air, HP EliteBook/Spectre/ZBook, Chromebooks Bullet 4 TESTED & VERIFIED: USB Type-C adapter tested @ 4K mini DisplayPort (60Hz)/HDMI (30Hz) or 1080p VGA/DVI with TV, monitor & projector brands like Dell, Asus, Acer, LG, Samsung, Sharp, Sony, Epson Bullet 5 EASY TO USE: Supporting a driverless plug-and-play setup, this adapter is fully compatible with multiple OS platforms: Windows / macOS / Linux / Chrome OS Bullets (Compact) 4-in-1 USB Type C multiport video adapter to one 4K HDMI (30Hz)/mini DisplayPort (60Hz) or 1080p VGA/DVI monitor/display / HDCP 2.2/1.4 / Thunderbolt 3 Compatible - Space Gray Aluminum - Works w/ Dell Lenovo Surface MacBook HP Chromebook - No Drivers Bullets (Consolidated) 4-in-1 multiport USB-C video adapter to any one of HDMI 1.4 (4K 30Hz) or Mini DisplayPort 1.2 (4K 60Hz) | VGA or DVI (1080p) | HDCP 2.2/1.4 - Portable and durable aluminum Space Gray housing w/ magnetic hideaway cable - For USB Type C/Thunderbolt 3 laptops like Dell XPS Precision Latitude/Lenovo ThinkPad X1 Carbon Extreme/Surface Laptop 3 Book 3/MacBook Pro Air/HP EliteBook Spectre ZBook/Chromebooks - Tested w/ range of displays/monitors/projectors - No Drivers Windows macOS Linux Chrome OS Marketing Copy Marketing Copy (No HTML) Applications - Connect to virtually any display while traveling
- Connect your BYOD MacBook to a VGA, DVI, HDMI or mDP display at work or school
- Connect a secondary VGA, DVI, HDMI or mDP monitor to your MacBook
Website Search Keyword - 4 in 1
- 4 in 1 video
- 4k
- 4k 60hz
- 4k uhd
- 4k ultra hd
- 4k usb c
- 4k usb c adapter
- 4k usb c monitor adapter
- 4k60
- adapter for macbook pro 2017
- apple usb c adapter
- dell xps 13 accessories
- mac usb c adapter
- macbook pro 2016 adapter
- macbook pro adapter
- MacBook Pro to DisplayPort
- MacBook Pro to HDMI
- macbook pro usb c adapter
- macbook usb c adapter
- monitor adapter
- multi display adapter
- multi display adapter for laptop
- multi monitor adapter
- multi video output
- multiport adapter
- Slate Gray
- slate gray usb c adapter
- Slate Grey
- slate grey usb c adapter
- Slate Grey Video Adapter
- space Gray
- space gray usb c adapter
- Space Gray Video Adapter
- space Grey
- space grey usb c
- space grey usb c adapter
- space grey usb c hub
- universal display adapter
- universal multi display adapter
- universal usb c adapter
- usb 3.1 type c 4k
- usb 3.1 type c adapter
- usb c 4k 60hz
- usb c 4k 60hz dock
- usb c 4k 60hz hub
- usb c 4k adapter
- usb c adapter
- usb c adapter hub
- usb c adapter space grey
- usb c all in one adapter
- usb c av adapter
- usb c display adapter
- usb c dongle
- usb c hdmi 4k 60hz
- usb c laptop adapter
- usb c monitor adapter
- usb c multi display
- usb c multi display adapter
- usb c multi monitor adapter
- usb c multi video adapter
- usb c multiport
- usb c multiport adapter
- usb c multiport video adapter
- usb c to dvi adapter
- usb c to hdmi adapter
- usb c to hdmi vga
- usb c to hdmi vga adapter
- usb c to mdp
- usb c to mdp adapter
- usb c to mini displayport adapter
- usb c to mini dp adapter
- usb c to thunderbolt
- usb c to vga adapter
- usb c to vga hdmi
- usb c to vga hdmi adapter
- usb c to video
- usb c vga hdmi
- usb c vga hdmi adapter
- usb c video adapter
- usb type c adapter
- usb type c converter
- usb type c multiport adapter
- usb type c video adapter
- USB-C A/V Travel Adapter
- USB-C Multiport Adapter
- USB-C to DVI
- USB-C to HDMI
- USB-C to HDMI 4K60
- USB-C to HDMI, VGA, and Mini DisplayPort
- USB-C to Mini DisplayPort
- USB-C to VGA
- USB-C Travel 4-in-1
- USB-C Travel Adapter
- USB-C with DP Alt Mode
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
Special Notes - Only one video output is supported on the video adapter at a time, if multiple connections are made, only one of the outputs will function
- Maximum Cable Distance to Display refers to digital video. VGA distance capabilities are dependent upon the quality of your cabling
Accessory Products - MXT101MMHQ1
- MXT101MMHQ3
- MXT101MMHQ
- MXT101MMHQ10
- MXT101MMHQ20
- MXT101MMHQ25
- HDMM1
- HDMM3
- HDMM6
- HDMM8
- HDMM10
- HDMM12
- HDMM15
- HDMM20
- HDMM25
- DVIDDMM1
- DVIDDMM3
- DVIDDMM6
- DVIDDMM10
- DVIDDMM15
- DVIDDMM20
- DVIDDMM25
- MDP2DPMM3
- MDP2DPMM6
- MDP2DPMM10
- MDP2DPMM1MW
- MDP2DPMM2MW
- MDP2DPMM3MW
- MDP2DPMM4M
- MDISPLPORT3
- MDISPLPORT6
- MDPMM1MW
- MDPMM2MW
- MDPMM3MW
Related Products - MDPVGDVHD4K
- MDP2VGDVHD
- MDP2DPDVHD
- MDP2VGDVHDW
- MDP2HDVGA
- MDP2HDVGAW
- DP2VGDVHD
- DP2HDVGA
- CDPVDHDMDPRG
- CDPVGDVHDMDP
Power Delivery No PD Pass-Through Cable Length (mm) 110 Color Space Gray Humidity Material Aluminum Operating Temperature 0°C to 45°C (32°F to 113°F) Primary Material Aluminum Product Length (mm) 175.000 Product Width (mm) 145.000 Product Height (mm) 30.000 Product Weight (g) 180.000 Storage Temperature -10°C to 70°C (14°F to 158°F) TAA Compliant No Audio Specifications - HDMI - 7.1 Channel Audio
- DVI - No Audio Support
- VGA - No Audio Support
- Mini DisplayPort - 2 Channel Audio
HDR Support No Maximum Analog Resolutions 1920 x 1200 @ 60Hz Maximum Cable Distance To Display 15200 Maximum Digital Resolutions 3840 x 2160 @ 30Hz Maximum Supported Resolution 4K 60Hz (3840x2160) MTBF (hours) 654,111 hours OS Compatibility OS Independent Supported Resolutions Video Output Port - DVI
- HDMI
- Mini DisplayPort
- VGA
Wide Screen Supported Yes Active or Passive Adapter Active AV Input USB-C AV Output - HDMI - 1.4
- DVI-I (Digital Only) - Single-Link
- VGA
- Mini DisplayPort - 1.2
Chipset ID Converter Type Travel A/V Adapters Host Connection Port USB-C Number of Displays 1 Carton Depth (mm) 338 Carton Height (mm) 434 Carton Quantity 70 Carton Weight Gross (g) 13904 Included in Package 1 - travel A/V adapter Package Depth (mm) 144 Package Height (mm) 32 Package Width (mm) 175 Package Quantity 1 Package Weight (g) 176 Packaging Description 4-in-1 USB-C Video Adapter - Space Gray - 4K Packaging Description India 4-in-1 USB-C Video Converter - Space Gray - 4K Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-C DP++ (DP Alt-Mode) Connector 1 (Quantity) 1 Connector 2 Mini DisplayPort Connector 2 (Quantity) 1 Connector 3 VGA Connector 3 (Quantity) 1 Connector 4 DVI-D Dual-Link (25-Pin) Connector 4 (Quantity) 1 Connector 5 HDMI Connector 5 (Quantity) 1 Amazon Merchandising Manager Kristian Haighton Artwork Due Date 2018-03-13 Buying Center - AV & Collaboration Yes Buying Center - End User Compute Yes Buying Center - Networking & Edge No Digital Content Due Date 2018-04-13 Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FI,FR,HK,IE,IN,IT,JP,MX,NL,NZ,PE,SE,SG,UK,US Primary Technology USB-C Product Development Specialist Abhinav Pathak Product Information Creation Specialist (PICS) Dan Dagenais Product Manager David Muzinic Product Performance Specialist John Mardinly Product Photographer Caleigh Le Grand Target Development Completion Date 2018-02-16 Target Production Release 2018-03-16 Tech Lead Brian Linseman Technical Writer Dan Dagenais Technology Lifecycle None
