Main Image
CDPVDHMDPDP
4-in-1 USB-C to MDP, VGA, DVI or HDMI 4K Convert
USB-C™ to VGA DVI HDMI® or mDP Travel Adapter | Aluminum| 4K 60Hz | Wrap-Around Cable
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
BOM Image
Product Name 4-in-1 USB-C to MDP, VGA, DVI or HDMI 4K Convert Product Number CDPVDHMDPDP UPC 065030878074 Lifecycle status End of Life Warranty 3 Years Taxonomy Product > Docks, Hubs & Video Adapters > Video Adapters Category Level 1 Display and Video Adapters Category Level 2 USB-C Display Adapters Category Level 3 USB-C Travel Adapters Family USBC to Multiport Display Adapters, DP Alt Mode, 4K60 Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX008X Product Title (Ultra-Short) USB C Video Adapter Product Title (Short) USB C to HDMI/mDP/VGA/DVI Video Adapter Product Title (Medium) USB-C Multiport Video Adapter 4-in-1 - 95W Power Delivery - Space Gray - 4K 60Hz Product Title (Standard) USB C Multiport Video Adapter - 4K 60Hz UHD Portable 5-in-1 USB Type C to HDMI 2.0, mDP, VGA or DVI, PD 3.0, Cable Management Product Title (Long) USB C Multiport Video Adapter - 4K 60Hz UHD Portable 5-in-1 USB Type C to HDMI 2.0, Mini DisplayPort, VGA or DVI (1080p) - 95W PD Passthrough - Cable Management - Aluminum Product Title (AMZ) USB C Multiport Video Adapter - 4K 60Hz UHD Portable 5-in-1 USB Type C to HDMI 2.0, Mini DisplayPort, VGA or DVI (1080p) - 95W PD Passthrough - Cable Management - Aluminum (CDPVDHMDPDP) Title Ingram (Part 1) USB C Multiport Video Adapter - Title Ingram (Part 2) USB C to VGA DVI HDMI or mDP Website Product Headline USB-C™ to VGA DVI HDMI® or mDP Travel Adapter | Aluminum| 4K 60Hz | Wrap-Around Cable Bullet 1 5-IN-1 MULTIPORT USB-C VIDEO ADAPTER: USB-C DP Alt Mode to any one of 4K 60Hz HDMI 2.0/mDP 1.2 or 1080p VGA/DVI with HDCP 2.2/1.4, Thunderbolt 3 compatible, 95W Power Delivery Pass-Through, Space Gray Bullet 2 95W PD 3.0 PASS-THROUGH: Use a USB-C power adapter to charge laptop (Ultrabooks & workstations) up to 95W; prevents video drop/flickering when power is added/removed on PD 3.0 laptops like MacBook Pro Bullet 3 COMPATIBILITY: USB-C display adapter for TB3 MacBook Pro/Air, Dell XPS/Precision/Latitude, Lenovo ThinkPad X1 Carbon/Extreme, Surface Laptop 3/Surface Book 3, HP EliteBook/Spectre/ZBook, Chromebooks Bullet 4 TESTED & VERIFIED: USB Type-C adapter tested @ 4K 60Hz HDMI 2.0/Mini DisplayPort or 1080p VGA/DVI for compatibility w/ TVs, monitors & projectors like Dell, Asus, Acer, LG, Samsung, Sharp, Sony, Epson Bullet 5 EASY TO USE: Durable aluminum space gray housing w/ magnetically-secured hideaway cable wrap; supports driverless plug-and-play setup, and is compatible with Windows / macOS / Linux / Chrome OS Bullets (Compact) 5-in-1 USB Type C multiport video adapter to single 4K 60Hz UHD HDMI 2.0/mini DisplayPort 1.2 or 1080p VGA/DVI monitor/display / HDCP 2.2/1.4 - 95W Power Delivery Pass-Through - Thunderbolt 3 Compatible - Portable Aluminum Housing - No Drivers Bullets (Consolidated) 5-in-1 multiport USB-C video adapter to any one of 4K 60Hz UHD HDMI 2.0 or Mini DisplayPort 1.2 or VGA or DVI 1080p | HDCP 2.2/1.4 |Thunderbolt 3 compatible | Space Gray - Use a USB-C power adapter to charge your laptop w/ up to 95W Power Delivery 3.0 - Works w/ MacBook Pro Air/Dell XPS Precision Latitude/Lenovo ThinkPad X1 Carbon Extreme/Surface Laptop 3 Surface Book 3/HP EliteBook Spectre ZBook/Chromebooks - Tested w/ range of displays/monitors/projectors - Driverless setup | OS Independent Marketing Copy Marketing Copy (No HTML) Applications - Connect to virtually any display while traveling
- Connect a MacBook or USB-C laptop to a VGA, DVI, HDMI or mDP display
- Connect a secondary monitor to your Space Gray MacBook or USB-C laptop
Website Search Keyword - 4k usb c adapter
- adapter for macbook pro 2017
- apple usb c adapter
- dell xps 13 accessories
- macbook pro 2016 adapter
- macbook pro adapter
- macbook pro usb c adapter
- monitor adapter
- multi display adapter for laptop
- usb 3.1 type c adapter
- usb c adapter
- usb c adapter hub
- usb c all in one adapter
- usb c av adapter
- usb c display adapter
- usb c dongle
- usb c laptop adapter
- usb c monitor adapter
- usb c multiport
- usb c multiport adapter
- usb c multiport video adapter
- usb c to dvi adapter
- usb c to hdmi adapter
- usb c to hdmi vga adapter
- usb c to mdp
- usb c to mdp adapter
- usb c to mini displayport adapter
- usb c to mini dp adapter
- usb c to thunderbolt
- usb c to vga adapter
- usb c to vga hdmi
- usb c video adapter
- usb type c adapter
- USB-C Multiport Adapter
- USB-C to DVI
- USB-C to HDMI
- USB-C to Mini DisplayPort
- USB-C to VGA
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
Special Notes - Only one video output is supported on the video adapter at a time, if multiple connections are made, only one of the outputs will function
- Your laptop may have specific requirements for charging. This USB-C multiport adapter supports USB Power Delivery 3.0, up to 95W. When using your laptop’s USB-C power adapter, the multiport adapter powers both the adapter and your laptop - with up to 85W charging available for laptop charging. For more information on your laptop’s charging requirements, refer to the manufacturer of your laptop.
- Maximum Cable Distance to Display refers to digital video. VGA distance capabilities are dependent upon the quality of your cabling
Accessory Products - MXT101MMHQ1
- MXT101MMHQ3
- MXT101MMHQ
- MXT101MMHQ10
- MXT101MMHQ20
- MXT101MMHQ25
- HDMM1
- HDMM3
- HDMM6
- HDMM8
- HDMM10
- HDMM12
- HDMM15
- HDMM20
- HDMM25
- DVIDDMM1
- DVIDDMM3
- DVIDDMM6
- DVIDDMM10
- DVIDDMM15
- DVIDDMM20
- DVIDDMM25
- MDP2DPMM3
- MDP2DPMM6
- MDP2DPMM10
- MDP2DPMM1MW
- MDP2DPMM2MW
- MDP2DPMM3MW
- MDP2DPMM4M
- MDISPLPORT3
- MDISPLPORT6
- MDPMM1MW
- MDPMM2MW
- MDPMM3MW
Related Products - MDPVGDVHD4K
- MDP2VGDVHD
- MDP2DPDVHD
- MDP2VGDVHDW
- MDP2HDVGA
- MDP2HDVGAW
- DP2VGDVHD
- DP2HDVGA
- CDPVDHDMDPSG
- CDPVDHDMDPRG
- CDPVGDVHDBP
Constrained SKU Alternatives (Limited Stock) - CDPVDHDMDPRG
- CDPVDHDMDPSG
Power Consumption (In Watts) 10W Power Delivery 95W Power Source USB-Powered Cable Length (mm) 101 Color Black Humidity 0~95% RH Material Aluminum Operating Temperature 0°C to 45°C (32°F to 113°F) Primary Material Aluminum Product Length (mm) 109 Product Width (mm) 57 Product Height (mm) 18 Product Weight (g) 128 Storage Temperature 0°C to 60°C (32°F to 140°F) TAA Compliant No Audio Specifications - HDMI - 7.1 Channel Audio
- DVI - No Audio Support
- VGA - No Audio Support
- Mini DisplayPort - 5.1 Channel Audio
HDR Support No Maximum Analog Resolutions 1920 x 1200 @ 60Hz Maximum Cable Distance To Display 15200 Maximum Digital Resolutions Maximum Supported Resolution 4K 60Hz (3840x2160) OS Compatibility OS Independent Supported Resolutions Video Output Port - DVI
- HDMI
- Mini DisplayPort
- VGA
Wide Screen Supported Yes Active or Passive Adapter Active AV Input USB-C AV Output - DVI-I (Digital Only) - Single-Link
- VGA
- Mini DisplayPort - 1.2
- HDMI - 2.0
Chipset ID Converter Type Travel A/V Adapters Host Connection Port USB-C Number of Displays 1 Carton Depth (mm) 334 Carton Height (mm) 224 Carton Quantity 30 Carton Weight Gross (g) 7324 Included in Package 1 - Travel A/V Adapter Package Depth (mm) 143 Package Height (mm) 32 Package Width (mm) 176 Package Quantity 1 Package Weight (g) 216 Packaging Description 4-in-1 USB-C Video Adapter - USB PD - 4K Packaging Description India 4-in-1 USB-C Video Converter - USB PD - 4K Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-C DP++ (DP Alt-Mode) Connector 1 (Quantity) 1 Connector 2 Mini DisplayPort Connector 2 (Quantity) 1 Connector 3 VGA Connector 3 (Quantity) 1 Connector 4 DVI-I Dual-Link (29-Pin) Connector 4 (Quantity) 1 Connector 5 HDMI Connector 5 (Quantity) 1 Connector 6 USB-C (100W PD Only) Connector 6 (Quantity) 1 Amazon Merchandising Manager Kristian Haighton Artwork Due Date 2018-08-09 Buying Center - AV & Collaboration Yes Buying Center - End User Compute Yes Buying Center - Networking & Edge No Digital Content Due Date 2018-11-02 Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CO,DE,DK,ES,EU,FI,FR,IE,IN,IT,JP,MX,NL,NZ,SE,SG,UK,US Primary Technology USB-C Priority New Product N/A Product Development Specialist Abhinav Pathak Product Information Creation Specialist (PICS) Dan Dagenais Product Manager David Muzinic Product Performance Specialist John Mardinly Product Photographer Caleigh Le Grand Target Development Completion Date 2018-07-27 Target Production Release 2018-08-31 Tech Lead Brian Linseman Technical Writer Evan Hanbidge Technology Lifecycle None
