D01ML55P-FIBER-MEDIA
Gigabit Ethernet to LC Fiber Converter Dongle - PoE Powered
Convert and extend a Gigabit RJ45 Ethernet connection over single or multimode LC fiber
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
BOM Image
Product Name Gigabit Ethernet to LC Fiber Converter Dongle - PoE Powered Product Number D01ML55P-FIBER-MEDIA UPC 065030909822 Lifecycle status Active Warranty 2 Years Weighted Opportunity 0 Taxonomy Product > Networking > Ethernet Media Converters Category Level 1 Networking Category Level 2 Ethernet Media Converters Category Level 3 Multi Mode Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX137X Product Title (Ultra-Short) 1G Media Converter Product Title (Short) Gigabit Fiber to RJ45 Media Converter Product Title (Medium) Gigabit Fiber to RJ45 Ethernet Media Converter Dongle, LC Single/Multimode, TAA Product Title (Standard) Gigabit Fiber to RJ45 Ethernet Media Converter Dongle, PoE Powered, SMF/MMF, Single/Multimode Optical Fiber, TAA Product Title (Long) Gigabit Fiber to RJ45 Ethernet Media Converter Dongle, Optical Singlemode 10km/Multimode 800m, PoE Powered, Compact Design, Metal Housing, Micro Mini, TAA Product Title (AMZ) Gigabit Fiber to RJ45 Ethernet Media Converter Dongle, Optical Singlemode 10km/Multimode 800m, TAA, PoE Powered Title Ingram (Part 1) Gigabit Fiber to RJ45 Ethernet Title Ingram (Part 2) PoE Media Converter Dongle, SMF/MMF Website Product Headline Convert and extend a Gigabit RJ45 Ethernet connection over single or multimode LC fiber Bullet 1 FIBER TO ETHERNET MEDIA CONVERTER: Converts Gigabit fiber to RJ45 copper in a compact form factor; No SFP/Cat6 cables required; Conveniently PoE powered (802.3af or higher); Dimensions: 3.2x0.8x0.7in (82.4x20x17.2mm) Bullet 2 APPLICATIONS: Upgrade PoE capable computers, switches, routers, or other equipment to fiber; Suitable for on-site network troubleshooting, field deployments, industrial automation, telecommunications, broadcasting, data centers, and remote networking Bullet 3 SHORT & LONG RANGE FIBER: LC slot compatible w/Single-Mode (10km) & Multi-Mode (800m); Single speed 1Gbps for both fiber and RJ-45 ports; Status LEDs including LFPT (Link Fault Pass-Through) enables IT admins to monitor network connectivity Bullet 4 DURABLE CONSTRUCTION: IP20-rated full-metal housing for enhanced durability; Metal RJ45 latch tab ensures a robust and secure connection; Spring-loaded dust cover protects port when not in use Bullet 5 TECH SPECS: Single speed 1Gbps; x1 LC port; x1 RJ45; LC duplex; Singlemode SMF (10km) & multimode MMF (800m); 1310nm; LFPT; IP20 rated all metal housing; PoE powered 30-57V input; Max power consumption 2.5W Bullets (Compact) Gigabit fiber-RJ45 Ethernet media converter dongle; PoE powered - Single/multimode optical fiber - 1Gbps/x1 LC Port/x1 RJ45/SMF 10km/MMF 800m - All-metal; IP20 rated; Metal RJ45 tab - Ideal for upgrading computer/switch - TAA; Compact 3.2x0.8x0.7in Bullets (Consolidated) - Gigabit fiber to RJ45 Ethernet media converter dongle; PoE powered; Upgrade computer/switch/router to fiber - 1Gbps; x1 LC Port; x1 RJ45; SMF 10km; MMF 800m; LC slot compatible w/singlemode/multimode optical fiber; Spring-loaded tab protects port when not in use - Suitable for industrial automation/telecom/broadcasting/data centers/secure facilities/remote network - All-metal housing for durability; IP20 rating; Metal RJ45 latch - Compact size 3.2×0.8×0.7in Marketing Copy Marketing Copy (No HTML) Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box
- Laser Label - Safety - Laser - United States - FDA Class IIIa Laser Label
- Laser Label - Safety - Laser - Canada - Canada Laser Safety Label
- Laser Label - Safety - Laser - European Union - EU Laser Safety Label
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Safety - Electrical - European Union - Low Voltage Directive (LVD) 2014/35/EU
- TUV - Safety - Electrical - Canada / United States - TUV Rheinland cTUVus Mark
Special Notes The D01ML55P-FIBER-MEDIA expands toward the rear. Depending on the port spacing of your device, this may obstruct adjacent ports. Please refer to the technical diagram for precise dimensions and to ensure compatibility with your port spacing requirements. Accessory Products - N6PATCH6BL
- N6PATCH10BK
- 50FIBLCLC1
- 50FIBLCLC10
- 50FIBLCLC15
Related Products - MCM1110MMLC
- ET1000S40LC2
- AF211C-POE-INJECTOR
- AS445C-POE-INJECTOR
Input Voltage 30 - 57V DC Power Consumption (In Watts) 2.5W Power Source PoE-Powered Plug Type RJ45 Male Color Silver Humidity 5~85% RH Material Metal and Plastic Operating Temperature 0°C to 55°C (32°F to 131°F) Primary Material Steel Product Length (mm) 20.000 Product Width (mm) 82.390 Product Height (mm) 17.240 Product Weight (g) 42.000 TAA Compliant Yes Auto MDIX Yes Auto-Negotiation Yes Compatible Networks 1000 Mbps (1 Gbps) MTBF (hours) 374,141 hours at 25ºC (77ºF) OS Compatibility OS Independent Chipset ID Marvell - 88E1512 Fiber Connector LC Industry Standards - IEEE 802.3ab (1000BASE-T)
- IEEE 802.3z (1000BASE-LX)
- IEEE 802.3af (PoE)
LED Indicators - 1 - Power </br> Solid Green: Module On </br> Off: Module Off
- 1 - Link/ACT </br> Solid Green: 1000Mbps </br> Blinking Green: Activity </br> Off: Disconnected
- 1 - Fiber </br> Solid Blue: Connected </br> Off: Disconnected
Power over Ethernet Yes Carton Depth (mm) 340 Carton Height (mm) 126 Carton Quantity 24 Carton Weight Gross (g) 2425 Included in Package - 1 - Media Converter
- 1 - Product Documentation
Package Depth (mm) 80 Package Height (mm) 36 Package Width (mm) 138 Package Weight (g) 76 Packaging Description Gigabit RJ45 Ethernet to LC Fiber Converter Dongle - PoE Powered Packaging Description India Gigabit RJ45 Ethernet to LC Fiber Converter Dongle - PoE Supplied Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 LC Fiber Connector 1 (Quantity) 1 Connector 2 RJ-45 Connector 2 (Quantity) 1 A+ Not Required Actual Inbox Documents Created Compliance Insert Amazon Merchandising Manager Kathleen Marshall Application Photos Uploaded Artwork Due Date 2024-03-30 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge No Comparable SKU Comment Fiber Media Converter Gigabit 1000Mbps MM Fibre LC 550m Comparable SKU 2 Comment Gigabit Ethernet Fiber Media Converter - Compact - 850nm MM LC - 550m Digital Content Due Date 2024-08-02 Enhanced Gallery Not Required Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett ID Label Silkscreened or a Label Sticker label - custom size - requires size population below Launch Markets (concatenated) AT,AU,BE,CA,CH,DE,DK,ES,FI,FR,IE,IN,IT,JP,MX,NL,NZ,PL,SE,SG,UK,US Product Development Specialist Alex Sikora Product Information Creation Specialist (PICS) Maria Powell Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Development Completion Date 2024-01-31 Target Production Release 2024-03-30 Tech Lead Stefan Tirolese Technical Writer Maria Powell Technology Lifecycle None Video Not Required
