DISPLPORT50L
50ft DisplayPort Cable with Latches
Provide high resolution digital video and audio performance between your DisplayPort®-enabled devices
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Video Link YouTube
Product Name 50ft DisplayPort Cable with Latches Product Number DISPLPORT50L UPC 065030834117 Lifecycle status Active Warranty Lifetime Taxonomy Product > Cables > Video Cables Category Level 1 Digital Display Cables Category Level 2 DP Cables Category Level 3 DP Cables - 1.2 Family DP 1.0 Cables, Partial VBL, 1080p60 Web Hierarchy Cables - Audio-Video Cables - Displayport Cables Country of Origin Europe & Japan China Country of Origin North America Vietnam Country of Origin History (1) China Country of Origin Revision (1) XXXXXX012X Country of Origin History (2) Vietnam Country of Origin Revision (2) XXXXXX190X Country of Origin History (3) China Country of Origin Revision (3) XXXXXX045X Product Title (Ultra-Short) . Product Title (Short) 50ft Latching DisplayPort Cable Product Title (Standard) 50 ft DisplayPort Cable with Latches - M/M Product Title (Long) 50ft (15m) DisplayPort Cable - 1920 x 1200p - Displayport to Displayport Cable - DP to DP Cable for Monitor - DP Video/Display Cord - Latching DP Connectors - HDCP & DPCP Product Title (AMZ) 50ft (15m) DisplayPort Cable - 1920 x 1200p - Displayport to Displayport Cable - DP to DP Cable for Monitor - DP Video/Display Cord - Latching DP Connectors - HDCP & DPCP (DISPLPORT50L) Title Ingram (Part 1) 50 ft DisplayPort Cable with Lat Title Ingram (Part 2) ches - M/M Website Product Headline Provide high resolution digital video and audio performance between your DisplayPort®-enabled devices Bullet 1 HIGH PERFORMANCE CABLE: This 50ft (15m) DisplayPort to DisplayPort cable supports Full HD (1920x1200p) 60Hz, (1920x1080p) 60Hz, 6.48 Gbps bandwidth, Multi-Stream Transport (MST), 5.1, 7.1 Audio Channel, GTC for precise audio channel timing & 3D Stereo Bullet 2 QUALITY CONSTRUCTION: 26AWG wire with gold-plated connectors for improved signal integrity and reliability; Superior EMI shielding with Al-Mylar foil and copper braid provides higher quality video and audio; Backwards compatible with DP 1.1 Bullet 3 RELIABLE DESIGN: Durable ABS connectors with flexible PVC strain relief & jacket prevents fraying/damage due to bending or rough usage; Metal connector sub-structure provides EMI shielding; Latching DP connectors prevent accidental disconnection Bullet 4 APPLICATIONS: Ideal for home/offices/boardrooms/conference rooms/classrooms; works with your professional workstations with FirePro™ S9000/7000, W8100/7100/5100 or R5000 graphic cards; Use with 1080p/UHD/4K monitors, projector or large display Bullet 5 SPECS: 50 ft (15 m) | Black | DisplayPort v1.0 | DP Latching Male to Male | 26 AWG | PVC cable jacket, ABS connector shell | Shield: Al-Mylar foil with Braid | Protocols: MST, GTC | Lifetime Warranty Bullets (Compact) - 50ft/15m DisplayPort to DisplayPort cable; Full HD (1920 x 1200p 60Hz)/6.48 Gbps bandwidth/HDCP/DPCP/MST - Durable PVC strain relief; Latching connectors - For office/boardroom with laptop/workstation and monitor/projector; Samsung/Sony/Dell Bullets (Consolidated) 50ft/15m DisplayPort to DisplayPort cable supports Full HD (1920 x 1200p 60Hz); 6.48 Gbps bandwidth/HDCP/DCPC/MST/GTC/3D Stereo - Durable 26AWG cable w/flexible PVC strain relief prevents damage due to bends/rough use; Latching DP connectors prevent accidental disconnection - For home/office/boardroom/classroom use w/ laptop/workstation and Full HD monitor/projector/large display; Samsung/Sony/Dell - Supports DP1.2 and earlier versions - StarTech.com Lifetime Warranty Marketing Copy Marketing Copy (No HTML) Applications Connecting a DisplayPort® display to a PC or alternative DisplayPort source Website Search Keyword P580-050 Required Regulatory Compliance Marks - CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- UKCA - Environmental - United Kingdom - UK Restriction of Hazardous Substances (RoHS) 2012
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- Triman/Info-Tri - Packaging - Waste - European Union - Plastic Bag
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Plastic - Low-Density Polyethylene
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
Cable Length (mm) 15245 Cable OD 8.5 Color Black Connector Style Latching Primary Material Plastic Product Length (mm) 15240.000 Product Width (mm) 20.000 Product Height (mm) 13.000 Product Weight (g) 1086.000 TAA Compliant No Wire Gauge 26 AWG (0.404 mm) DisplayPort Version DP 1.2 - (HBR2) Cable Jacket Material PVC - Polyvinyl Chloride Cable Shield Material Aluminum-Mylar Foil with Braid Connector Plating Nickel Connectors DisplayPort to DisplayPort Fire Rating CMG Number of Conductors 19 Carton Depth (mm) 515 Carton Height (mm) 256 Carton Quantity 10 Carton Weight Gross (g) 11952 Included in Package 1 - 50 ft DisplayPort® Cable with Latches - M/M Package Depth (mm) 221 Package Height (mm) 80 Package Width (mm) 202 Package Quantity 1 Package Weight (g) 1104 Packaging Description 50ft (15.2m) DisplayPort Cable with Latches - 1920 x 1200p 60Hz Packaging Description India 50ft (15.2m) DisplayPort Cable with Latches - 1920 x 1200p 60Hz Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 DisplayPort Connector 1 (Quantity) 1 Connector 2 DisplayPort Connector 2 (Quantity) 1 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2014-06-18 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge No Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) CA,CL,CO,IN,MX,PE,SE,US Primary Technology None Product Development Specialist Pierre Wheeler Product Information Creation Specialist (PICS) Brian Chan Product Manager David Muzinic Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Tech Lead Justin Weaver Technical Writer Brian Chan Technology Lifecycle Mainstream
