Main Image
DK30CHDPPDUE
Dual 4K USB C Dock DP HDMI 60W PD SD Slot
Add dual monitors (4K HDMI® & 4K DP), an SD card reader, multiple USB ports, GbE, and audio to your laptop, plus power and charge your laptop
Main Image
Product Images
Product Images
Product Images
Product Images
Video Link YouTube
Video Link YouTube
Product Name Dual 4K USB C Dock DP HDMI 60W PD SD Slot Product Number DK30CHDPPDUE UPC 065030872683 Lifecycle status Active Warranty 3 Years Taxonomy Product > Docks, Hubs & Video Adapters > Docking Stations & Multiports Category Level 1 Docking Stations Category Level 2 USB-C Docks Category Level 3 USB-C Multi-Monitor Docks Family no family Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX158X Product Title (Ultra-Short) Dual 4K USB C Dock Product Title (Short) USB C Dock Dual Monitor HDMI/DP 60W PD Product Title (Medium) Dual Monitor USB C Dock - Windows/Mac - Dual 4K DP/HDMI - 60W Power Delivery, SD Product Title (Standard) USB C Dock - 4K Dual Monitor HDMI & DisplayPort USB Type-C Docking Station - 60W Power Delivery, SD, 4-port USB 3.0 Hub, GbE Product Title (Long) USB C Dock - Dual Monitor HDMI & DisplayPort 4K 30Hz - USB Type-C Laptop Docking Station 60W Power Delivery, SD, 4-port USB-A 3.0 Hub, GbE, Audio - Thunderbolt 3 Compatible Product Title (AMZ) USB C Dock - Dual Monitor HDMI & DisplayPort 4K 30Hz - USB Type-C Laptop Docking Station 60W Power Delivery, SD, 4-port USB-A 3.0 Hub, GbE, Audio - Thunderbolt 3 Compatible Title Ingram (Part 1) Dual Monitor USB C Dock - Power Title Ingram (Part 2) Delivery 60W - Dual 4K DP/HDMI, SD Website Product Headline Add dual monitors (4K HDMI® & 4K DP), an SD card reader, multiple USB ports, GbE, and audio to your laptop, plus power and charge your laptop Bullet 1 FULL FEATURE USB-C DOCK: 4K 30Hz HDMI + 4K 30Hz DP video, 4x USB-A 5Gbps (incl. BC 1.2 fast charge port), 60W PD, Gigabit Ethernet, 3.5mm headset audio; Two external displays on Apple MacBook Air/Pro (base M-Series) laptops that natively only support one Bullet 2 SUPPORT FOR SD/SDXC MEDIA: This USB-C docking station has an SD slot supporting SD/SDXC cards, great for additional storage or backup using Windows File History or MacOS Time Machine Bullet 3 EASY INSTALLATION: This universal USB-C port replicator incl. a 1m (3.3ft) USB-C host cable, front facing power button, MAC Address Changer utility and works w/ Windows, macOS, Chrome OS, and Ubuntu Bullet 4 WIDE DEVICE COMPATIBILITY: Multi monitor USB Type-C dock with HDMI & DP works w/ Thunderbolt 3 and 4 laptops & ultrabooks, USB-C laptops, ultrabooks, Chromebooks (MacBooks, HP, Dell, Lenovo & Surface) Bullet 5 60W POWER DELIVERY: This USB Type-C docking station powers and charges while you work with 60W PD; great for ultrathin laptops like Lenovo ThinkPad T Series, X1 Carbon, Surface Pro7 Bullets (Compact) USB-C docking station w/ dual monitor 4K 30Hz HDMI + DisplayPort/4x USB-A/GbE/Audio - SD/SDXC Slot - Incl 3.3ft/1m USB Type-C host cable & MAC Address Changer utility - For Thunderbolt/USB-C laptops; 60W Power Delivery - Windows/macOS/ChromeOS/Ubuntu Bullets (Consolidated) - Dual monitor 4K 30Hz HDMI + DisplayPort USB-C dock/4x USB-A (incl BC 1.2 fast charge)/Gigabit Ethernet/3.5mm Audio/60W Power Delivery - Supports 2 extended displays on Apple MacBook Air/Pro (base M-Series) laptops that natively only support one - SD/SDXC card reader works w/ Windows File History/MacOS Time Machine - 3.3ft/1m USB-C host cable and MAC Address Changer utility - Works with Thunderbolt and USB-C laptops/Ultrabooks/Chromebooks - Compatible w/ Windows, macOS, Ubuntu, ChromeOS Marketing Copy Marketing Copy (No HTML) Applications - Ideal for professionals who work with highly detailed graphics or data-intensive applications, including graphic and web designers, videographers, animators, analysts and engineers (CAD)
- Scale your desktop across multiple displays — perfect for government, finance, marketing and sales environments
- Expand the connectivity of your laptop — compatible with MacBook Pro, Dell XPS 15 or other USB-C enabled laptops
Website Search Keyword - usb c hdmi dp dock
- usb c hdmi displayport dock
- usb c dual monitor dock
- usb c dual 4k dock
- usb c hdmi docking station
- usb c docking station hdmi dp
- usb c docking station dual monitor
- hdmi displayport docking station
- dual 4k dock hdmi dp
- usb c dock hdmi dp 4k
- usb c dock with usb c port
- Docking Stations
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Corrugated Fiberboard
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + paper tray/divider
- Triman/Info-Tri - Product - Waste - European Union - EEE Device + accessories + cords
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
Special Notes - Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your host USB-C port supports USB Power Delivery 2.0 and DP alt mode.
- 4K resolution is supported on both video ports. A 4K-capable DisplayPort or HDMI display is required to achieve 4Kx2K resolutions
- If connected to a USB 2.0 host port, or if using a USB 2.0 host connection cable, performance may be limited (USB 3.0 host cable included)
- USB 3.0 is also known as USB 3.1 Gen 1; this connectivity standard offers speeds up to 5Gbps
- The card reader supports popular SD cards (SDSC, SDHC and SDXC including UHS cards), and is backwards compatible with older SD card versions. The card reader will also support microSD™ and miniSD™ (with adapter) and MMCmobile™, RS-MMC™ and MMCplus™ (with adapter).
- DisplayLink docking stations and video adapters support more than one external display on Apple's M1-based Mac. Requires driver installation. Please contact StarTech.com support for a recommendation based on your specific setup.
System and Cable Requirements USB-C enabled computer with an available USB Type-C port Accessory Products - MUYHSMFF
- HDMM2M
- HDMM3M
- 45PAT2MBK
- S2510BMU33CB
- S2510SM12U33
- S3520BU33ER
- DP2HDMM2MB
- DP2HDMI2
- DISPL2M
- DISPL3M
- 45PAT3MBK
Related Products MST30C2DPPD Constrained SKU Alternatives (Limited Stock) DK30C2DPPDUE Input Current 2 A Input Voltage 110V-240V AC Output Current 5 A Output Voltage (V) 20V DC Power Consumption (In Watts) 100W Power Delivery 60W Power Source AC Adapter Included Plug Type N Center Tip Polarity Positive Cable Length (mm) 1000 Color Black & Silver Humidity 0~95% RH Material Plastic Operating Temperature 0°C to 60°C (32°F to 140°F) Primary Material Plastic Product Length (mm) 220.000 Product Width (mm) 80.000 Product Height (mm) 25.000 Product Weight (g) 261.000 Storage Temperature -20°C to 60°C (-4°F to 140°F) TAA Compliant No Auto MDIX Yes Compatible Networks 10/100/1000 Mbps Downstream Maximum Data Transfer Rate USB 3.2 Gen 1 (5Gbps) Full Duplex Support Yes General Specifications Supports SD 4.0 and UHS-II (Ultra High Speed) for high speed file transfers, with bus speed up to 312MB/s Maximum Data Transfer Rate Maximum Digital Resolutions Maximum Supported Resolution 4K 30Hz (3840x2160) Memory Media Type - SD/MMC (Secure Digital/Multimedia Card)
- SDHC (Secure Digital High Capacity)
- SDXC (Secure Digital eXtended Capacity)
- microSD (Micro Secure Digital) (adapter required)
- microSDHC (Micro Secure Digital High Capacity) (adapter required)
- microSDXC (Micro Secure Digital eXtended Capacity) (adapter required)
OS Compatibility - Windows 8
- Windows 7
- Windows 10
- Mac OS X El Capitan (10.11)
- macOS Sierra (10.12)
- macOS Mojave (10.14)
- Chrome OS
- macOS Catalina (10.15)
- macOS Big Sur (11.0)
- Ubuntu
- Windows 11
- macOS Monterey (12.0)
- macOS Ventura (13.0)
- macOS Sonoma (14.0)
- Windows 11 ARM
- macOS Sequoia (15.0)
- macOS Tahoe (26.0)
UASP Support Yes USB Type and Rate USB 3.0 (5Gbps) Video Output Port - HDMI
- DisplayPort
Video Transport Technology USB Graphics Bus Type USB-C Chipset ID Host Connection Port USB-C Industry Standards Interface/Bridge USB 3.2 Gen 1 (5Gbps) Laptop Dock 4K Support Yes Laptop Dock Number of Displays 2 Laptop Dock / USB Hub Fast-Charge Yes Number of Displays 2 Other Ports - Gigabit Ethernet
- USB-A BC 1.2 Fast Charge
- SD Card Reader
- 3.5mm TRRS Headset (Speaker+Mic) Audio Jack
Carton Depth (mm) 280 Carton Height (mm) 302 Carton Quantity 6 Carton Weight Gross (g) 8355 Included in Package - 1 - docking station
- 1 - USB-C cable
- 1 - universal power adapter (UK, EU)
- 1 - instruction manual
Package Depth (mm) 155 Package Height (mm) 90 Package Width (mm) 270 Package Quantity 1 Package Weight (g) 1302 Packaging Description USB-C Dual-4K Monitor Laptop Dock - PD - SD Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 DisplayPort Connector 1 (Quantity) 1 Connector 2 HDMI Connector 2 (Quantity) 1 Connector 3 USB-C (5Gbps, 4.5W) Connector 3 (Quantity) 1 Connector 4 USB-A (7.5W Power Only) Connector 4 (Quantity) 1 Connector 5 USB-A (5Gbps, 4.5W) Connector 5 (Quantity) 3 Connector 6 RJ-45 Connector 6 (Quantity) 1 Connector 7 3.5mm (4 Conductors, TRRS) Connector 7 (Quantity) 1 Connector 8 SD Card Slot Connector 8 (Quantity) 1 Amazon Merchandising Manager Kristian Haighton Artwork Due Date 2017-10-13 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge No Digital Content Due Date 2017-12-15 Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,BE,CH,DE,DK,ES,EU,FI,FR,IE,IT,NL,SE,SG,UK Primary Technology USB-C Product Development Specialist Michael Munn Product Information Creation Specialist (PICS) Dan Dagenais Product Manager Tim North Product Performance Specialist John Mardinly Product Photographer Caleigh Le Grand Target Development Completion Date 2018-02-16 Target Production Release 2018-02-23 Tech Lead Sam Raskas Technical Writer Dan Dagenais Technology Lifecycle Legacy Vending Machine Not Compatible with Vending Machine
