Main Image
DKT30CHPD
USB Type-C Travel Laptop Dock Mini Docking Station
Portable Docking Station | Mac & Windows® | GbE | Thunderbolt™ 3 Compatible
Main Image
Product Images
Product Images
Product Images
Product Images
Quick-Start Guide
Product Name USB Type-C Travel Laptop Dock Mini Docking Station Product Number DKT30CHPD UPC 065030864978 Lifecycle status Active Warranty 3 Years Taxonomy Product > Docks, Hubs & Video Adapters > Docking Stations & Multiports Category Level 1 Multiport Adapters Category Level 2 USB-C Multiport Adapters Category Level 3 USB-C Multiport Adapters - 5Gbps Family USB-C Multiport Adapters - 5Gbps - Single Video - <6 ports Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX052X Product Title (Ultra-Short) USB C Adapter - HDMI Product Title (Short) USB-C Multiport Adapter - 4K HDMI/PD/GbE Product Title (Medium) USB C Multiport Adapter 4K HDMI - 2x USB-A USB 3.0- GbE - 60W PD - Mac & Windows Product Title (Standard) USB-C Multiport Adapter, USB-C Travel Dock w/4K HDMI, 60W PD Passthrough, GbE, 2x USB-A, Mini USB Type-C Docking Station, TAA Product Title (Long) USB-C Multiport Adapter - USB-C Travel Docking Station with 4K HDMI - 60W Power Delivery Pass-Through, GbE, 2pt USB-A 3.0 Hub - Portable Mini USB Type-C Dock for Laptop - TAA Product Title (AMZ) USB-C Multiport Adapter - USB-C Travel Docking Station with 4K HDMI - 60W Power Delivery Pass-Through, GbE, 2pt USB-A 3.0 Hub - Portable Mini USB Type-C Dock for Laptop , TAA (DKT30CHPD) Title Ingram (Part 1) USB C Multiport Adapter with Title Ingram (Part 2) HDMI - 4K - 2x USB 3.0 - GbE Website Product Headline Portable Docking Station | Mac & Windows® | GbE | Thunderbolt™ 3 Compatible Bullet 1 4-IN-1 TRAVEL DOCK: USB-C multiport adapter has 4K 30Hz UHD HDMI video output for a single display, 2x USB-A 3.0 (5Gbps) ports, Gigabit Ethernet (GbE), and 60W Power Delivery 2.0 charging pass through Bullet 2 EXTRA LONG CABLE: The portable USB-C mini dock’s 25cm (10 in.) attached cable provides extended reach to reduce port/connector strain on 2-in-1 devices or laptops on riser stands Bullet 3 WIDE DEVICE COMPATIBILITY: USB C multiport adapter for USB-C & Thunderbolt 3 laptops, Ultrabooks, Chromebooks, tablets & phones for brands like HP, Dell, Lenovo, MacBooks, Surface and Samsung Galaxy Bullet 4 WIDE OPERATING SYSTEM COMPATIBILITY: With automatic driver setup, this all-in-one USB 3.1 Gen 1 Type-C docking station supports Windows, macOS, Chrome OS, Ubuntu, Android (Galaxy S9 & up, Pixel 3) Bullet 5 POWERED BY LAPTOP OR EXTERNAL ADAPTER: This dock can draw power from the laptop USB bus or charge the laptop via PD-Passthrough if a USB-C power adapter is connected (12W for dock & 48W for charging) Bullets (Compact) USB-C travel dock w/ 4K 30Hz HDMI video display, 2x USB-A 3.0, GbE, 60W PD Pass Through - Portable mini dock w/ 10in cable - USB C multiport adapter for USB Type-C/Thunderbolt 3 laptops, Ultrabooks, Chromebook, tablets, phones - Windows/macOS/Android Bullets (Consolidated) 4-in-1 USB-C multiport adapter with 4K 30Hz HDMI video (single display)/2x USB-A 3.0 5Gbps/Gigabit Ethernet/60W Power Delivery pass through - 10" attached cable for extended reach to ports on 2-in-1s or device on riser - For USB Type-C/Thunderbolt 3 laptops Ultrabooks Chromebooks tablets phones from HP/Dell/Lenovo/MacBooks/Surface/Samsung - USB C travel dock for Windows/macOS/Chrome OS/Android - Portable USB-C mini docking station powered by laptop USB bus or external USB-C power adapter Marketing Copy Marketing Copy (No HTML) Applications - Connect to an external HDMI monitor for multitasking
- Connect to an HDMI TV in a hotel or hot desk space
- Deliver presentations on an HDMI TV or projector in a boardroom or classroom
Website Search Keyword - 4k hdmi adapter
- apple usb c adapter
- dell usb c adapter
- dell wd15
- dell xps 13 accessories
- mac adapter
- macbook adapter usb-c
- macbook usb c adapter
- multiport adapter
- portable docking station
- portable docking station for laptop
- powered usb c hub
- travel docking station for laptops
- type c docking station
- usb c adapter
- usb c adapter with charging
- usb c hdmi
- usb c hdmi multiport adapter
- usb c hub
- usb c multiport adapter
- usb c multiport adapter with hdmi
- usb c to ethernet
- usb c to hdmi
- usb c to hdmi adapter
- usb c video adapter
- usb type c docking station
- usb type c hub
- usb type c laptop dock
- usb type c multiport adapter
- usb type c to hdmi
- usb-c adapter
- usb-c digital av multiport adapter
- usb-c hdmi
- usb-c multiport adapter
- usb-c to hdmi
- usb-c to usb
- usb-c to usb adapter
- U444-06N-H4GUSC
- U442-DOCK11-S
- U442-DOCK10-S
- U444-06N-H4GU-C
- U444-06N-HGU-C
- U444-06N-H4GUBC
- U444-T6N-H4GUBC
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
Special Notes - A 4K-capable display is required to achieve 3840 x 2160p resolution (4K is also known as 4K x 2K)
- USB 3.0 is also known as USB 3.1 Gen 1; this connectivity standard offers speeds up to 5Gbps.
- Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your host USB-C port supports USB Power Delivery 2.0 and DP alt mode.
- The adapter can connect to a host laptop’s USB-C port that doesn’t support USB Power Delivery 2.0. However, in this configuration if a power adapter is connected to the multifunction adapter, it will not pass power through to your host laptop.
- Your laptop might have specific charging requirements. For example, if your laptop requires exactly 60W of power and an adapter consumes some of the 60W, your laptop might not recognize that it is getting enough power. For more information about Power Delivery, refer to the manufacturer of your hardware.
System and Cable Requirements - A host laptop with an available USB-C port (to ensure full adapter functionality, the host USB-C port must support USB Power Delivery 2.0 and DP alt mode)
- Optional: USB-C power adapter (for example, your laptop’s USB-C based power adapter)
Accessory Products - HDMM1
- HDMM3
- HDMM6
- HDMM8
- HDMM10
- HDMM12
- HDMM15
- HDMM20
- HDMM25
- HDMM30
- HDMIDVIMM6
- UUSBHAUB3
- UUSBHAUB6
- UUSBHAUB10
- N6PATCH1BL
- N6PATCH3BL
- N6PATCH6BL
- N6PATCH15BL
- USB31C5C1M
- USB315CC2M
- USB2C5C4M
- N6LPATCH3BK
Related Products - DKT30CHV
- DKT30CDVPD
- CDP2VGAUACP
- DKT30CHVW
- DKT30CHPDW
- CDP2HDUACP
- CDP2HDUACPW
- DKT30CHD
- DKT30CSDHPD
- MST30C2DPPD
- CDPVGDVHDBP
- CDPVGDVHDB
- CDPVGDVHDMDP
Constrained SKU Alternatives (Limited Stock) DKT31CHPDL Output Voltage (V) 5 DC Power Delivery 60W Power Source USB-Powered Cable Length (mm) 348 Color Black Humidity 0~85% RH (Non-condensing) Material Plastic Operating Temperature 0°C to 50°C (32°F to 122°F) Primary Material Plastic Product Length (mm) 96.000 Product Width (mm) 50.000 Product Height (mm) 15.000 Product Weight (g) 64.000 Storage Temperature -10°C to 65°C (14°F to 149°F) TAA Compliant Yes Auto MDIX Yes Compatible Networks 10/100/1000 Mbps Downstream Maximum Data Transfer Rate USB 3.2 Gen 1 (5Gbps) Full Duplex Support Yes Maximum Cable Length (mm) 307 Maximum Data Transfer Rate Maximum Digital Resolutions Maximum Supported Resolution 4K 30Hz (3840x2160) OS Compatibility - Windows 10
- Windows 8
- Windows 7
- Mac OS X El Capitan (10.11)
- Chrome OS
- macOS Sierra (10.12)
- macOS High Sierra (10.13)
- macOS Mojave (10.14)
- macOS Catalina (10.15)
- macOS Big Sur (11.0)
- Windows 11
- macOS Monterey (12.0)
- macOS Ventura (13.0)
- macOS Sonoma (14.0)
- Windows 11 ARM
- macOS Sequoia (15.0)
- Ubuntu
- macOS Tahoe (26.0)
UASP Support Yes USB Type and Rate USB 3.0 (5Gbps) Video Output Port HDMI Video Transport Technology USB-C (DP Alt-Mode) Wake-On-LAN (WOL) Yes Bus Type USB-C Chipset ID Host Connection Port USB-C Industry Standards Laptop Dock 4K Support Yes Laptop Dock Number of Displays 1 Laptop Dock / USB Hub Fast-Charge No Number of Displays 1 Other Ports Gigabit Ethernet Carton Depth (mm) 460 Carton Height (mm) 443 Carton Quantity 40 Carton Weight Gross (g) 8386 Included in Package - 1 - USB-C multiport adapter
- 1 - quick-start guide
Package Depth (mm) 210 Package Height (mm) 41 Package Width (mm) 146 Package Quantity 1 Package Weight (g) 186 Packaging Description USB-C Multiport Adapter - PD - 4K HDMI Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2016-06-21 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge No Comparable SKU DKT30CHV Digital Content Due Date 2016-06-14 Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FI,FR,HK,IE,IN,IT,JP,MX,NL,NZ,PE,SE,SG,UK,US Primary Technology USB-C Product Development Specialist Abhinav Pathak Product Information Creation Specialist (PICS) Dan Dagenais Product Manager Natalie Goodale Product Performance Specialist John Mardinly Product Photographer Caleigh Le Grand Target Production Release 2016-07-22 Tech Lead Sam Raskas Technical Writer Dan Dagenais Technology Lifecycle Mainstream
