DP2HDMIADAP
DisplayPort to HDMI Converter
Connect your HDMI® monitor or HDTV to a DisplayPort® equipped computer
Main Image
Product Images
Product Images
Product Name DisplayPort to HDMI Converter Product Number DP2HDMIADAP UPC 065030832427 Lifecycle status Active Warranty 3 Years Taxonomy Product > Docks, Hubs & Video Adapters > Video Adapters Category Level 1 Display and Video Adapters Category Level 2 DP and MDP Display Adapters Category Level 3 DP to HDMI Family DP to HDMI 1.3 Adapters Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX008X Country of Origin History (2) Vietnam Country of Origin Revision (2) XXXXXX170X Product Title (Short) DisplayPort to HDMI Adapter Converter Product Title (Medium) x Product Title (Standard) DisplayPort to HDMI Adapter, 1080p Compact DP to HDMI Adapter/Video Converter, VESA Certified, DP to HDMI Monitor, Passive Product Title (Long) DisplayPort to HDMI Adapter - 1080p Compact DP to HDMI Adapter/Video Converter - VESA DisplayPort Certified - Passive DP 1.2 to HDMI Monitor/Display/Projector Cable Adapter Product Title (AMZ) DisplayPort to HDMI Adapter - Compact DP to HDMI Adapter/Video Converter 1080p - VESA DisplayPort Certified - Passive DP 1.2 to HDMI Monitor/Display/Projector Cable Adapter (DP2HDMIADAP) Title Ingram (Part 1) DisplayPort to HDMI Video Adapte Title Ingram (Part 2) r Converter - M/F Website Product Headline Connect your HDMI® monitor or HDTV to a DisplayPort® equipped computer Bullet 1 PERFORMANCE: This DisplayPort 1.2 to HDMI adapter connects a DP desktop or laptop to an HDMI display, projector, monitor or TV | Supports HD 1920x1200 (1080p) video, 7.1ch Audio, HDCP 1.4 | VESA DisplayPort Certified Bullet 2 HOST COMPATIBILITY: DisplayPort to HDMI adapter tested for compatibility with DP++ source; Passive converter supports DP++ source connector incl workstations, desktops (AMD/Nvidia video cards), laptops, small form factor computers & docking stations Bullet 3 SMALL FORM FACTOR: With no attached cable and compact design, the adapter connects directly to your HDMI cable for a clean look | Use to connect primary monitor or projector or add a secondary display | Perfect for travel and easily fits into a bag pocket Bullet 4 STABLE CONNECTION: DP to HDMI adapter features a non-latching DP connector that is easy to disconnect from a hard to reach source | Tested with HDMI cables at extended lengths up to 35ft Bullet 5 EASY TO USE: With no software or drivers required, the DisplayPort to HDMI video adapter is OS independent; DP male to HDMI female Bullets (Compact) Passive DisplayPort to HDMI adapter - 1080p Video/7.1ch Audio/HDCP/DP 1.2; VESA DisplayPort Certified - Connects DP source to HDMI display/monitor/projector - Compact DP to HDMI adapter with no attached cable - Supports DP++ source - OS Independent Bullets (Consolidated) DisplayPort to HDMI adapter supports HD 1920x1200 (1080p)/7.1ch Audio/HDCP 1.4 | DP 1.2 | VESA DisplayPort Certified - Passive DP to HDMI adapter supports DP++ source incl workstations/desktops (AMD/Nvidia video cards)/laptops/docking stations - Compact; fits into any laptop bag | No attached cable | Connects DP host computer to an HDMI display/monitor/TV/projector - DP to HDMI video converter | Tested with HDMI cables up to 35ft | Male/Female - Driverless setup |OS independent Marketing Copy Marketing Copy (No HTML) Applications The DisplayPort® to HDMI® adapter allows for an easy and hassle free connection to any HDMI-enabled display Website Search Keyword - DisplayPort
- HDMI
- Video
- Converter
- Adapter
- P136-000-1
- P136-000
- P136-000-BP
- P136-000-1-BP
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
System and Cable Requirements DP++ port (DisplayPort ++) required on video card or video source (DVI and HDMI pass-through must be supported) Accessory Products - HDMM1
- HDMM3
- HDMM6
- HDMM8
- HDMM10
- HDMM12
- HDMM15
- HDDVIMM3
- HDMIDVIMM6
- HDMIDVIMM10
- HDMIDVIMM15
Related Products - DP2HD4K60S
- DP2HD4KADAP
- DP2HD4KS
- DP2HDMM1MB
- DP2HDMM3MB
- DP2HDMM5MB
- DP2HDMM2MB
- DP2HDMI2
- DP2HDMI
- DP2HDMIUSBA
- SLMPT2HD
- DP2HDSW
Color Black Humidity 65% ±10%RH Operating Temperature 5°C to 35°C (41°F to 95°F) Primary Material Plastic Product Length (mm) 55 Product Width (mm) 18 Product Height (mm) 9 Product Weight (g) 16 Storage Temperature -20°C to 60°C (-4°F to 140°F) TAA Compliant No Audio Specifications HDMI - 7.1 Channel Audio HDR Support No Maximum Cable Distance To Display 15200 Maximum Digital Resolutions 1920x1200 / 1080p Maximum Supported Resolution 1080p MTBF (hours) 3,506,778 hours Video Output Port HDMI Active or Passive Adapter Passive Audio Yes AV Input DisplayPort - 1.2 AV Output HDMI Converter Type Adapters Host Connection Port DisplayPort Number of Displays 1 Amount of recycled material in plastic packaging At Least 30% Carton Depth (mm) 334 Carton Height (mm) 220 Carton Quantity 600 Carton Weight Gross (g) 11402 Included in Package 1 - DisplayPort to HDMI Adapter Included In Package for Label 1 - DisplayPort to HDMI Converter Package Depth (mm) 47 Package Height (mm) 33 Package Width (mm) 89 Package Quantity 1 Package Weight (g) 20 Packaging Description DisplayPort® to HDMI® Adapter Packaging Description India DisplayPort to HDMI Converter Sub-Carton Depth (mm) 109 Sub-Carton Height (mm) 45 Sub-Carton Width (mm) 106 Sub-Carton Weight (g) 176 Connector 1 DisplayPort Connector 1 (Quantity) 1 Connector 2 HDMI Connector 2 (Quantity) 1 Amazon Merchandising Manager Kristian Haighton Artwork Due Date 2014-06-18 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge No Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FI,FR,HK,IE,IN,IT,JP,MX,NL,NZ,PE,SE,SG,UK,US Primary Technology None Product Development Specialist Abhinav Pathak Product Information Creation Specialist (PICS) Dan Dagenais Product Manager David Muzinic Product Performance Specialist John Mardinly Product Photographer Caleigh Le Grand Tech Lead Brian Linseman Technical Writer Dan Dagenais Technology Lifecycle Legacy
