DP2HDMIUSBA
DisplayPort to HDMI Adapter with USB Audio
Connect an HDMI® display to a DisplayPort® source with audio
Main Image
Product Images
Product Images
Product Images
Quick-Start Guide
Product Name DisplayPort to HDMI Adapter with USB Audio Product Number DP2HDMIUSBA UPC 065030842792 Lifecycle status Discontinued Warranty 3 Years Taxonomy Product > Legacy Discontinued Category Level 1 Display and Video Adapters Category Level 2 DP and MDP Display Adapters Category Level 3 DP to HDMI Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX012X Product Title (Short) Displayport to HDMI Adapter - USB Audio Product Title (Standard) DisplayPort to HDMI Adapter with USB Audio Product Title (Long) DisplayPort to HDMI Adapter with USB Audio Product Title (AMZ) DisplayPort to HDMI Adapter with USB Audio - DP to HDMI Converter Adapter - 1920x1080 (DP2HDMIUSBA) Title Ingram (Part 1) DisplayPort to HDMI Adapter with Title Ingram (Part 2) USB Audio Website Product Headline Connect an HDMI® display to a DisplayPort® source with audio Bullet 1 Easy to use cable, no software/drivers required Bullet 2 Supports HDTV resolutions up to 1080p (1920x1080) Bullet 3 DisplayPort® video with USB Audio pass-through to a single HDMI® cable Bullet 4 USB-Powered - No external power source required Bullet 5 Supports uncompressed, 2-channel audio such as LPCM Bullets (Consolidated) Connect an HDMI display to a DisplayPort source with audio - Compatible with DisplayPort equipped desktop computers such as Dell OptiPlex - Passive Single-Link/DP++/Dual-mode DisplayPort/Black - supports resolutions up to 1920x1200 - Connect your computer to an HDMI Television or Projector with USB audio - DP to HDMI/Display Port to HDMI/DisplayPort to TV/DP to HDMI display - Convert DisplayPort to HDMI and add PC USB audio to your HDMI output single Marketing Copy Applications - Deliver audio/video content from your DisplayPort-capable PC or Mac to your A/V devices (HDTV or receiver) for a larger viewing area and louder audio experience
- Ideal for digital entertainment centers, home offices, business conference rooms and trade show displays
- Keep your existing HDMI® monitor to be used with your DisplayPort-output device
Website Search Keyword - Adapter
- apple
- Converter
- DisplayPort
- HDMI
- mac
- DisplayPort to HDMI with Audio
- DisplayPort with audio
- Video
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
System and Cable Requirements DP++ port (DisplayPort ++) required on video card or video source (DVI and HDMI pass-through must be supported) Accessory Products - HDMM6
- HDMM10
- HDMM15
Related Products - MDP2HDMIUSBA
- DP2DVID
- DP2HDMI
- DP2VGA
- MDP2DVI
- MDP2HDMI
- MDP2VGA
- DP2DVI
Replacement Product DP2HDMI2 Power Consumption (In Watts) 2W (max) Power Source USB-Powered Cable Length (mm) 610 Color Black Humidity 10~85% RH Material Plastic Operating Temperature 0°C to 70°C (32°F to 158°F) Product Length (mm) 700 Product Width (mm) 55 Product Height (mm) 15 Product Weight (g) 84.8 Storage Temperature -10°C to 80°C (14°F to 176°F) TAA Compliant No Audio Specifications HDMI - 7.1 Channel Audio Maximum Cable Distance To Display 15200 Maximum Digital Resolutions 1920x1200 / 1080p Wide Screen Supported Yes Active or Passive Adapter Passive Audio Yes AV Input DisplayPort - 1.2 AV Output HDMI - 1.4 Converter Type Adapters Industry Standards LED Indicators 1 - Red - Power Carton Depth (mm) 370 Carton Height (mm) 275 Carton Quantity 60 Carton Weight Gross (g) 6422 Included in Package 1 - DisplayPort and USB Audio to HDMI Adapter Number of Sub-Cartons 6 Package Depth (mm) 200 Package Height (mm) 14 Package Width (mm) 220 Package Quantity 1 Package Weight (g) 92 Packaging Description DisplayPort® to HDMI® Adapter with USB Audio Packaging Description India DisplayPort® to HDMI® Adapter with USB Audio Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Quantity 10 Sub-Carton Weight (g) 971 Connector 1 DisplayPort Connector 1 (Quantity) 1 Connector 2 USB-A (480Mbps, 2.5W) Connector 2 (Quantity) 1 Connector 3 HDMI Connector 3 (Quantity) 1 Amazon Merchandising Manager Kristian Haighton Artwork Due Date 2014-06-18 Enhanced Gallery Designer Rob Selenis en-US Content Approved Yes Graphic Designer Shane Arnett Launch Markets (concatenated) CA,EU,UK,US Primary Technology None Product Development Specialist Abhinav Pathak Product Information Creation Specialist (PICS) Dan Dagenais Product Manager David Muzinic Product Performance Specialist John Mardinly Product Photographer Caleigh Le Grand Tech Lead Brian Linseman Technical Writer Dan Dagenais Technology Lifecycle None
