Main Image
DRW115SAT
Main Image
Product Name Professional SATA150 Drive Drawer Product Number DRW115SAT UPC 065030799645 Lifecycle status Discontinued Warranty 3 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan China Country of Origin North America China Product Title (Long) Serial ATA Drive Drawer with Shock Absorbers - Professional Series Bullet 1 Fits a single SATA drive into a front accessible 5.25" bay Bullet 2 Heavy duty aluminum construction for the drive caddy and bay Bullet 3 Key lockable drive caddy Bullet 4 Rubber shock absorbers Bullet 5 7,000+ insertion rating Marketing Copy Applications - Add additional hot-swap bays to a server or workstation computer
- Replace or upgrade old IDE backplane with a SATA backplane
- System builders who need to image many drives simultaneously and quickly
- Environments where drives need to be replaced/removed regularly, without external protection for the drives required after removal
- Be able to replace/remove individual drives from a storage array with minimal or no system down time
Website Search Keyword - DE110
- SC21J147
- S21J100
- StorCase
Accessory Products DRW115CADS Related Products DRW115SATBK Replacement Product DRW115SATBK Color Beige Material Aluminum Product Length (mm) 220 Product Width (mm) 148 Product Height (mm) 41 Product Weight (g) 980 TAA Compliant No General Specifications - HD Compatibility: 3.5 Inch SATA, SATA II, SATA III Hard Drives
- CPU Compatibility: PC or Mac with a 5.25 Inch Drive Bay
- Weight (w/o drive): 2.15 lbs (0.98 kg)
- Dimensions:
- : Inches: 8.6 x 5.75 x 1.61
- : Millimeters: 220 x 148 x 41
- Cooling Fan: 2 Ball-Bearing Fans
- Fan Enclosure: Plastic
- Drive Drawer Enclosure: Aluminum
- Enclosure Color: Beige
- Fan Dimensions: Inches: 1.57 x 1.57 x 0.39 Millimeters: 40 x 40 x 10
- Certifications: CE
- Note: Unit is model specific and is not meant for use with different models of drive drawer unless otherwise stated
- : 1x SATA Power 15 Pin Male
- : 1x SATA Data 7 Pin Male
- Hard Drive: 1x SATA Data 7 Pin Female
- : 1x SATA Power 15 Pin Female
- Internal: 1x LP4 Male
Fans 2 - 40 mm Front Door Key Lock Yes LED Indicators 1 - Power Carton Depth (mm) 550 Carton Height (mm) 260 Carton Quantity 20 Carton Weight Gross (g) 23949.6576 Package Depth (mm) 52 Package Height (mm) 253 Package Width (mm) 160 Package Weight (g) 1090 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 en-US Content Approved Yes Product Manager David Muzinic
