Main Image
DRW150ATABK
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
Product Name Black Aluminum ATA/133 Drive Drawer Product Number DRW150ATABK UPC 065030795555 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX075X Product Title (Long) Black Aluminum ATA/133 Removable Hard Drive Mobile Rack Drawer Bullet 1 Secure and affordable solution to store and transfer data Bullet 2 Ball-bearing fan maintains optimum cooling and increased air flow Bullet 3 LED indicators continuously show the operating status of the drive drawer Bullet 4 Key lock mechanism prevents a hard drive from being accidentally removed while in operation Bullet 5 Screw type stopper to avoid cover vibration while the HDD is working Marketing Copy Applications - Removable drive drawers can be used in homes, at work, offices and in schools
- Mobile solution for high-capacity databases and large applications
- A fast and easy way to make backup copies of your files, applications and company's critical data
Website Search Keyword - ino
- RJR110
- SC21B109
- StorCase
- removable drive enclosure
- mobile rack
- S21b109
- drw150ata
Color Black Material Aluminum Product Length (mm) 220 Product Width (mm) 148 Product Height (mm) 41 Product Weight (g) 860 TAA Compliant No General Specifications - Hard Drive Compatibility: All 3.5-Inch IDE Hard Drives
- CPU Compatibility: PC or Mac with a 5.25 Inch Drive Bay
- Weight (w/o drive): 1.90 Lbs (0.86 Kgs)
- Internal Connectors: Header: 40 Pin Female & LP4: 4 Pin Female
- External Connectors: Header: 40 Pin Male & LP4: 4 Pin Female
- Drive Drawer Dimensions:
- Inches: 9.00 x 5.75 x 1.61
- Millimeters: 220 x 148 x 41
- LED Indicators: Drive Activity & Drive Power
- Fan Enclosure: Plastic
- Drive Drawer Enclosure: Aluminum
- Enclosure Color: Black
- Fan Dimensions: 1.57 x 1.57 x 0.39 Inches (40 x 40 x 10 mm)
- Certifications: CE
- Note: Unit is model specific and is not meant for use with different models of drive drawer unless otherwise stated
Fans 1 - 40 mm Front Door Key Lock Yes LED Indicators - 1 - Power
- 1 - Activity
Carton Depth (mm) 550 Carton Height (mm) 260 Carton Quantity 20 Carton Weight Gross (g) 19800 Package Depth (mm) 47 Package Height (mm) 235 Package Width (mm) 152 Package Weight (g) 920 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 IDE / PATA (ATA/133) Connector 1 (Quantity) 1 Connector 2 IDE / PATA (ATA/133) Connector 2 (Quantity) 1 Connector 3 LP4 / Molex Power (4-Pin, 5V / 12V) Connector 3 (Quantity) 1 Connector 4 LP4 / Molex Power (4-Pin, 5V / 12V) Connector 4 (Quantity) 1 en-US Content Approved Yes Product Manager David Muzinic
