Main Image
DRW150SCSI
Main Image
Product Images
Product Images
Product Images
Product Images
Product Images
Product Images
Product Name SCSI U320 Removable Drive Drawer Product Number DRW150SCSI UPC 065030795456 Lifecycle status Discontinued Warranty 2 Years Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX075X Product Title (Long) 3.5in SCSI U320 Removable Hard Drive Mobile Rack for 5.25in Bay Bullet 1 Supports Ultra 160 & 320 SCSI with data transfer rates up to 320 MBytes/sec Bullet 2 Secure and affordable solution to store and transfer data Bullet 3 Two Ball Bearing fans, front and rear, maintain optimum cooling and increased air flow Bullet 4 Bay is built with a key lock mechanism to prevent the hard drive from being accidentally removed while in operation Bullet 5 4 LED indicators continuously show the operating status of the drive drawer Marketing Copy Applications - Can be conveniently used as a mobile back-up system
- Excellent for use in servers, storage subsystems and high-end workstations
- Optimal for mission critical control PCs where downtime must be minimized
- Ideal for environments using RAID storage applications which includes multimedia, video streaming and digital broadcasting
- Mobile solution for high-capacity databases and large applications
Website Search Keyword - DE100
- DE110
- DE100I-SW160
- S21A100
- StorCase
- removable drive enclosure
- mobile rack
Accessory Products 150SCSIBKCAD Related Products DRW150SCSIBK Color Beige Material Aluminum Product Length (mm) 224 Product Width (mm) 148 Product Height (mm) 41 Product Weight (g) 980 TAA Compliant No General Specifications - HD Compatibility: All 3.5" SCSI Hard Drives including Ultra160 & Ultra320
- CPU Compatibility: PC or Mac with a 5.25 Inch Drive Bay
- Weight (without drive): 1.90 lbs (0.98 kg)
- Connectors:
- Internal: Header – 68 Pin Female & LP4 – 4 Pin Female
- External: Header – 68 Pin Male & LP4 – 4 Pin Male
- Drive Drawer Dimensions:
- Inches: 8.85 x 5.75 x 1.61
- Millimeters: 224 x 148 x 41
- LED Indicators:
- Drive Activity: Yellow
- Drive Power: Green
- Fan Status: Fan Failure - Red & Standby Fan - Green
- Temperature: Normal - Green & Overheating - Red
- Cooling Fan: 2 Ball-Bearing Fans
- Drive Drawer Enclosure: Aluminum
- Enclosure Color: Beige
- Fan Dimensions:
- Inches: 1.57 x 1.57 x 0.39
- Millimeters: 40 x 40 x 10
- Certifications: CE
- Note: Unit is model specific and is not meant for use with different models of drive drawer unless otherwise stated
Fans 2 - 40 mm Front Door Key Lock Yes LED Indicators - 1 - Power
- 1 - Activity
- 1 - Fan Failure
- 1 - Temperature Warning
Carton Depth (mm) 550 Carton Height (mm) 260 Carton Quantity 20 Carton Weight Gross (g) 20400 Package Depth (mm) 48 Package Height (mm) 240 Package Width (mm) 155 Package Weight (g) 960 Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 HPDB68 SCSI-3 (68-Pin) Connector 1 (Quantity) 1 Connector 2 HPDB68 SCSI-3 (68-Pin) Connector 2 (Quantity) 1 Connector 3 LP4 / Molex Power (4-Pin, 5V / 12V) Connector 3 (Quantity) 1 Connector 4 LP4 / Molex Power (4-Pin, 5V / 12V) Connector 4 (Quantity) 1 en-US Content Approved Yes Product Manager David Muzinic
