DS8100POE
8 Port 10/100 Mbps Desktop Switch with 4 Port PoE Switch
Rugged PoE Ethernet Switch for Powered Devices
Main Image
Product Images
Product Images
Product Name 8 Port 10/100 Mbps Desktop Switch with 4 Port PoE Switch Product Number DS8100POE UPC 065030836067 Warranty 2 Years Taxonomy Product > Legacy Discontinued Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) 1 Country of Origin History (2) China Product Title (Short) 8 Port 10/100 Desktop Switch w/ PoE Product Title (Standard) StarTech.com 8 Port 10/100 Mbps Desktop Switch with 4 Port PoE Switch Product Title (Long) 8 Port 10/100 Mbps Desktop Switch with 4 Port PoE Switch Title Ingram (Part 1) 8 Port 10/100 Mbps Desktop Switc Title Ingram (Part 2) h with 4 Port PoE Switch Website Product Headline Rugged PoE Ethernet Switch for Powered Devices Bullet 1 PoE support: up to 15.4W per each PoE port with a total offering of 53W combined Bullet 2 All 8 RJ-45 ports support 10BaseT/100BaseTX and Full-Duplex/Half-Duplex Auto-negotiation function Bullet 3 Auto MDIX (crossover) function Bullet 4 IEEE 802.3 10BaseT Ethernet, 802.3u 100BaseTX Fast Ethernet, and IEEE802.3af compliant Bullet 5 IEEE 802.3x compliant flow control for full duplex and backpressure for half-duplex Marketing Copy Applications - Provides a 200Mbps link for servers
- Segmenting network hubs and access points for improved network performance
- Small business networks requiring fast data transfer
- Provide power and data connections to remote Wireless AP and HUBs
- Provide power and data connections to IP Phones
- Provide power and data connections to Security Camera, recorders, and other devices
- Powering and connecting to Radio Frequency Identification (RFID) devices
Website Search Keyword - 10/100
- 8 port
- Ethernet Network Adapter
- PoE
- IEEE 802.3af
- Fast Ethernet
- CAT5
- Cat5e
- Switch
- Unmanaged
- Power over Ethernet
- PSE
- Power Sourcing Equipment
Accessory Products - ET90110SC
- ET90110ST
- M45PATCH100B
- M45PATCH10BL
- M45PATCH15BL
- NETRS2321POE
- MCM110SC2P
- MCM110ST2P
Related Products - DS16105
- DS5107
- DS8107
Input Current 1400mA Input Voltage 115V-230V AC Output Current 1.25A Output Voltage (V) 48 DC Power Source AC Adapter Included Plug Type N Center Tip Polarity Positive Color Black Humidity 90% RH Operating Temperature 0°C to 40°C (32°F to 104°F) Product Length (mm) 171 Product Width (mm) 98 Product Height (mm) 27 Product Weight (g) 1150 Storage Temperature -40°C to 70°C (-40°F to 158°F) TAA Compliant No Auto MDIX Yes Full Duplex Support Yes Maximum Data Transfer Rate 100Mbps (Half Duplex); 200Mbps (Full Duplex) LED Indicators - 1 - Power Indicator (On/Off)
- 1 - PoE MAX Indicator (Flashing - >=53W, Solid - >=43W, Off - <43W)
- 4 - PoE Ports (Green - PoE device connected, Red - PoE short/Over PD's Class, Off - No PoE device detected
- 8 - Link/Activity (Flashing - Transmit/Receive, Solid - Link, Off - No Device)
- 8 - 100Mbps (On - 100Mbps device detected, Off - 10Mbps device connected)
Included in Package - 1 - 8 Port Ethernet Switch
- 1 - Instruction Manual
- 1 - Power Adapter
- 1 - Rubber Feet
- 3 - Power Cords (UK, NA, EU)
Connector 1 RJ-45 Connector 1 (Quantity) 8 en-US Content Approved Yes
