EC13941A1B
2 Port ExpressCard34 Firewire Adapter 1A 1B Port
Add FireWire 400 and FireWire 800 port through your laptop ExpressCard slot
Main Image
Product Images
Product Images
Product Images
Product Images
Product Name 2 Port ExpressCard34 Firewire Adapter 1A 1B Port Product Number EC13941A1B UPC 065030832809 Lifecycle status Discontinued Warranty Lifetime Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX054X Product Title (Short) 1b 1a ExpressCard FireWire Adapter Card Product Title (Standard) StarTech.com 1b 1a ExpressCard FireWire Adapter Card Product Title (Long) 2 Port 1b 1a ExpressCard 34mm Laptop 1394 FireWire Adapter Card Title Ingram (Part 1) 2 Port ExpressCard 34mm Laptop Title Ingram (Part 2) 1394 FireWire Adapter Card Website Product Headline Add FireWire 400 and FireWire 800 port through your laptop ExpressCard slot Bullet 1 One 9-pin FireWire 800 port with transfer rates up to 800Mbps Bullet 2 One 6-pin FireWire 400 port with transfer rates up to 400Mbps Bullet 3 Compliant with IEEE 1394b and backward compatible with IEEE 1394a - 2000 as well as 1394-1995 standards Bullet 4 Optional external power support for high-powered FireWire devices Bullet 5 Fits in both 34mm and 54mm ExpressCard slots Marketing Copy Applications - Add a high-speed FireWire port to a laptop without any FireWire ports
- Connect a digital camera to a laptop with an ExpressCard slot to download photos and video
- Connect a high-speed external hard drive to an ExpressCard-enabled system
Website Search Keyword - IEEE 1394
- 1394a
- 1394b
- firewire expresscard
- firewire 800
- firewire 400
- 2 port expresscard
- dual firewire adapter
- IEEE 1394b
- IEEE 1394a
Special Notes Optional power adapter specifications: 12VDC, 2000+ mA, Center positive, Type H plug Accessory Products - 1394_94_6
- 1394_94_10
- 1394_96_6
- 1394_96_10
- 1394_99_6
- 1394_99_10
- 1394_6
- 1394_10
- 1394_15
- 1394_46_6
- 1394_46_10
- 1394_46_15
- ECBRACKET
Related Products - PEX1394_2
- PEX1394A2DV
- PEX1394B3
- EC1U2F
- EC13942
- PEX2EC
- CB1394_2
- CB1394
- PCI1394_2
- PCI1394_2LP
- EC1394B2
Power Source Not Included (not required for standard applications) Product Length (mm) 115 Product Width (mm) 44 Product Height (mm) 20 Product Weight (g) 31 TAA Compliant No Maximum Data Transfer Rate OS Compatibility - Linux
- Windows 2000
- Windows XP
- Windows Vista
- Windows 7
- Mac OS X
- Windows 8
Bus Type ExpressCard Card Type 34mm ExpressCard Chipset ID LSI - FW643 Interface/Bridge FireWire 400 (1394a) Carton Depth (mm) 500 Carton Height (mm) 350 Carton Quantity 40 Carton Weight Gross (g) 0 Included in Package - 1 - ExpressCard FireWire Card
- 1 - FireWire Cable
- 1 - Software CD
- 1 - Instruction Manual
Package Depth (mm) 145 Package Height (mm) 60 Package Width (mm) 235 Package Weight (g) 178 Packaging Description 1b 1a ExpressCard FireWire Card Packaging Description India 1b 1a ExpressCard FireWire Card Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 ExpressCard/34 Connector 1 (Quantity) 1 Connector 2 FireWire 400 (6-Pin, 400Mbps, Bus Power) Connector 2 (Quantity) 1 Connector 3 FireWire 800 (9-Pin, 800Mbps, Bus Power) Connector 3 (Quantity) 1 en-US Content Approved Yes Product Manager Rafal Gwozdz
