EC230USB
2 Port USB 2.0 ExpressCard Adapter
Add two USB 2.0 ports to a computer through an ExpressCard slot
Main Image
Product Images
Product Images
Product Images
Product Images
BOM Image
Product Name 2 Port USB 2.0 ExpressCard Adapter Product Number EC230USB UPC 065030824255 Lifecycle status Discontinued Warranty Lifetime Taxonomy Product > Legacy Discontinued Category Level 1 Legacy Category Category Level 2 Legacy Sub-Category Category Level 3 Legacy Group Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX072X Product Title (Short) 2 Port ExpressCard USB Adapter Card Product Title (Standard) StarTech.com 2 Port ExpressCard Laptop USB 2.0 Adapter Card - USB adapter - ExpressCard - USB, Hi-Speed USB - 2 ports Product Title (Long) 2 Port ExpressCard Laptop USB 2.0 Adapter Card Product Title (AMZ) 2 Port ExpressCard Laptop USB 2.0 Adapter Card - USB adapter - ExpressCard - USB, Hi-Speed USB - 2 ports (EC230USB) Title Ingram (Part 1) 2 Port ExpressCard Laptop USB 2. Title Ingram (Part 2) 0 Adapter Card Website Product Headline Add two USB 2.0 ports to a computer through an ExpressCard slot Bullet 1 Supports all available USB transfer rates: High-speed (480Mbps), Full-speed (12Mbps), and Low-speed (1.5Mbps) Bullet 2 Compliant with Express Card (34mm) Type II Standard Bullet 3 Backward compatible with USB version 1.1 Bullet 4 Optional power adapter accommodates high current consumption devices Bullet 5 Easy Plug & Play installation Marketing Copy Marketing Copy (No HTML) Applications - MP3 players
- Digital cameras
- PDAs
- Portable hard drives
- Mice and keyboards
- External CDR/RWs
- DVD drives
- Flash card readers/writers
- Joysticks
- Printers
- Scanners
- Webcams
Website Search Keyword - ExpressCard
- USB ExpressCard
- 2 Port ExpressCard
Accessory Products - ST4205USB
- USB2HAB6
- USB2HAB10
- USB2HAB15
- USB2HAB6T
- USB2HAB10T
- USB2HAB15T
- PCI2PCMCIA1
- PCI2PCMCIA2
- PCI2PCMCIA1E
- ECBRACKET
Output Voltage (V) 5 DC Power Source Not Included (not required for standard applications) Center Tip Polarity Positive Color Black & Silver Product Length (mm) 0.000 Product Width (mm) 0.000 Product Height (mm) 0.000 Product Weight (g) 0.000 TAA Compliant No Maximum Data Transfer Rate 480 Mbps OS Compatibility - Windows 2000
- Windows XP
- Windows Vista
- Windows Server 2003
- Windows 7
- Windows Server 2008 R2
- Linux
- Mac OS X
- Windows 8
Bus Type ExpressCard Card Type 34mm ExpressCard Chipset ID Renesas/NEC - µPD720114 Interface/Bridge USB 2.0 Carton Depth (mm) 550 Carton Height (mm) 380 Carton Quantity 50 Carton Weight Gross (g) 5700 Included in Package - 1 - 2 Port USB ExpressCard Adapter
- 1 - Instruction Manual
Package Depth (mm) 72 Package Height (mm) 180 Package Width (mm) 172 Package Weight (g) 90 Packaging Description 2 Port ExpressCard USB 2.0 Card Packaging Description India 2 Port ExpressCard USB 2.0 Card Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 ExpressCard/34 Connector 1 (Quantity) 1 Connector 2 USB-A (480Mbps, 2.5W) Connector 2 (Quantity) 2 en-US Content Approved Yes Product Manager Aaron Rabena
