Main Image

FAN775

Socket 775 Intel CPU Fan

Main Image

Product Images

Product Images

Product Images

Product Images

Product Images

Product Name	Socket 775 Intel CPU Fan
Product Number	FAN775
UPC	065030812214
Lifecycle status	Discontinued
Warranty	2 Years
Taxonomy	Product > Legacy Discontinued
Category Level 1	Legacy Category
Category Level 2	Legacy Sub-Category
Category Level 3	Legacy Group
Country of Origin Europe & Japan	China
Country of Origin North America	China
Country of Origin History (1)	China
Country of Origin Revision (1)	XXXXXX027X

Manual https://images.salsify.com/image/upload/s--bQgV45qi--/d7d8a5dfd95613b76468e7d0890f4484e1c94f6e.pdf

Product Title (Long)	Intel Socket 775 Heatsink with Fan.
Bullet 1	Improves cooling capacity of the CPU cooler by thermally bonding the CPU to the heatsink (thermal transfer compound included)
Bullet 2	Large aluminum heatsink provides efficient heat dissipation
Bullet 3	StarTech.com’s CPU cooler heatsink / fan combination delivers better cooling performance and keeps your system stable
Bullet 4	Quiet and Stylish Ball Bearing Fan!
Marketing Copy	FAN775 is built to cool the power hungry 775 Intel Processor. The extruded aluminum uses aluminum alloy material and the radial fin design directs hot air away from the CPU. Comes complete with thermal transfer compound for quick, professional quality installation.
Applications	Intel Socket 775, P4 (up to 3.8 GHz)
Website Search Keyword	socket LGA 775 cpu cooler

Air Flow Rate	26.97 ~ 52.4 CFM
General Specifications	Heatsink Dimensions: 3.86 x 3.86 x 3.50 in. Fan Dimension: 92 x 92 x 32 mm Supports up to Intel P4 3.8 GHz Weight: 0.85 Lbs Thermal Resistance: 0.23° C/W
Noise Level	27 dBA
RPM	1500 ~ 3500

Fan Bearing Type	Ball Bearing
Number of Conductors	4 Pin Connector

Color	Blue
TAA Compliant	No

Connector 1	Fan TX3 (3-Pin, 12V)
Connector 1 (Quantity)	1

en-US Content Approved	Yes
Product Manager	Daryl Hunt
