Main Image
HB30A4AIB
4 Port USB 3 0 Hub USB A to 4x USB A
Portable USB 3.2 Gen 1 to USB Hub | Bus-Powered | USB 3.2 Gen 1
Main Image
Product Images
Product Images
Product Images
Quick-Start Guide
Product Name 4 Port USB 3 0 Hub USB A to 4x USB A Product Number HB30A4AIB UPC 065030874243 Lifecycle status Active Warranty 2 Years Taxonomy Product > Docks, Hubs & Video Adapters > USB Hubs Category Level 1 Hubs Category Level 2 USB-A Hubs Category Level 3 USB-A Bus Powered Hubs - 5Gbps Family USB-A Bus Powered Hubs - 5Gbps - 4-Port - All A Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX028X Country of Origin History (2) Vietnam Country of Origin Revision (2) XXXXXX132X Product Title (Ultra-Short) 4-Port USB 3 Hub Product Title (Short) 4 Port USB 3.0 Hub - USB-A Port Switches Product Title (Medium) 4-Port USB 3.0 Hub - 4x USB-A Ports w/ Individual On/Off Switches - Bus-Powered Product Title (Standard) 4 Port Bus Powered USB Hub with Individual On/Off Switches, USB 3.0 5Gbps Expansion Hub, Laptop USB-A to USB-A Splitter Product Title (Long) 4 Port Bus Powered USB Hub with Individual On/Off Switches, USB 3.0 (5Gbps) Expansion Hub, Desktop/Laptop USB-A to USB-A Splitter Product Title (AMZ) 4 Port Bus Powered USB Hub with Individual On/Off Switches, USB 3.0 (5Gbps) Expansion Hub, Desktop/Laptop USB-A to USB-A Splitter Title Ingram (Part 1) 4-Port USB 3.0 Hub - 4x USB-A - Title Ingram (Part 2) With Individual On/Off Switches Website Product Headline Portable USB 3.2 Gen 1 to USB Hub | Bus-Powered | USB 3.2 Gen 1 Bullet 1 4 PORT USB A HUB: Expand the connectivity of a USB-A laptop or desktop computer by adding 4x USB-A ports with individual port switches, using this USB hub Bullet 2 INDIVIDUAL PORT SWITCHES: Each USB-A port has an on/off push button (w/ LEDs) to disconnect power to devices; Save energy by turning off SSD/thumb drives, web cams, headsets, etc. when not in use Bullet 3 MANAGE POWER & RESET DEVICES: Port switches enable you to direct power to selected peripherals, power on/off without physically unplugging the device which reduces wear and tear on the USB port Bullet 4 COMPACT & PORTABLE: A lightweight bus powered USB 5Gbps hub with black plastic housing, 9.8" (25 cm) attached USB-A host cable and small form factor [3.3in (85mm) x 1.4in (35mm) x 0.8in (1.9cm)] Bullet 5 WIDE COMPATIBILITY: USB Type-A laptop hub is OS independent & no drivers to install; supporting operating systems including Windows, macOS, Linux, Chrome OS and Android; USB 1.0/2.0/3.0 device compatible Bullets (Compact) 4 port USB 3.2 Gen 1 hub with individual port switches - 4x USB Type-A ports - SuperSpeed 5Gbps - Bus powered USB hub (4.5W shared w/downstream devices) - On/off power switches/LEDs on each port - 9.8in USB-A host cable - OS independent Bullets (Consolidated) 4-Port USB 3.2 Gen 1 Hub | From a USB-A host port add 4x USB Type-A ports with individual port switches | SuperSpeed 5Gbps (USB 3.2 Gen 1) - On/off power buttons on each USB-A port saves energy | Works with SSDs/thumb drives/web cams/headsets - Direct power to selected peripherals/Power ports on/off without unplugging devices reducing wear on USB port - Bus powered USB laptop hub | 4.5W of power shared w/all connected devices - Compact housing | 9.8" attached host cable - OS independent Marketing Copy Marketing Copy (No HTML) This portable 4 -port USB 3.2 Gen 1 hub gives you an easy way to add four USB 3.2 Gen 1 Type-A ports to your laptop, with individual power switches to save power. The USB port expander plugs easily into your laptop's USB Type-A port. Plus, it's bus-powered for easy portability. Use your existing computer accessories such as flash drives, mouse, keyboard and external hard drives. The USB 3.2 Gen 1 hub with on/off switch expands your computer's USB Type-A port into four USB 3.2 Gen 1 (Type-A) ports, and it's backward compatible with your older USB 2.0 devices. Each port on the USB 3.2 Gen 1 hub has its own power switch so you can turn off devices when they're not in use. That means you can better manage power consumption for your USB devices, without having to physically disconnect the device or cable. With its compact, lightweight design, this USB to USB splitter is perfect for portable use. The versatile USB 3.2 Gen 1 hub with on/off switch is bus-powered, with no need for an external power adapter. You can travel lighter with fewer cables to carry with you. The 4-Port USB 3.2 Gen 1 hub installs automatically when you connect it to your laptop, so you can be up and running in seconds. Applications - Take the hub with you when you travel, to connect your USB devices
- Switch unused ports off when using high power-consuming USB equipment
- Perfect for office, hot-desk, home office and bring-your-own-device environments
Website Search Keyword - USB 3.0 hub
- USB splitter
- USB to USB
- USB 3.0 hub with on/off switch
- USB hub
- Multi USB port
- 4 port USB 3.0 hub
- USB port expander
- hub
- port expander
- port splitter
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Corrugated Fiberboard
- UKCA - Safety - Electrical - United Kingdom - UK Electrical Equipment (Safety) Regulations 2016
Special Notes System and Cable Requirements - Available USB Type-A port - USB 3.0 (5Gbps)
- The total available power output of the HB30A4AIB is based on the available input power and is shared between all downstream facing ports.
Accessory Products - USB3SEXT2MBK
- USB3EXT6INBK
- USB3AUB15CMS
- USB3SAB1MRA
- USB3AU1MRS
- USB3AUB1MS
- USB3CAUB1M
- USB3AU1MLS
- USB3SEXT1M
- USB3CAB1M
- USB31AC1M
Related Products - HB30C4AB
- HB30C3A1CFB
- HB30C3A1GEA
- HB30C3A1GE
- HB30C3A1CFBW
- HB30C5A2CST
- HB30C3A1CST
- HB30C3APD
- HB30C3APDW
- HB30C3A1CFS
- HB30C3AGEPD
- HB30C4ABW
- HB30C4AFS
- HB30C4AFPD
Constrained SKU Alternatives (Limited Stock) HB30C4AIB Input Voltage 5V DC Output Voltage (V) 5 DC Power Source USB-Powered Cable Length (mm) 250 Color Black Humidity 20~80% RH (Non-condensing) Material Plastic Operating Temperature 0°C to 55°C (32°F to 131°F) Primary Material Plastic Product Length (mm) 325 Product Width (mm) 34.900 Product Height (mm) 19.200 Product Weight (g) 43.000 Storage Temperature -10°C to 70°C (14°F to 158°F) TAA Compliant No Downstream Maximum Data Transfer Rate USB 3.2 Gen 1 (5Gbps) Fast Charge Ports (BC 1.2) No Maximum Data Transfer Rate 5 Gbps (USB 3.2 Gen 1) MTBF (hours) 841,302 hours OS Compatibility OS Independent UASP Support Yes USB Type and Rate USB 5Gbps Bus Type USB 3.2 Gen 1 (5Gbps) Chipset ID VIA/VLI - VL817 Ethernet Port No Industry Standards USB 3.1 Gen 1 (USB 3.0) - Backward compatible with USB 2.0 and 1.1 Interface/Bridge USB 3.2 Gen 1 (5Gbps) Laptop Dock / USB Hub Fast-Charge No LED Indicators 4 - Port Power USB-C Device Port(s) No USB-C Host Connection No Carton Depth (mm) 479 Carton Height (mm) 452 Carton Quantity 70 Carton Weight Gross (g) 8418 Included in Package - 1 - hub
- 1 - quick-start guide
Included In Package for Label - 1 - hub
- 1 - quick-start guide
Package Depth (mm) 146 Package Height (mm) 32 Package Width (mm) 174 Package Quantity 1 Package Weight (g) 108 Packaging Description 4-Port USB 3.0 Hub - Individual Port Power - A to 4x A Packaging Description India 4-Port USB 3.0 Hub - USB-A to 4x USB-A Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-A (5Gbps, 4.5W) Connector 1 (Quantity) 4 Connector 2 USB-A (5Gbps, 4.5W) Connector 2 (Quantity) 1 Amazon Merchandising Manager Kristian Haighton Artwork Due Date 2018-05-16 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge No Digital Content Due Date 2018-07-06 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FI,FR,IE,IN,IT,JP,MX,NL,NZ,PE,SE,SG,UK,US Primary Technology None Product Development Specialist Sam Bushell Product Information Creation Specialist (PICS) Maria Powell Product Manager Natalie Goodale Product Performance Specialist Aaron Bens Product Photographer Caleigh Le Grand Target Development Completion Date 2018-06-01 Target Production Release 2018-06-01 Tech Lead Stefan Tirolese Technical Writer Maria Powell Technology Lifecycle Mainstream
