HB30C4AIB
Portable 4 Port USB 3 0 Hub with individual port p
Portable USB-C to USB 3.2 Gen 1 Hub | Bus-Powered
Main Image
Product Images
Product Images
Product Images
Product Images
Quick-Start Guide
Product Name Portable 4 Port USB 3 0 Hub with individual port p Product Number HB30C4AIB UPC 065030874335 Lifecycle status Active Warranty 2 Years Taxonomy Product > Docks, Hubs & Video Adapters > USB Hubs Category Level 1 Hubs Category Level 2 USB-C Hubs Category Level 3 USB-C Bus Powered Hubs - 5Gbps Family USB-C Bus Powered Hubs - 5Gbps - 4-Port - All A Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX028X Country of Origin History (2) Vietnam Country of Origin Revision (2) XXXXXX132X Product Title (Ultra-Short) 4-Port USB C Hub Product Title (Short) 4 Port USB C Hub - USB-A Port Switches Product Title (Medium) 4-Port USB C Hub - Portable USB-C to USB 3.0 Hub - Individual On/Off Switches Product Title (Standard) 4 Port Bus Powered USB C Hub with Individual On/Off Switches, USB 3.0 5Gbps Expansion Hub, Laptop USB-C to USB-A Splitter Product Title (Long) 4 Port Bus Powered USB C Hub with Individual On/Off Switches, USB 3.0 (5Gbps) Expansion Hub, Desktop/Laptop USB-C to USB-A Splitter Product Title (AMZ) 4 Port Bus Powered USB C Hub with Individual On/Off Switches, USB 3.0 (5Gbps) Expansion Hub, Desktop/Laptop USB-C to USB-A Splitter Title Ingram (Part 1) 4-Port USB C Hub - 4x USB-A w/ Title Ingram (Part 2) Individual On/Off Switches Website Product Headline Portable USB-C to USB 3.2 Gen 1 Hub | Bus-Powered Bullet 1 4 PORT USB C HUB: Expand the connectivity of a USB-C laptop by adding 4x USB-A ports with individual port switches, using this USB hub; 15W power shared between downstream devices Bullet 2 INDIVIDUAL PORT SWITCHES: Each USB-A port has an on/off push button (w/ LEDs) to disconnect power to devices; Save energy by turning off SSD/thumb drives, web cams, headsets, etc. when not in use Bullet 3 MANAGE POWER & RESET DEVICES: Port switches enable you to direct power to selected peripherals, power on/off without physically unplugging the device which reduces wear and tear on the USB port Bullet 4 COMPACT & PORTABLE: A lightweight bus-powered adapter hub with black plastic housing, 9.8" (25 cm) attached USB-C host cable and small form factor [3.3in (85mm) x 1.4in (35mm) x 0.8in (1.9cm)] Bullet 5 WIDE COMPATIBILITY: USB-C laptop hub is OS independent, supporting major operating systems including Windows, macOS, Linux, iPadOS, Chrome OS and Android; USB 3.0/2.0/1.0 device compatible Bullets (Compact) Bus-powered 4 port hub with individual port switches - USB-C to 4x USB Type-A ports - SuperSpeed 5Gbps (USB 3.2 Gen 1) - 15W/3A@5V of power - On/off power switches/LEDs on each port - 9.8in (25cm) USB-C host cable - OS independent Bullets (Consolidated) Bus-powered 4-Port USB-C Hub; From a USB-C host port add 4x USB Type A ports with individual port switches | SuperSpeed 5Gbps (USB 3.2 Gen 1 or USB 3.2 Gen 1) - On/off power buttons on each USB-A port saves energy | Works with SSDs/thumb drives/web cams/headsets - Direct power to selected peripherals/Power ports on/off without unplugging devices reducing wear and tear on USB port - Power up to 15W shared with all connected devices - Compact housing; 9.8" attached host cable - OS independent Marketing Copy Marketing Copy (No HTML) Applications - Take the hub with you when you travel, to connect your USB devices
- Switch unused ports off when using high power-consuming USB equipment
- Perfect for office, hot-desk, home office and bring-your-own-device environments
Website Search Keyword - USB C hub
- USB C to USB 3.0 Hub
- 4 port USB hub
- USB hub
- USB Type C hub
- USB C to USB hub
- 4-port USB 3.0 hub
- USB C to USB 3.0 hub
- USB C to multiple USB
- Port expander
- hub
- USB splitter
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- Triman/Info-Tri - Manual - Waste - European Union - Print Paper
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- Triman/Info-Tri - Packaging - Waste - European Union - Paper Box
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
Special Notes System and Cable Requirements - Available USB Type-C port - USB 3.0 (5Gbps)
- The total available power output of the HB30C4AIB is based on the available input power and is shared between all downstream facing ports.
Accessory Products - USB3SEXT2MBK
- USB3EXT6INBK
- USB3AUB15CMS
- USB3SAB1MRA
- USB3AU1MRS
- USB3AUB1MS
- USB3CAUB1M
- USB3AU1MLS
- USB3SEXT1M
- USB3CAB1M
- USB31AC1M
- HB30A4AIB
Related Products - HB30C4AB
- HB30C3A1CFB
- HB30C3A1GEA
- HB30C3A1GE
- HB30C3A1CFBW
- HB30C5A2CST
- HB30C3A1CST
- HB30C3APD
- HB30C3APDW
- HB30C3A1CFS
- HB30C3AGEPD
- HB30C4ABW
- HB30C4AFS
- HB30C4AFPD
Input Voltage 5V DC Output Voltage (V) 5 DC Power Delivery No PD Pass-Through Power Source USB-Powered Cable Length (mm) 250 Color Black Humidity 20~80% RH (Non-condensing) Material Plastic Operating Temperature 0°C to 55°C (32°F to 131°F) Primary Material Plastic Product Length (mm) 85.000 Product Width (mm) 343.000 Product Height (mm) 17.5 Product Weight (g) 42.000 Storage Temperature -10°C to 70°C (14°F to 158°F) TAA Compliant No Downstream Maximum Data Transfer Rate USB 3.2 Gen 1 (5Gbps) Fast Charge Ports (BC 1.2) No Maximum Data Transfer Rate 5 Gbps (USB 3.2 Gen 1) MTBF (hours) 841,302 hours OS Compatibility OS Independent UASP Support Yes USB Speed USB 3.2 Gen 1 (5Gbps) USB Type and Rate USB 5Gbps Bus Type USB 3.2 Gen 1 (5Gbps) Chipset ID VIA/VLI - VL817 Ethernet Port No Industry Standards USB 3.1 Gen 1 (USB 3.0) - Backward compatible with USB 2.0 and 1.1 Interface/Bridge USB 3.2 Gen 1 (5Gbps) Laptop Dock / USB Hub Fast-Charge No LED Indicators 4 - Port Power USB-C Device Port(s) No USB-C Host Connection Yes Amount of recycled material in plastic packaging At Least 30% Carton Depth (mm) 338 Carton Height (mm) 448 Carton Quantity 70 Carton Weight Gross (g) 8454 Included in Package - 1 - hub
- 1 - quick-start guide
Included In Package for Label - 1 - hub
- 1 - quick-start guide
Package Depth (mm) 122 Package Height (mm) 32 Package Width (mm) 162 Package Quantity 1 Package Weight (g) 92 Packaging Description 4-Port USB-C Hub - Individual Port Power - C to A Packaging Description India 4-Port USB-C Hub - USB-C to 4x USB-A Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-A (5Gbps, 4.5W) Connector 1 (Quantity) 4 Connector 2 USB-C (5Gbps, 4.5W) Connector 2 (Quantity) 1 Amazon Merchandising Manager Kristian Haighton Artwork Due Date 2018-05-16 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute Yes Buying Center - Networking & Edge Yes Digital Content Due Date 2018-07-06 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FI,FR,IE,IN,IT,JP,MX,NL,NZ,PE,SE,SG,UK,US Primary Technology USB-C Product Development Specialist Sam Bushell Product Information Creation Specialist (PICS) Maria Powell Product Manager Natalie Goodale Product Performance Specialist Aaron Bens Product Photographer Caleigh Le Grand Target Development Completion Date 2018-06-01 Target Production Release 2018-06-01 Tech Lead Stefan Tirolese Technical Writer Maria Powell Technology Lifecycle Mainstream
