ICUSB2321F
1-Port FTDI USB to Serial Converter Cable
Add an RS232 serial port with COM retention to your laptop or desktop computer through USB
Main Image
Product Images
Product Images
Product Images
BOM Image
Quick-Start Guide
Product Name 1-Port FTDI USB to Serial Converter Cable Product Number ICUSB2321F UPC 065030843485 Lifecycle status Active Warranty 2 Years Taxonomy Product > Cards & Adapters > Serial and Parallel Cards & Adapters Category Level 1 Computer Cards and Adapters Category Level 2 Serial Cards, Adapters and Extenders Category Level 3 USB Serial Host Adapter Interconnects Family USB to Serial Adapter Cables - USB-A - FTDI Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX013X Product Title (Short) FTDI USB to Serial Adapter Cable w/ COM Product Title (Medium) x Product Title (Standard) 6ft (1.8m) 1-Port FTDI USB to Serial RS232 Adapter Cable with COM Retention, USB to RS232 Adapter - TAA Product Title (Long) 6ft (1.8m) 1-Port FTDI USB to Serial RS232 Adapter Cable with COM Retention, USB to RS232 Adapter - TAA Product Title (AMZ) 6ft (1.8m) 1-Port FTDI USB to Serial RS232 Adapter Cable with COM Retention, USB to RS232 Adapter - TAA Title Ingram (Part 1) 1 Port FTDI USB to Serial Adapte Title Ingram (Part 2) r Cable with COM Retention Website Product Headline Add an RS232 serial port with COM retention to your laptop or desktop computer through USB Bullet 1 CUSTOMIZABLE SOLUTION: This USB serial hub features an FTDI chipset, making it highly customizable and compatible, and the ideal solution for any setup Bullet 2 COMPACT DESIGN: Designed with a small form factor, this serial RS232 converter is USB powered and requires no bulky power adapters or an outlet Bullet 3 EASY INSTALLATION: This serial adapter ensures easy installation and operation with COM port retention that provides robust serial connectivity for legacy devices Bullet 4 TECH SPECS: 6 feet (1.8 meters); FTDI FT232RL Chipset; Max Baud Rate: 115.2 Kbps; 256 Bytes FIFO; None/Odd/Even/Mark Parity Modes; 7 or 8 Data Bits; 1 or 2 Stop bits; TAA Compliant Bullet 5 MULTI-USE FUNCTIONALITY: This versatile USB to serial RS232 adapter is perfect for a range of applications, from digital signage to connecting point-of-sale systems and barcode scanners Bullets (Compact) USB to serial RS232 adapter - FTDI chipset, making it highly customizable and compatible - Small form factor, serial RS232 converter is USB powered - COM port retention; Compatible with Windows, macOS and Linux - 6ft (1.8m); FTDI FT232RL Chipset; TAA Bullets (Consolidated) - USB to serial RS232 adapter - USB serial hub features an FTDI chipset, making it highly customizable and compatible - Small form factor, serial RS232 converter is USB powered and requires no bulky power adapters or an outlet; Powered by the USB port - Simple installation and operation and COM port retention; Compatible with Windows, macOS and Linux - 6ft (1.8m); FTDI FT232RL Chipset; 115.2 Kbps Max Baud Rate; 256 Bytes FIFO; 7 or 8 Data Bits; 1 or 2 Stop bits; TAA Compliant Marketing Copy Marketing Copy (No HTML) Applications - Connect a satellite receiver, serial modem, or PDU
- Connect and program LED and Digital signage boards with serial communication ports
- Connect bar code scanners, receipt printers and other point of sale devices
- Connect, monitor and control industrial/automotive sensors and equipment
- Perfect for IT Administrators looking to add legacy functionality to newer notebooks, PCs and servers that lack an integrated RS232 port
Website Search Keyword - Serial
- serial adapter
- USB to RS-232
- RS-232 adapter
- USB Serial
- USB RS-232
- USB RS232
- serial cable
- usb serial cable
- connect serial to pc
- pc serial connect
- U209-005-COM
Required Regulatory Compliance Marks - Triman/Info-Tri - Packaging - Waste - European Union - Paper Box + plastic bag + Paper/foam divider/tray
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- UKCA - EMC/EMI - United Kingdom - UK Electromagnetic Compatibility Regulations 2016
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- Triman/Info-Tri - Product - Waste - European Union - EEE Device + accessories
- EU RIC + Italian Sorting - Packaging - Waste - European Union - Corrugated Fiberboard
System and Cable Requirements One available USB 1.1 (or better) port Accessory Products - MXT10050CMBK
- MXT1001MBK
- MXT1002MBK
- MXT1003MBK
- SCNM9FM1MBK
- SCNM9FM2MBK
- MXT106
- MXT10010
- MXT100_25
- USBEXTAA3BK
- USBEXTAA6BK
- USBEXTAA10BK
Related Products - ICUSB232PRO
- ICUSB232V2
- ICUSB232DB25
- ICUSB2321FIS
- ICUSB2321X
- ICUSB232SM3
- ICUSB232IS
- ICUSBANDR232
- ICUSB232D
- ICUSB2321284
- ICUSB2322X
- ICUSB232C2
- ICUSB2322F
- ICUSB2322I
- ICUSB2324
- ICUSB2324I
- ICUSB2324X
- ICUSB2328
- ICUSB2328I
- ICUSB23208FD
- ICUSB23216FD
- ICUSB23216F
- ICUSB2322RJ
- ICUSB232FTN
- ICUSB2324852
Constrained SKU Alternatives (Limited Stock) ICUSB2321X Power Source USB-Powered Cable Length (mm) 1830 Color Black Humidity 5~95% RH Material Plastic Operating Temperature 0°C to 55°C (32°F to 131°F) Primary Material Plastic Product Length (mm) 1830.000 Product Width (mm) 41.500 Product Height (mm) 21.800 Product Weight (g) 80 Storage Temperature -20°C to 85°C (-4°F to 185°F) TAA Compliant Yes Data Bits 7, 8 FIFO 256 Bytes Max Baud Rate 115.2 Kbps MTBF (hours) 836981.2 hours OS Compatibility - Linux
- Windows 8
- Windows Server 2012
- Windows 7
- Windows 10
- macOS Sierra (10.12)
- Windows Server 2016
- macOS High Sierra (10.13)
- macOS Mojave (10.14)
- Windows Server 2019
- macOS Catalina (10.15)
- macOS Big Sur (11.0)
- Windows 11
- macOS Monterey (12.0)
- macOS Ventura (13.0)
- Windows Server 2022
- macOS Sonoma (14.0)
- Windows 11 ARM
- macOS Sequoia (15.0)
- macOS Tahoe (26.0)
- Windows Server 2025
Parity None, Odd, Even, Mark, Space Stop Bits 1, 2 Supported Serial Protocol RS-232 Bus Type USB 2.0 Chipset ID FTDI - FT232RL Interface/Bridge Serial IO Card Port Style Cable Adapters Carton Depth (mm) 534 Carton Height (mm) 356 Carton Quantity 80 Carton Weight Gross (g) 14794 Included in Package - 1 - Driver CD
- 1 - Instruction Manual
- 1 - USB to RS-232 Serial Adapter
Included In Package for Label - 1 - Driver CD
- 1 - Instruction Manual
- 1 - USB to RS-232 Serial Converter
Package Depth (mm) 175 Package Height (mm) 32 Package Width (mm) 144 Package Quantity 1 Package Weight (g) 170 Packaging Description 1 Port FTDI USB to Serial Adapter Cable Packaging Description India 1-Port FTDI USB to Serial Converter Cable Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 DB-9 Serial Connector 1 (Quantity) 1 Connector 2 USB-A (480Mbps, 2.5W) Connector 2 (Quantity) 1 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2014-06-18 Buying Center - AV & Collaboration Yes Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level - 1 Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FI,FR,HK,IE,IN,IT,JP,MX,NL,NZ,PE,SE,SG,UK,US Primary Technology None Product Information Creation Specialist (PICS) Alex Garcia Product Manager Natalie Goodale Product Performance Specialist Aaron Bens Product Photographer Alejandra Valencia Tech Lead Brian Linseman Technical Writer Andrew Richardson Technology Lifecycle None
