ICUSB2328
8 Port USB To RS232 Adapter
Add eight RS232 serial ports to any notebook or desktop computer using a single USB port
Main Image
Product Images
Product Images
Product Images
Product Name 8 Port USB To RS232 Adapter Product Number ICUSB2328 UPC 065030825825 Lifecycle status End of Life Warranty Lifetime Taxonomy Product > Cards & Adapters > Serial and Parallel Cards & Adapters Category Level 1 Computer Cards and Adapters Category Level 2 Serial Cards, Adapters and Extenders Category Level 3 USB Serial Host Adapter Interconnects Family Desktop USB to Serial Adapters - FTDI Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX013X Product Title (Ultra-Short) 8Pt USB to RS232 Hub Product Title (Short) 8 Port USB to RS232 Serial Adapter Hub Product Title (Standard) USB to Serial Adapter Hub – 8 Port – DB9 (9-pin) – USB Serial – FTDI USB to RS232 Adapter – USB Serial Product Title (Long) 8 Port USB to RS232 Serial DB9 Adapter Hub - TAA Product Title (AMZ) USB to Serial Adapter Hub - 8 Port - DB9 (9-pin) - USB Serial - FTDI USB to RS232 Adapter - USB Serial (ICUSB2328) Title Ingram (Part 1) 8 Port USB to RS232 Serial DB9 A Title Ingram (Part 2) dapter Hub Website Product Headline Add eight RS232 serial ports to any notebook or desktop computer using a single USB port Bullet 1 Bus-powered – requires no external power adapter Bullet 2 Easy Plug-and-Play installation Bullet 3 Fully compliant with USB 1.1 specifications and compatible with USB 2.0 Bullet 4 Adds eight RS232 serial ports using USB Bullet 5 Hex nuts included for optional screw or nut DB9 interface Bullets (Consolidated) Serial adapter - USB 2.0 - RS-232 x 8 Marketing Copy Applications - Connect modems, digitizer tablets, mice, bar code scanners, GPS receivers, ISDN terminal adapters, mobile phones, scanners, UPS and POS equipment to your system
- Connect and program LED and Digital signage boards with serial communication ports
Website Search Keyword - 8 Port
- USB to RS232
- Adapter
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
Accessory Products - USB2FAAEXT15
- USB2HAB10
- USB2HAB15
- USB2HAB10T
- USB2HAB15T
- SCNM9FM
- SCNM925FM
- MXT106
- MXT100
- MXT100_25
- MXT100FF
- RS232EXTC5
- SVA5M3NEUA
Related Products - ICUSB2324
- ICUSB2321X
- ICUSB232
- ICUSB232C2
- ICUSB2322X
- ICUSB2324X
Output Current 1A+ Output Voltage (V) 5 DC Power Source Not Included (not required for standard applications) Plug Type M Center Tip Polarity Positive Cable Length (mm) 1830 Color Black Humidity 5~95% RH Material Plastic Operating Temperature 0°C to 55°C (32°F to 131°F) Primary Material Plastic Product Length (mm) 150.000 Product Width (mm) 66.500 Product Height (mm) 26.000 Product Weight (g) 860.000 Storage Temperature -20°C to 85°C (-4°F to 185°F) TAA Compliant Yes Data Bits 7, 8 FIFO 256 Bytes Max Baud Rate 921.6 Kbps OS Compatibility - Linux
- Windows Server 2012
- Windows 7
- Windows 8
- Windows 10
- macOS Sierra (10.12)
- Windows Server 2016
- macOS High Sierra (10.13)
- macOS Mojave (10.14)
- Windows Server 2019
- macOS Catalina (10.15)
- macOS Big Sur (11.0)
- Windows 11
- macOS Monterey (12.0)
- macOS Ventura (13.0)
- Windows Server 2022
- macOS Sonoma (14.0)
- Windows 11 ARM
- macOS Sequoia (15.0)
- macOS Tahoe (26.0)
Supported Serial Protocol RS-232 Bus Type USB 2.0 Chipset ID FTDI - FT232RL Interface/Bridge Serial IO Card Port Style External Hub Carton Depth (mm) 398 Carton Height (mm) 328 Carton Quantity 14 Carton Weight Gross (g) 12882 Included in Package - 1 - 8 Port Serial Hub
- 1 - 6ft USB Cable
- 1 - User Manual
- 1 - Driver CD
- 1 - Serial Breakout Cable
- 8 - Optional DB9 Connector Hex Nut Pairs
Package Depth (mm) 191 Package Height (mm) 74 Package Width (mm) 295 Package Quantity 1 Package Weight (g) 854 Packaging Description 8 Port USB to RS232 Serial DB9 Adapter Hub Packaging Description India 8 Port USB to RS232 Serial DB9 Converter Hub Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 USB-B (480Mbps, 2.5W) Connector 1 (Quantity) 1 Connector 2 DB-9 Serial Connector 2 (Quantity) 8 Amazon Merchandising Manager Veronica Ye Artwork Due Date 2014-06-18 Buying Center - AV & Collaboration No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,BE,CA,CH,DE,DK,ES,EU,FR,IE,IN,IT,NL,SE,UK,US Primary Technology None Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Natalie Goodale Product Performance Specialist Aaron Bens Product Photographer Alejandra Valencia Tech Lead Brian Linseman Technical Writer Andrew Richardson Technology Lifecycle None Vending Machine Not Compatible with Vending Machine
