Main Image
JD094BST
HP JD094B compatible SFP transceiver
10 Gbps | Single Mode Fiber | LC | 10 km (6.2 mi) | Lifetime Warranty
Main Image
Product Images
Product Images
Product Name HP JD094B compatible SFP transceiver Product Number JD094BST UPC 065030868501 Lifecycle status Active Warranty Lifetime Taxonomy Product > Networking > SFP Transceivers Category Level 1 Networking Category Level 2 SFP Transceivers Category Level 3 HP Compatible Family HP Compatible - 10G SFP+ Modules Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX091X Product Title (Ultra-Short) HP JD094B SFP+ - SM Product Title (Short) HPE JD094B Compatible SFP+ - 10GbE DDM Product Title (Medium) HP JD094B Compatible SFP+ Fiber Module - 10GBASE-LR - Lifetime Warranty Product Title (Standard) HPE JD094B Compatible SFP+ Module - 10GBASE-LR 10GE Gigabit Ethernet SFP+ 10GbE Single Mode/SMF Fiber Optic Transceiver 10km Product Title (Long) HPE JD094B Compatible SFP+ Module - 10GBASE-LR - 10GbE Single Mode Fiber Optic Transceiver - 10GE Gigabit Ethernet SFP+ - LC 10km - 1310nm - DDM HPE 5900, 12500, 5500 Product Title (AMZ) HPE JD094B Compatible SFP+ Module - 10GBASE-LR - 10GbE Single Mode (SMF) Fiber Optic Transceiver - 10GE Gigabit Ethernet SFP+ - LC 10km - 1310nm - DDM HPE 5900, 12500, 5500 (JD094BST) Title Ingram (Part 1) HP JD094B Compatible - Title Ingram (Part 2) SFP+ Module - Fiber Transceiver Website Product Headline 10 Gbps | Single Mode Fiber | LC | 10 km (6.2 mi) | Lifetime Warranty Bullet 1 100% HPE JD094B COMPATIBLE: Works with HPE switches like 5900, 12500, 5500, 5820, 5120 and others Bullet 2 TECHNICAL SPECS: 10GBASE-LR | 10Gbps | Single Mode (SMF) | LC Connector | 1310nm | Digital Diagnostic Monitoring (DDM) | Distances up to 10km (6.2mi) Bullet 3 TESTED FOR OEM HOST COMPATIBILITY: Hot-swappable in HPE routers and switches; DDM support reports the transceiver's status to most SNMP network management tools Bullet 4 THE IT PRO’S CHOICE: Designed and built for IT Professionals, this SFP module is backed for life (lifetime of module, not network switch), including free lifetime 24/5 multi-lingual technical assistance Bullet 5 WORKS WITH MSA COMPLIANT SWITCHES: Also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules Bullets (Compact) HPE JD094B Compatible SFP+ - 10GBASE-LR 10Gbps - 10GbE Module - 10GE Gigabit Ethernet SFP+ 1310nm Single Mode (SMF) Transceiver - 10km (6.2mi) - LC Connector DDM - Hot-Swappable & MSA Compliant - Lifetime Warranty Bullets (Consolidated) HPE JD094B Compatible SFP+ 10GBASE-LR (10Gbps) Gigabit Ethernet - 1310nm Single Mode (SMF) - Up to 10km (6.2mi) - LC Connector DDM - For HPE switches like: 5900 12500 5500 5820 5120 5130 A5800 - Hot-Swappable and MSA Compliant - Backed by a StarTech.com lifetime warranty on the module itself not the life of the OEM switch/router and will not void your OEM warranty Marketing Copy Marketing Copy (No HTML) Applications - Replacing defective or damaged SFP+ modules in HP switches and routers
- Expand your network to remote segments
Website Search Keyword - HP JD094B Compatible SFP+
- HP JD094B SFP+
- 10GBase-LR SFP+ module
- 10Gb Fiber SFP+
- 10 Gigabit SFP+
- Single-mode SFP+
- SM SFP+
- 10G SFP+
- SFP+ transceiver
- HP compatible SFP+ module
- 10GBase-LR
- HP SFP+
- SFP+ optical transceiver
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- UL Recognized - Safety - Electrical - Canada / United States - cURus Recognised Component Mark
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- CE - Safety - Electrical - European Union - Low Voltage Directive (LVD) 2014/35/EU
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
Special Notes For use in 10 Gigabit fiber networking equipment and media converters System and Cable Requirements MSA or HP compliant SFP port Accessory Products - PEX20000SFPI
- PEX10000SFP
- PEX10000SFPI
- ET10GSFP
Power Consumption (In Watts) < 1.2 W Color Silver Humidity 5~95% RH Material Aluminum Operating Temperature 0°C to 70°C (32°F to 158°F) Primary Material Aluminum Product Length (mm) 58.400 Product Width (mm) 13.900 Product Height (mm) 12.600 Product Weight (g) 20.000 Storage Temperature -40°C to 85°C (-40°F to 185°F) TAA Compliant No Compatible Networks 10 Gbps Digital Diagnostics Monitoring Support Yes Fiber Operating Mode Full-Duplex Fiber Type Single Mode Maximum Data Transfer Rate 10 Gbps Max Transfer Distance 10 km (6.2 mi) MTBF (hours) 2,104,865 hours Wavelength 1310nm Fiber Connector LC Industry Standards IEEE 802.3ae 10GBASE-LR OEM Part Number JD094B SFP Compatible Brand HPE Carton Depth (mm) 340 Carton Height (mm) 211 Carton Quantity 55 Carton Weight Gross (g) 397 Included in Package 1 - SFP+ transceiver Package Depth (mm) 91 Package Height (mm) 33 Package Width (mm) 114 Package Quantity 1 Package Weight (g) 48 Packaging Description 10 Gb Fiber SFP+ - JD094B Compatible - SM LC Packaging Description India 10 Gb Fiber SFP+ - JD094B Compatible - SM LC Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Host Connector 1 LC Duplex Fiber Host Connector 1 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2016-12-06 Buying Center - AV & Collaboration No Buying Center - Data Center Yes Buying Center - End User Compute No Buying Center - Networking & Edge Yes Digital Content Due Date 2016-12-23 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,DE,DK,ES,EU,FR,HK,IE,IN,IT,JP,NL,NZ,SE,UK,US Primary Technology None Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Development Completion Date 2016-12-09 Target Production Release 2016-12-09 Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle None
