JD118BST
HP JD118B compatible SFP transceiver
1000 Mbps (1 Gbps) | Multi Mode Fiber | LC | 550 m (1804 ft) | Lifetime Warranty
Main Image
Product Images
Product Images
Product Name HP JD118B compatible SFP transceiver Product Number JD118BST UPC 065030868532 Lifecycle status Active Warranty Lifetime Taxonomy Product > Networking > SFP Transceivers Category Level 1 Networking Category Level 2 SFP Transceivers Category Level 3 HP Compatible Family HP Compatible - 1G SFP Modules Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX091X Product Title (Ultra-Short) HP JD118B SFP MM Product Title (Short) HPE JD118B Compatible SFP - 1GbE DDM Product Title (Medium) HP JD118B Compatible SFP Fiber Module - 1000BASE-SX - Lifetime Warranty Product Title (Standard) HPE JD118B Compatible SFP Module - 1000BASE-SX - 1GE Gigabit Ethernet SFP 1GbE Multi Mode (MMF) Fiber Optic Transceiver 550m Product Title (Long) HPE JD118B Compatible SFP Module - 1000BASE-SX - 1GbE Multi Mode Fiber Optic Transceiver - 1GE Gigabit Ethernet SFP - LC 550m - 850nm - DDM HPE 5900, 12500, 5500 Product Title (AMZ) HPE JD118B Compatible SFP Module - 1000BASE-SX - 1GbE Multi Mode (MMF) Fiber Optic Transceiver - 1GE Gigabit Ethernet SFP - LC 550m - 850nm - DDM HPE 5900, 12500, 5500 (JD118BST) Title Ingram (Part 1) HP JD118B Compatible - Title Ingram (Part 2) SFP Module - Fiber Transceiver Website Product Headline 1000 Mbps (1 Gbps) | Multi Mode Fiber | LC | 550 m (1804 ft) | Lifetime Warranty Bullet 1 100% HPE JD118B COMPATIBLE: Works with HPE switches like 5900, 12500, 5500, 5820, 5120 and others Bullet 2 TECHNICAL SPECS: 1000BASE-SX | 1Gbps | Multi Mode (MMF) | LC Connector | 850nm | Digital Diagnostic Monitoring (DDM) | Distances up to 550m (1804ft) Bullet 3 TESTED FOR OEM HOST COMPATIBILITY: Hot-swappable in HPE routers and switches; DDM support reports the transceiver's status to most SNMP network management tools Bullet 4 THE IT PRO’S CHOICE: Designed and built for IT Professionals, this SFP module is backed for life (lifetime of module, not network switch), including free lifetime 24/5 multi-lingual technical assistance Bullet 5 WORKS WITH MSA COMPLIANT SWITCHES: Also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules Bullets (Compact) HPE JD118B Compatible SFP - 1000BASE-SX 1Gbps - 1GbE Module - 1GE Gigabit Ethernet SFP 850nm Multi Mode (MMF) Transceiver - 550m (1804ft) - LC Connector DDM - Hot-Swappable & MSA Compliant - Lifetime Warranty Bullets (Consolidated) HPE JD118B Compatible SFP 1000BASE-SX (1Gbps) Gigabit Ethernet - 850nm Multi Mode (MMF) - Up to 550m (1804') - LC Connector DDM - For HPE switches like: 5900 12500 5500 5820 5120 5130 A5800 - Hot-Swappable and MSA Compliant - Backed by a StarTech.com lifetime warranty on the module itself not the life of the OEM switch/router and will not void your OEM warranty Marketing Copy Marketing Copy (No HTML) Applications - Replacing defective or damaged SFP modules in HP switches and routers
- Expand your network to remote segments
Website Search Keyword - HP JD118B Compatible SFP
- JD118B Compatible SFP
- HP JD118B
- HP
- HPE
- HP compatible SFP
- SFP Module
- GBIC Module
- mini GBIC
- MSA
- HPE compatible SFP
- 1000Base-SX
- 1000Base-SX SFP
- MM SFP
Required Regulatory Compliance Marks - UL Recognized - Safety - Electrical - Canada / United States - cURus Recognised Component Mark
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- CE - Safety - Electrical - European Union - Low Voltage Directive (LVD) 2014/35/EU
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
- FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
Special Notes For use in Gigabit fiber networking equipment and media converters System and Cable Requirements MSA or HP compliant SFP port Accessory Products - 50FIBLCLC1
- 50FIBLCLC2
- 50FIBLCLC3
- 50FIBLCLC5
- 50FIBLCLC10
- PEX1000SFP2
- IES101002SFP
- IES101GP2SFW
- IES101G2SFPW
- MCM1110SFP
Related Products 3CSFP91ST Output Voltage (V) 3.3V DC Power Consumption (In Watts) < 1 W Color Silver Humidity 5~95% RH Material Aluminum Operating Temperature 0°C to 70°C (32°F to 158°F) Primary Material Aluminum Product Length (mm) 56.600 Product Width (mm) 13.700 Product Height (mm) 12.500 Product Weight (g) 18.000 Storage Temperature -40°C to 85°C (-40°F to 185°F) TAA Compliant No Compatible Networks 1000 Mbps (1 Gbps) Digital Diagnostics Monitoring Support Yes Fiber Operating Mode Full-Duplex Fiber Type Multi Mode Maximum Data Transfer Rate 1.25 Gbps Max Transfer Distance 550m [1804ft] MTBF (hours) 3,381,761 hours Wavelength 850nm Fiber Connector LC Industry Standards IEEE 802.3z 1000BASE-SX OEM Part Number JD118B SFP Compatible Brand HPE Carton Depth (mm) 250 Carton Height (mm) 203 Carton Quantity 36 Carton Weight Gross (g) 1967 Included in Package 1 - SFP transceiver Package Depth (mm) 114 Package Height (mm) 32 Package Width (mm) 93 Package Quantity 1 Package Weight (g) 46 Packaging Description Gb Fiber SFP - JD118B Compatible - MM LC Packaging Description India Gb Fiber SFP - JD118B Compatible - MM LC Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Host Connector 1 LC Duplex Fiber Host Connector 1 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2016-12-06 Buying Center - AV & Collaboration No Buying Center - Data Center No Buying Center - End User Compute No Buying Center - Networking & Edge Yes Digital Content Due Date 2016-12-23 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,DE,DK,ES,EU,FR,HK,IE,IN,IT,JP,MX,NL,NZ,SE,UK,US Primary Technology None Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Development Completion Date 2016-12-09 Target Production Release 2016-12-09 Tech Lead Stefan Tirolese Technical Writer Andrew Richardson Technology Lifecycle None
