Main Image
JG661A-ST
HP JG661A Compatible TAA Compliant 40GBase LR4 QSFP
40 Gbps | Single Mode Fiber | LC | 10 km (6.2 mi) | Lifetime Warranty
Main Image
Product Images
BOM Image
Product Name HP JG661A Compatible TAA Compliant 40GBase LR4 QSFP Product Number JG661A-ST UPC 065030886215 Lifecycle status End of Life Warranty Lifetime Taxonomy Product > Networking > SFP Transceivers Category Level 1 Networking Category Level 2 SFP Transceivers Category Level 3 HP Compatible Family HP Compatible - 40G QSFP+ Modules Country of Origin Europe & Japan China Country of Origin North America China Country of Origin History (1) China Country of Origin Revision (1) XXXXXX091X Product Title (Ultra-Short) JG661A Comp Product Title (Short) HPE JG661A Compatible QSFP+ - 40GbE DDM Product Title (Medium) HP JG661A Compatible QSFP+ SM Module - 40GBase-LR4 - Lifetime Warranty Product Title (Standard) HPE JG661A Compatible QSFP+ Module - 40GBASE-LR4 - 40GE Gigabit Ethernet QSFP+ 40GbE Single Mode Fiber Optic Transceiver 10km Product Title (Long) HPE JG661A Compatible QSFP+ Module - 40GBASE-LR4 - 40GbE Single Mode Fiber Optic Transceiver - 40GE Gigabit Ethernet QSFP+ - LC 10km - 1270nm to 1330nm - DDM HPE 5900AF, 12902 Product Title (AMZ) HPE JG661A Compatible QSFP+ Module - 40GBASE-LR4 - 40GbE Single Mode (SMF) Fiber Optic Transceiver - 40GbE QSFP+ - LC 10km - 1270nm to 1330nm - DDM HPE 5900AF, 12902 (JG661A-ST) Title Ingram (Part 1) HP JG661A Comp - Title Ingram (Part 2) QSFP+ Module - MM Transceiver Website Product Headline 40 Gbps | Single Mode Fiber | LC | 10 km (6.2 mi) | Lifetime Warranty Bullet 1 100% HPE JG661A COMPATIBLE: Works with HPE switches like 5900AF, 12902 and others Bullet 2 TECHNICAL SPECS: 40GBASE-LR4 | 40Gbps | Single Mode (SMF) | LC Connector | 1270nm to 1330nm | Digital Diagnostic Monitoring (DDM) | Distances up to 10km (6.2mi) Bullet 3 TESTED FOR OEM HOST COMPATIBILITY: Hot-swappable in HPE routers and switches; DDM support reports the transceiver's status to most SNMP network management tools Bullet 4 THE IT PRO’S CHOICE: Designed and built for IT Professionals, this SFP module is backed for life (lifetime of module, not network switch), including free lifetime 24/5 multi-lingual technical assistance Bullet 5 WORKS WITH MSA COMPLIANT SWITCHES: Also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules Bullets (Compact) HPE JG661A Compatible QSFP+ - 40GBASE-LR4 40Gbps - 40GbE Module - 40GE Gigabit Ethernet QSFP+ 1270nm to 1330nm Single Mode (SMF) Transceiver - 10km (6.2mi) - LC Connector DDM - Hot-Swappable & MSA Compliant - Lifetime Warranty Bullets (Consolidated) HPE JG661A Compatible QSFP+40GBASE-LR4 (40Gbps) Gigabit Ethernet - 1270nm to 1330nm Single Mode (SMF) - Up to 10km (6.2mi) - LC Connector DDM - For HPE switches like: 5900AF 12902 - Hot-Swappable and MSA Compliant - Backed by a StarTech.com lifetime warranty on the module itself not the life of the OEM switch/router and will not void your OEM warranty Marketing Copy Marketing Copy (No HTML) Website Search Keyword - 40 gigabit qsfp+
- 40G qsfp+
- 40g qsfp+ lr4
- 40g qsfp+ transceiver
- 40gbase lr4
- 40gbase lr4 qsfp+
- 40gbe qsfp+
- 40ge qsfp+
- fiber optic transceiver
- fiber optic transceiver module
- fiber transceiver module
- HP JG661A
- HP qsfp+
- HPE qsfp+
- JG661A
- qsfp+
- qsfp+ module
- qsfp+ optical transceiver
- qsfp+ transceiver
- single mode fiber module
- single mode fiber transceiver
- single mode module
- single mode transceiver
Required Regulatory Compliance Marks - FCC - EMC/EMI - United States - FCC Part 15 Class B Digital Device Interference
- ICES - EMC/EMI - Canada - Industry Canada (IC) CAN ICES-003 Class B Digital Device Product Label Statement
- RCM - EMC/EMI - Australia/New Zealand - RCM Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- CE - EMC/EMI - European Union - EU EMC Directive 2014/30/EU
- Recycling - Waste - Japan - Plastic Recycling Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
Power Consumption (In Watts) < 1.3W Material Steel Primary Material Steel Product Length (mm) 18.300 Product Width (mm) 122 Product Height (mm) 8.5 Product Weight (g) 49 TAA Compliant No Compatible Networks 40 Gbps Digital Diagnostics Monitoring Support Yes Fiber Operating Mode Full-Duplex Fiber Type Single Mode Maximum Data Transfer Rate 40.00 Gbps Max Transfer Distance 10 km (6.2 mi) MTBF (hours) 95,832,027 hours Wavelength 1270nm to 1330nm Fiber Connector LC Industry Standards IEEE 802.3ba 40GBASE-LR4 OEM Part Number JG661A SFP Compatible Brand HPE Carton Depth (mm) 120 Carton Height (mm) 35 Carton Quantity 1 Carton Weight Gross (g) 60 Included in Package 1 - QSFP+ Transceiver Package Depth (mm) 133 Package Height (mm) 49 Package Width (mm) 185 Package Quantity 1 Package Weight (g) 118 Packaging Description 40Gb Fiber QSFP+ - JG661A Compatible - SM LC Packaging Description India 40Gb Fiber QSFP+ - JG661A Compatible - SM LC Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 SFP Slot Connector 1 (Quantity) 1 Connector 2 LC Duplex Fiber Connector 2 (Quantity) 1 Amazon Merchandising Manager Kathleen Marshall Artwork Due Date 2019-07-19 Buying Center - AV & Collaboration No Buying Center - Data Center Yes Buying Center - End User Compute No Buying Center - Networking & Edge Yes Digital Content Due Date 2019-08-02 Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett Launch Markets (concatenated) AT,AU,BE,CA,CH,CL,CO,DE,DK,ES,EU,FR,IE,IN,IT,JP,NL,NZ,PE,SE,UK,US Priority New Product N/A Product Development Specialist Ray Aoki Product Information Creation Specialist (PICS) Alex Garcia Product Manager Rob Fleck Product Performance Specialist Ray Aoki Product Photographer Alejandra Valencia Target Development Completion Date 2019-06-28 Target Production Release 2019-07-19 Tech Lead Stefan Tirolese Technical Writer Evan Hanbidge Technology Lifecycle None
