Main Image
K31D-2U00-POWER-CORD
NEMA L5-20P to NEMA 5-20R - Heavy-Duty, 20A, 125V, 12 AWG, 6
Extend a power connection or connect to a PDU with a cable that's designed for heavy use
Main Image
Product Images
Product Images
Product Images
Video Link YouTube
Product Name NEMA L5-20P to NEMA 5-20R - Heavy-Duty, 20A, 125V, 12 AWG, 6 Product Number K31D-2U00-POWER-CORD UPC 065030900829 Lifecycle status Active Warranty Lifetime Weighted Opportunity 12058 Taxonomy Product > Cables > Power Cables Category Level 1 Cables - Other Category Level 2 Power Cables Category Level 3 External Power Cords Family L5-20P to 5-20R Country of Origin Europe & Japan Taiwan Country of Origin North America Taiwan Country of Origin History (1) Taiwan Country of Origin Revision (1) XXXXXX120X Product Title (Ultra-Short) AC Power Cord Product Title (Short) 6in Power Cord, L5-20P to 5-20R Product Title (Medium) 6in (15cm) Heavy Duty Power Cord, NEMA L5-20P to NEMA 5-20R, 20A 125V Product Title (Standard) 6in (15cm) Heavy Duty Power Cord, NEMA L5-20P to NEMA 5-20R Plug Converter Cable, 20A 125V, 12AWG, UL Listed, TAA Product Title (Long) 6in (15cm) Heavy Duty Power Cord, NEMA L5-20P to NEMA 5-20R, Black Adapter Cord, 20A 125V, 12AWG, Heavy Gauge Plug Converter Cable, TAA Compliant, UL Listed Product Title (AMZ) 6in (15cm) Heavy Duty Power Cord, NEMA L5-20P to NEMA 5-20R, AC Power Adapter Cable, 20A 125V, 12AWG, Heavy Gauge Power Cable - UL Listed , TAA (K31D-2U00-POWER-CORD) Title Ingram (Part 1) 15cm Heavy Duty Power Cord Title Ingram (Part 2) NEMA L5-20P to 5-20R, 20A 125V Website Product Headline Extend a power connection or connect to a PDU with a cable that's designed for heavy use Bullet 1 HEAVY DUTY ADAPTER CABLE: 6in heavy gauge power cord with NEMA L5-20P to NEMA 5-20R connector is suitable for high-powered equipment; Convert a NEMA L5-20 outlet for high-power devices requiring a NEMA 5-20R connection; Indoor use; Rated up to 125V at 20A Bullet 2 BUILT FOR PERFORMANCE AND SAFETY: UL Listed; VW-1 Fire Rated cable with fully molded connector strain reliefs for durability; 3-conductor power cable made with 100% copper wire Bullet 3 SPECS: 6in (15.24cm); TAA Compliant; NEMA L5-20P to NEMA 5-20R; 12AWG; 125V 20A (Max); Jacket Rating: SJT; Color: Black; Temperature Range: -4°F to 221°F (-20℃ to 105℃); Cable O.D.: 0.44in (11.2mm) Bullet 4 COMPATIBILITY: NEMA L5-20P to NEMA 5-20R adapter power cord works with North American PDUs and high-powered devices; Convert an L5-20 outlet to NEMA 5-20R for convenient integration with servers, switches, or UPS; Heavy duty adapter power cord Bullet 5 THE IT PRO’S CHOICE: Designed and built for IT Professionals, this heavy duty adapter power cord is backed for life, including free lifetime 24/5 multi-lingual technical assistance; This adapter power cable is available in other plug configurations Bullets (Compact) 6in heavy duty power cord with NEMA L5-20P to NEMA 5-20R connectors; 250V at 20A; UL Listed; Wire: 100% Copper; Fire Rating: VW-1; 12AWG; Jacket Rating: SJT; Temp Range: -4 to 221°F; Cable O.D.: 0.44in; TAA Compliant Bullets (Consolidated) 6in (15.24cm) Heavy duty power cord with NEMA L5-20P to NEMA 5-20R connectors; Rated to carry 125V at 20A (Max) - UL Listed; Durable molded connectors w/strain reliefs; 100% Copper wire; Fire Rating: VW-1 - 12AWG; Jacket Rating: SJT; Temperature Range: -4 to 221 DEGF; Cable O.D.: 0.44in - TAA Compliant; Convert an L5-20 outlet to NEMA 5-20R for convenient integration with servers, switches, or UPS; NEMA 5-20R connector works with North American servers/switches Marketing Copy Marketing Copy (No HTML) Our power cables are the preferred choice for IT professionals, tailored to meet the specific demands of IT applications. Our comprehensive range includes standard and heavy-duty power cords, extension cords, medical-grade cords, splitter cables, and passthrough options. We prioritize safety, and reliability through rigorous in-house and third-party testing. Our cables are certified for both performance and safety, constructed using UL-listed components compliant with UL62 and UL817 standards. They also adhere to environmental safety standards, including REACH and RoHS compliance. We use 100% copper wiring that undergoes thorough testing for continuity and conductivity, guaranteeing maximum performance and reliability. Our cables are further tested in temperature chambers to ensure they meet environmental and jacket ratings. Backed for life with 24-hour, five day-a-week support from qualified Technical Advisor and our IT Pro community forums, our brand is trusted throughout the IT ecosystem and used by over 80% of Fortune 500 companies Applications - Heavy Duty power cord supports high-powered equipment and PDUs
- Extend a server or rackmount equipment power cord by an additional 6in
Website Search Keyword - 6in Heavy duty power cord
- L5-20P to 5-20R Power Cable
- L5-20P to 5-20R Power Cord
- Heavy gauge extension cable
- heavy duty power cable
Required Regulatory Compliance Marks - UL - Safety - Electrical - Canada / United States - Enhanced UL Mark
- Recycling - Waste - Japan - Paper Recycling Mark
- Recycling - Waste - Japan - Plastic Recycling Mark
- CE - Environmental - European Union - EU Restriction of Hazardous Substances (RoHS) 2011/65/EU
- WEEE - Waste - European Union - WEEE Mark (crossed-out wheeled bin)
- REACH - Environmental - European Union - Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- REACH - Environmental - United Kingdom - UK Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) - General Statement
- Triman/Info-Tri - Product - Waste - European Union - EEE Device
Input Current 20A Input Voltage 125V AC Cable Length (mm) 152.4 Cable OD 11.2 Color Black Humidity 0% to 65% RH Operating Temperature -20° to 105°C (-4° to 221°F) Product Length (mm) 170.000 Product Width (mm) 39.500 Product Height (mm) 34.800 Product Weight (g) 166.000 Storage Temperature -20° to 105°C (-4° to 221°F) TAA Compliant Yes Wire Gauge 12 AWG Features Locking Connector Voltage Rating 125V Cable Jacket Material PVC Cable Shield Overlap Aluminium-Mylar Foil Cable Type SJT Connector Plating Nickel Female Connector 5-20R Fire Rating VW-1 Rated Male Connector / Plug L5-20P Number of Conductors 3 Type AC Power Cord Carton Depth (mm) 466 Carton Height (mm) 244 Carton Quantity 75 Carton Weight Gross (g) 14066 Included in Package 1 - 6in NEMA L5-20P to NEMA 5-20R Heavy-Duty Power Cord Package Depth (mm) 68 Package Height (mm) 42 Package Width (mm) 251 Package Weight (g) 180 Packaging Description Heavy-Duty Power Cord - NEMA L5-20P to NEMA 5-20R - 6in (15cm) Black Packaging Description India Heavy-Duty Power Cord - NEMA L5-20P to NEMA 5-20R - 6in (15cm) Black Sub-Carton Depth (mm) 0 Sub-Carton Height (mm) 0 Sub-Carton Width (mm) 0 Sub-Carton Weight (g) 0 Connector 1 NEMA L5-20P (125V AC, 20A) Connector 1 (Quantity) 1 Connector 2 NEMA 5-20R (125V AC, 20A) Connector 2 (Quantity) 1 A+ Required Actual Inbox Documents Created None Amazon Merchandising Manager Veronica Ye Application Photos Required Artwork Due Date 2023-06-16 Buying Center - AV & Collaboration No Buying Center - Data Center Yes Buying Center - End User Compute No Buying Center - Networking & Edge Yes Comparable SKU Comment Not the same, close only. Comparable SKU 2 Comment NA Digital Content Due Date 2023-10-10 Enhanced Gallery Not Required Enhanced Gallery Designer Catherine Almeida en-US Content Approved Yes Focus Rank Level 0 - Not Applicable Graphic Designer Shane Arnett ID Label Silkscreened or a Label No ID label Launch Markets (concatenated) CA,US Product Development Specialist Alex Sikora Product Information Creation Specialist (PICS) Brian Chan Product Manager Tim North Product Performance Specialist Ray Aoki Product Photographer Shane Arnett Target Development Completion Date 2023-06-09 Target Production Release 2023-07-15 Tech Lead Justin Weaver Technical Writer Brian Chan Technology Lifecycle Mainstream Vending Machine Not Compatible with Vending Machine Video Not Required
